Page 1
The model and serial numbers are located on the bottom of the unit. Record the serial number in the space provided below. Refer to these numbers whenever you call upon your Sony dealer regarding this product. Model No. CDX-GT61UI Serial No.
Page 2
(sold separately). Please see your nearest authorized Sony dealer for details on the satellite radio tuner module. “SAT Radio,” “SAT Radio Ready,” the SAT Radio and SAT Radio Ready logos and all related marks are trademarks of Sirius Satellite Radio Inc.
(analog connection). – CD/MD changers: CD/MD changers can be connected to the SONY BUS at the rear of the unit. *1 A CD TEXT disc is a CD-DA that includes information such as disc, artist and track name.
Setting the clock The clock uses a 12-hour digital indication. Press and hold the select button. The setup display appears. Press the select button repeatedly until “CLOCK-ADJ” appears. Press (SEEK) +. The hour indication flashes. Rotate the volume control dial to set the hour and minute.
Location of controls and basic operations Main unit PUSH SELECT SEEK Card remote commander RM-X151 SOURCE – DSPL – SOURCE SEEK MODE GP/ALBM SHUF DSPL qfqg Refer to the pages listed for details. The corresponding buttons on the card remote commander control the same functions as those on the unit.
K SEEK –/+ buttons CD/MD* /USB* /PD* To skip tracks (press); skip tracks continuously (press, then press again within about 1 second and hold); reverse/fast- forward a track (press and hold). Radio: To tune in stations automatically (press); find a station manually (press and hold). L Receptor for the card remote commander M MODE button 8, 10, 13...
For details on selecting a CD/MD changer, see page 13. Display items A AAC/WMA/ATRAC/MP3 indication B Source C Track/album/group number*, Disc/artist/ album/group/track name, Elapsed playing time, Text information, Clock * Album/group number is displayed only when the album is changed. To change display items C, press (DSPL);...
Tuning automatically Select the band, then press (SEEK) –/+ to search for the station. Scanning stops when the unit receives a station. Repeat this procedure until the desired station is received. If you know the frequency of the station you want to listen to, press and hold (SEEK) –/+ to locate the approximate frequency, then press (SEEK) –/+ repeatedly to fine adjust to the desired frequency...
Listening to music on a Mass Storage Class type audio device Repeat and shuffle play 1 During playback, press (3) (REP) or (4) (SHUF) repeatedly until the desired setting appears. Select To play TRACK track repeatedly. ALBUM album repeatedly. SHUF ALBUM album in random order.
• When the ignition key is turned to the ACC position, or the unit is on, the iPod will be recharged. • If the iPod is disconnected during playback, playback will pause. Note An another iPod cannot be connected using the XA- 110IP.
Other functions Changing the sound settings Adjusting the sound characteristics — BAL/FAD/SUB You can adjust the balance, fader, and subwoofer volume. Press the select button repeatedly until “BAL,” “FAD” or “SUB” appears. The item changes as follows: LOW* t MID* t HI* BAL (left-right) t FAD (front-rear) t SUB (subwoofer volume)*...
LOCAL (Local Seek Mode) – “LOCAL-ON” : to only tune into stations with stronger signals. – “LOCAL-OFF” ( ): to tune normal reception. MONO* (Monaural Mode) To improve poor FM reception, select monaural reception mode. – “MONO-ON” : to hear stereo broadcast in monaural.
Repeat and shuffle play 1 During playback, press (3) (REP) or (4) (SHUF) repeatedly until the desired setting appears. Select To play DISC* disc repeatedly. SHUF tracks in the changer in random CHANGER* order. SHUF ALL* tracks in all units in random order.
USB devices via a USB hub, and is not compatible with devices that have a hub function. For details on the compatibility of your USB device, visit the Sony support website (page 21). • Corresponding codecs differ depending on device type.
For customers in USA, please visit the following site for further information: http://www.xplodsony.com If you have any questions or problems concerning your unit that are not covered in this manual, consult your nearest Sony dealer. Maintenance Replacing the lithium battery of the card remote commander...
