Traversing speed with RF382R Scanmode

The following table shows the traversing speed of a transponder through the main field. The direction of motion of the
transponder is horizontal.
Table 14 Traversing speed of different transponders
MDS D124
UID number 1.5 m/s
(8 bytes)

Mounting on metal

The RF382R can be mounted directly on metal. Flush mounting on metal is not permitted.

Minimum distance between several RF382R Scanmode readers

Figure 6 Minimum distance between several RF382R Scanmode readers
Minimum distance D from RF382R to RF382R
8
MDS D160
MDS D460
1.5 m/s
D ≥ 200 mm
MDS D324
MDS D424
1.5 m/s
SIMATIC RF382R Scanmode
J31069-D0214-U001-A1-7618, 10/2009
