Backplate
1.
Prepare the computer for disassembly (see
2.
Remove the hand strap (see
3.
Loosen the two screws under the hand strap (1).
4.
Slide the backplate upward slightly, and then lift it up enough to access the cables underneath that
connect the backplate to the system board (2).
IMPORTANT:
disconnect the cables when lifting the backplate.
5.
If equipped, disconnect the NFC and/or fingerprint reader cables from the system board (1).
6.
Disconnect the communication cable from the system board (2), and then remove the backplate.
To replace the backplate, reverse the removal procedures.
Hand strap on page
Cables route from the backplate to the system board. Be sure not to accidentally
Preparing to disassemble the computer on page
38).
37).
Backplate
39