If the fuse blows again after replacement, there may be an internal malfunction. In such a case, consult your nearest Sony dealer. Cleaning the connectors The unit may not function properly if the connectors between the unit and the front panel are not clean. In order to prevent this, detach the front panel (page 5) and clean the connectors with a cotton swab.
Fraunhofer IIS and Thomson. Note This unit cannot be connected to a digital preamplifier or an equalizer which is Sony BUS system compatible. Design and specifications are subject to change without notice. • Halogenated flame retardants are not used in the certain printed wiring boards.
Page 19
General No power is being supplied to the unit. • Check the connection. If everything is in order, check the fuse. • If the unit is turned off and the display disappears, it cannot be operated with the remote commander. t Turn on the unit.
OFFSET There may be an internal malfunction. t Check the connection. If the error indication remains on in the display, consult your nearest Sony dealer. OVERLOAD USB device is overloaded. t Disconnect the USB device, then change the source by pressing (SOURCE).
Page 21
*2 The disc number of the disc causing the error appears in the display. If these solutions do not help improve the situation, consult your nearest Sony dealer. If you take the unit to be repaired because of CD playback trouble, bring the disc that was used at the time the problem began.
Page 22
(se vende por separado). Si desea obtener más detalles sobre el módulo de sintonizador de radio por satélite, póngase en contacto con el distribuidor Sony autorizado más cercano. “SAT Radio”, “SAT Radio Ready”, los logotipos de SAT Radio, SAT Radio Ready y todas las marcas relacionadas son marcas comerciales de Sirius Satellite Radio Inc.
Page 23
Tabla de contenido Bienvenido......4 Procedimientos iniciales Restauración de la unidad ....4 Preparación del control remoto de tarjeta .
USB. Para obtener detalles de los dispositivos que se pueden utilizar, consulte “Acerca de los dispositivos USB” (página 16) o el sitio web de asistencia técnica de Sony (página 22). – Dispositivo de audio portátil: es posible conectar un dispositivo de audio portátil mediante la toma de entrada AUX situada en la parte frontal de la unidad (conexión...
Para mostrar el reloj, presione (DSPL). Vuelva a presionar (DSPL) para regresar a la pantalla anterior. Con el control remoto de tarjeta En el paso 4, para ajustar la hora y los minutos, presione M o m. Extracción del panel frontal Puede extraer el panel frontal de la unidad para evitar que la roben.
Ubicación de los controles y operaciones básicas Unidad principal PUSH SELECT SEEK Control remoto de tarjeta RM-X151 SOURCE – DSPL – SOURCE SEEK MODE GP/ALBM SHUF DSPL qfqg Consulte las páginas indicadas para obtener información detallada. Los botones correspondientes en el control remoto de tarjeta controlan las mismas funciones que los de la unidad.
Page 27
K Botones SEEK –/+ CD/MD* /USB* /PD* Para saltar pistas (presionar); para saltar pistas en forma continua (presionar y volver a presionar antes de que transcurra 1 segundo y mantener); para avanzar o retroceder una pista rápidamente (mantener presionado). Radio: Para sintonizar emisoras automáticamente (presionar);...
Para obtener más detalles sobre cómo seleccionar un cambiador de CD/MD, consulte la página 14. Elementos de la pantalla A Indicación AAC/WMA/ATRAC/MP3 B Fuente C Número de pista/álbum/grupo*, nombre del disco/artista/álbum/grupo/pista, tiempo de reproducción transcurrido, información de texto, reloj * El número de álbum/grupo se muestra solamente cuando se cambia de álbum.
Sintonización automática Seleccione la banda y, a continuación, presione (SEEK) –/+ para buscar la emisora. La búsqueda se detiene cuando la unidad recibe una emisora. Repita este procedimiento hasta recibir la emisora deseada. Sugerencia Si conoce la frecuencia de la emisora que desea escuchar, mantenga presionado (SEEK) –/+ para localizar la frecuencia aproximada y, a continuación, presione (SEEK) –/+ varias veces para ajustar la...
