Quadra-Fire EXCURSION-I Owner's Manual page 31

IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer
or distributor. Hearth and Home Technologies does not sell directly to consumers.
Provide model number and serial number when requesting service parts from your dealer
or distributor.
ITEM
Log Assembly (Hearth Refractory not Included)
1 Log 1
2 Log 2
3 Log 3
4 Log 4
5 Log 5
6 Log 6
7 Log 7
8 Log 8
9 Slide Plate Assembly
Tool, Slide Plate (Multi-purpose)
Gasket
10 Glass Clip Assembly, Top
11 Baf e, Firebox
12 Glass Clip Assembly, Bottom
13 Light Glass, Hold Down
14 Accent Glass
15 Light Glass Gasket
16 Halogen Re ector Lamp, 50W
17 Light Tub Assembly
Light Wire Assembly
18 Air Scoop
19 Pilot Shield
20 Burner Assembly
21 Base Pan
22 Grate
23 Refractory Assembly
Hearth, Refractory
24 Seal, Glass Frame
25 Glass Door Assembly
26 Power Cord
Fan
Additional service part numbers appear on following page.
Quadra-Fire • EXCURSION-I, EXCURSION-II, EXCURSION-III Owner's Manual • 2538-981 Rev. B • 2/19
Service Parts
R
DESCRIPTION
EXCURSION-III
Beginning Manufacturing Date: March 2019
Ending Manufacturing Date: Active
COMMENTS PART NUMBER
LOGS-2539
SRV2539-711
SRV2539-712
SRV2539-713
SRV2539-714
SRV2538-715
SRV2539-716
SRV2538-717
SRV2539-718
2532-014
2532-140
2532-113
Qty 2 req 2155-046
2533-138
Qty 2 req 2532-009
Qty 2 req 2532-149
Qty 2 req 2532-151
Qty 4 req 2532-150
Qty 2 req 2201-150
Qty 2 req 2532-006
2532-017
2532-135
2532-153
2539-007
2539-130
2538-014
SRV2539-076
SRV2539-703
2533-122
GLA-2533
2201-024
GFK-160A
Stocked
at Depot
Y
Y
Y
Y
Y
Y
Y
31
