Kohler Rite-Temp K-8300-PX Quick Start Manual

Features
•
Includes valve body, rough-in guide and test cap
•
1/2" PEX Crimp (F1807 style) inlets
•
1/2" Universal NPT & direct sweat outlets
•
Requires valve cartridge and trim to complete installation (sold
separately).
Material
•
Forged De-zincification Resistant Brass body provides long
term reliability and resistance to aggressive water conditions
Installation
•
Designed for use in standard, back to back and thin wall
installations
•
Valve body features integral mounting locations and symmetrical
valve inlets to simplify installation
•
Rough-in guide designed for both standard and thin wall
installations
•
Installed valve rough-in can be flushed and pressure tested to
150psi max (air or water) without cartridge, using K-10351 Test
Cap (supplied)
Required Accessories
K-8305/K-P8305 Series Rite-Temp Cartridges
USA/Canada: 1-800-4KOHLER (1-800-456-4537)
Kohler Co. reserves the right to make revisions without notice to product specifications.
For the most current Specification Sheet, go to www.kohler.com.
7-28-2017 07:43
Valve Body Rough-In
Codes/Standards
ASME A112.18.1/CSA B125.1
KOHLER Faucet Lifetime Limited
Warranty
See website for detailed warranty information.
Rite-Temp
K-8300-PX