Nota La pantalla puede variar en función del dispositivo USB de almacenamiento masivo y del dispositivo deaudio ATRAC. Escuchar música en un dispositivo de audio de tipo clase de almacenamiento masivo Reproducción repetida y aleatoria 1 Durante la reproducción, presione (3) (REP) o (4) (SHUF) varias veces hasta que aparezca el ajuste deseado.
iPod Reproducción en un iPod Si se conecta un iPod al conector de base situado en la parte posterior de la unidad, podrá escuchar el sonido a través de los altavoces del automóvil y controlar el iPod desde la unidad. Notas •...
Reproducción repetida y aleatoria Durante la reproducción, presione (3) (REP) o (4) (SHUF) hasta que aparezca el ajuste deseado. Seleccione Para reproducir REP TRK pistas en forma repetida. REP ALB álbumes en forma repetida. REP ART artistas en forma repetida. REP PLY listas de reproducción en forma repetida.
Gire el selector de control de volumen para ajustar el elemento seleccionado. El nivel de volumen puede ajustarse en intervalos de 1 dB, entre –10 dB y +10 dB. Repita los pasos 2 y 3 para ajustar la curva de ecualizador.
Uso de equipo opcional Equipo de audio auxiliar Si conecta un dispositivo de audio portátil opcional a la toma de entrada AUX (minitoma estéreo) de la unidad y simplemente selecciona la fuente, podrá escuchar por los altavoces del automóvil. Puede ajustar cualquier diferencia en el nivel de volumen entre la unidad y el dispositivo de audio portátil.
Información complementaria Precauciones • Si estaciona el automóvil bajo la luz directa del sol, deje que la unidad se enfríe antes de usarla. • La antena motorizada se extenderá automáticamente mientras la unidad se encuentre en funcionamiento. Condensación de humedad En días lluviosos o en zonas muy húmedas, es posible que se condense humedad en el interior de las lentes y la pantalla de la unidad.
Para obtener más información acerca de la compatibilidad del dispositivo USB, visite el sitio Web de soporte técnico de Sony (página 22). • El códec correspondiente difiere en función del tipo de dispositivo. – Almacenamiento masivo: MP3/WMA/AAC –...
Si desea realizar alguna consulta o solucionar algún problema relativo a la unidad que no se trate en este manual, póngase en contacto con el distribuidor Sony más cercano. Mantenimiento Sustitución de la pila de litio del control remoto de tarjeta En condiciones normales, la pila dura aproximadamente 1 año.
En tal caso, consulte con el distribuidor Sony más cercano. Limpieza de los conectores Es posible que la unidad no funcione correctamente si los conectores entre ésta y el panel frontal están sucios.
Nota Esta unidad no puede conectarse a un preamplificador digital ni a un ecualizador que sea compatible con el sistema BUS de Sony. El diseño y las especificaciones están sujetos a cambios sin previo aviso. • Ciertas placas del circuito impreso no contienen retardantes de llama halogenados.
Page 40
Las emisoras almacenadas y la hora correcta se borraron. El fusible se fundió. Se escucha ruido cuando se cambia la posición de la llave de encendido. Los cables no coinciden correctamente con el conector de alimentación auxiliar del automóvil. Las indicaciones desaparecen del visualizador o no aparecen en él.
Es posible que se haya producido una falla interna. t Revise la conexión. Si el indicador de error permanece en pantalla, póngase en contacto con el distribuidor Sony más cercano. OVERLOAD El dispositivo USB está sobrecargado. t Desconecte el dispositivo USB y, a continuación, presione (SOURCE) para cambiar la fuente.
Page 42
*2 La pantalla muestra el número del disco que causa el error. Si estas soluciones no ayudan a mejorar la situación, póngase en contacto con el distribuidor Sony más cercano. Si entrega la unidad para su reparación a causa de problemas en la reproducción de CD, lleve el disco...
Note: Stored data may be erased. Please contact (U.S.A. only); Call Support site If you have any questions or for the latest support information on this product, please visit the web site below: http://esupport.sony.com http://www.sony.com/xplod http://www.sony.net/ Sony Corporation Printed in Thailand 1-800-222-7669 http://www.SONY.com...
