K30 SERIES
RANGE HOODS
Seamless, handcrafted beauty and multifaceted
construction create a timeless object of desire.
FEATURES
•
Italian design
•
Wall mount
•
Finishes: 304 Stainless Steel #4 Brushed, White, Black
•
Widths: 35-7/16" (90cm), 48"
•
Ducted telescopic flue accommodates 8' to 9' ceilings
•
6" round duct connector/backdraft damper
•
Halogen lighting (2 x 20 watt, Type MR16 for 35-7/16"
model; 3 x 20 watt, Type MR16 for 48" model) provides two-
level lighting – bright cooktop illumination and a low
nighttime setting (bulbs included)
•
Advanced, multispeed, electronic push-button controls
with individual speed indicators
•
Quiet, variable-speed centrifugal blower with high-
efficiency motor produces 500 CFM of exhaust
•
Delay timer control automatically shuts off range hood
after ten minutes
•
Special control indicates when it's time to clean the filter
•
Dishwasher-safe filters feature a quick-release latch and
polished stainless steel
•
TM
Heat Sentry
- automatically turns blower to high speed
when excess cooking heat is detected
OPTIONS
•
Replacement grease filters available
•
Flue extension for 10' ceiling (Model FEXTK30 in Stainless
Steel, White, Black) (30-1/8" Long)
•
Exterior blower version (KEX30) available, providing 600,
900, 1200, or 1500 CFM exhaust
SPECIFICATIONS
VOLTS
AMPS
CFM
120
3.13/3.34
500
REFERENCE
QTY.
SONES
DUCT
8.5
6" round
BEST BY BROAN P.O. BOX 140 HARTFORD, WISCONSIN 53027
REMARKS
SPECIFICATION SHEET
HVI-2100 CERTIFIED RATINGS comply with new testing
technologies and procedures prescribed by the Home
Ventilating Institute, for off-the-shelf products, as they
are available to consumers. Product performance is
rated at 0.1 in. static pressure, based on tests
conducted in AMCA's state-of-the-art test laboratory.
Sones are a measure of humanly-perceived loudness,
based on laboratory measurements.
Project
Location
Architect
Engineer
Contractor
Submitted by
50J
Date
99043158C
