System board callouts

Sys Bd Label
WLAN
WWAN
SPK
POWER
SIM
TOUCH
Sys Bd Label
CN2251
CN2250
48 Chapter 6 Removal and replacement procedures for the mobility head unit
Color Component
Gold WLAN module
Gold WWAN module
Black Speakers
White Power button
White SIM board
White Display
Color Component
Black Front-facing webcam
Black Rear-facing webcam
Sys Bd Label Color
NFC White
FPR White
LCM Black
POGO Black
SSD Black
Sys Bd Label Color
MIC ALS Black
Component
NFC module
Fingerprint reader
Display
POGO connector
M.2 SSD drive
Component
Webcam light
