- Page 1 Paper Feed Unit PB2010 Machine Code: D699 Field Service Manual December, 2012 Subject to change...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. Paper Feed Unit PB2010 (D699) Safety and Symbols............................3 Replacement Procedure Safety........................3 Symbols Used in this Manual........................3 2. Replacement and Adjustment Covers and Roller...............................5 Covers................................5 Rear Cover.............................5 Right Cover.............................5 Feed Roller..............................6 Drive Components..............................7 Upper Feed Clutch............................7 Lower Feed Clutch............................7 Relay Clutch..............................8... - Page 4 Paper Size Detection............................25 Side and End Fences............................27 Side Fences..............................27 End Fence..............................27...
-
Page 5: Paper Feed Unit Pb2010 (D699)
1. Paper Feed Unit PB2010 (D699) Safety and Symbols Replacement Procedure Safety • Turn off the main power switch and unplug the machine before beginning any of the replacement procedures in this manual. Symbols Used in this Manual This manual uses the following symbols. - Page 6 1. Paper Feed Unit PB2010 (D699)
-
Page 7: Replacement And Adjustment
2. Replacement and Adjustment Covers and Roller Covers Rear Cover 1. Hold brackets [A] ( x 1 each) 2. Rear cover [B] ( x 3) Right Cover 1. Right cover [A] ( x 2) • Do not remove the anti-tip components [A] at the bottom of the unit. -
Page 8: Feed Roller
2. Replacement and Adjustment Feed Roller 1. Pull out the tray [A]. 2. Release the lock lever [B]. 3. Feed roller [C]... -
Page 9: Drive Components
Drive Components Drive Components • Turn off the main power switch and unplug the machine before beginning any of the procedures in this section. Upper Feed Clutch 1. Rear cover ( p.5 "Covers") 2. Bracket [A] ( x 2) 3. Hold bracket [B] ( x 1, bushing x 1) 4. -
Page 10: Relay Clutch
2. Replacement and Adjustment Relay Clutch 1. Rear cover ( p.5 "Covers") 2. Relay clutch [A] ( x 1, x 1) Paper Feed Motor 1. Rear cover ( p.5 "Covers") 2. Tray main board ( p.12 "Tray Main Board") 3. Gear [A] ( x 1) 4. -
Page 11: Lift Motors
Drive Components Lift Motors Upper Lift Motor 1. Rear cover ( p.5 "Covers") 2. Spring [A] (snap ring x 1, spacer x 1) 3. Lift motor bracket [B] ( x 3, x 1) -
Page 12: Lower Lift Motor
2. Replacement and Adjustment 4. Upper lift motor [C] ( x 3) Lower Lift Motor 1. Rear cover ( p.5 "Covers") 2. Spring (snap ring x 1, spacer x 1) 3. Lift motor bracket ( x 4, x 1) 4. Lower lift motor ( x 3) -
Page 13: Electrical Components
Electrical Components Electrical Components • Turn off the main power switch and unplug the machine before beginning any of the procedures in this section. Vertical Transport Sensor 1. Open the tray cover [A]. 2. Guide plate [B] ( x 2) 3. -
Page 14: Paper Size Sensors
2. Replacement and Adjustment Paper Size Sensors 1. Pull out the two trays. 2. Sensor bracket cover [A] ( x 1) 3. Sensor bracket [B] ( x 3, x 2) 4. Paper size sensors (hooks) Tray Main Board 1. Rear cover ( p.5 "Covers") 2. - Page 15 Electrical Components...
- Page 16 2. Replacement and Adjustment...
-
Page 17: Detailed Section Descriptions
3. Detailed Section Descriptions Component Layout Mechanical Component Layout 1. Upper paper feed roller 5. Lower tray 2. Lower paper feed roller 6. Upper tray 3. Lower bottom plate 7. Upper bottom plate 4. Optional tray heater... -
Page 18: Electrical Component Layout
3. Detailed Section Descriptions Electrical Component Layout... -
Page 19: Electrical Component Description
Component Layout 1. Paper size sensor 13. Tray heater (Option) 2. Paper size sensor 14. Transport motor 3. Paper size sensor 15. Main board 4. Tray lift motor 16. Tray lift motor 5. Tray set switch 17. Paper feed clutch 6. - Page 20 3. Detailed Section Descriptions Tray Lift Sensor Detects the amount of paper in the lower tray. Relay Sensor Detects misfeeds. Paper Size Sensor Determines what paper size is in the upper tray. Paper Size Sensor Determines what paper size is in the upper tray. Paper Size Sensor Determines what paper size is in the upper tray.
-
Page 21: Drive Layout
Component Layout Drive Layout 1. Paper feed motor 5. Lower paper feed clutch 2. Drive belt 6. Upper paper feed roller 3. Upper paper feed clutch 7. Relay roller 4. Relay clutch 8. Lower paper feed roller... -
Page 22: Paper Feed And Separation Mechanism
3. Detailed Section Descriptions Paper Feed and Separation Mechanism The paper tray holds 500 sheets. The paper feed roller [A] drives the top sheet of paper from the paper tray to the copier/printer. The friction pad [B] allows only one sheet to feed at a time. The friction pad applies pressure to the feed roller with a spring [C]. -
Page 23: Paper Lift Mechanism
Paper Lift Mechanism Paper Lift Mechanism The paper size switch detects when the tray is pushed in. When the paper tray is pushed into the machine, the pin [A] for the lift motor pressure shaft engages the lift motor coupling [B] and the pin [C] for the bottom plate lift shaft in the tray engages the bottom plate pressure lever coupling [D]. - Page 24 3. Detailed Section Descriptions When the paper tray is pulled out, the pins [A, C] disengage from the couplings [B, D], and the bottom plate drops. To make it easier to push the tray in, the lift motor rotates backwards 1.7 seconds to return the bottom plate pressure lever coupling [D] to the original position.
-
Page 25: Paper End Detection
Paper End Detection Paper End Detection If there is some paper in the paper tray, the paper stack raises the paper end feeler [A] and the paper end sensor [B] is deactivated. When the paper tray runs out of paper, the paper end feeler drops into the cutout [C] in the tray bottom plate and the paper end sensor is activated. -
Page 26: Paper Height Detection
3. Detailed Section Descriptions Paper Height Detection The amount of paper in the tray is detected by the combination of on/off signals from two paper height sensors [A] and [B]. When the amount of paper decreases, the bottom plate pressure lever [C] moves the actuator up. The following combination of sensor signals is sent to the copier/printer. -
Page 27: Paper Size Detection
Paper Size Detection Paper Size Detection There are three paper size sensors [A] (SN1, SN2 and SN3) on the paper tray unit. Each paper tray has its own actuator [B], with a unique combination of notches. This actuator is moved when the paper end fence [C] is adjusted for the installed paper. - Page 28 3. Detailed Section Descriptions LT SEF* 11" x 8 " B5 SEF 257 x 182 EXE SEF* " x 7 " A5 SEF 210 x 148 NA Size A3 LEF* 297 x 420 DLT LEF 11" x 17" B4 LEF* 257 x 364 LG LEF "...
-
Page 29: Side And End Fences
Side and End Fences Side and End Fences Side Fences If the tray is full of paper and it is pushed in strongly, the fences may deform or bend. This may cause the paper to skew or the side-to-side registration to be incorrect. To correct this, each side fence has a stopper [A] attached to it. - Page 30 MEMO...
