Battery

To remove the battery:
1. Prepare the computer for disassembly (see
2. Remove the hand strap (see
3. Remove the rear cover (see
4. Remove the display (see
5. From the back of the computer, disconnect the battery cable from the system board.
6. From the front of the computer, remove the five screws (1) that secure the battery, and then lift the
battery out of the computer (2).
To install the battery reverse the removal procedures.
44 Chapter 6 Removal and replacement procedures for the mobility head unit
Preparing to disassemble the computer on page
Hand strap on page 38).
Backplate on page 39).
Display on page 40).
37).
