Front Wheel Bracket - Snapper NP216012 Parts Manual

Front Wheel Bracket

Item Part No Qty
1 7051886
7051885
2 7015761
3 7012325
4 7027702
5A 7031017
5B 7031016
6 7011791
7 7091601
8 7074702
9 7021119
Footnotes:
21" STEEL DECK WALK BEHIND MOWERS
SERIES 12, 14, 15, & 16
Description
ASSEMBLY, Arm Right Wheel
ASSEMBLY, Arm Left Wheel
BOLT, 5/16-18 x 3/4" Shoulder
LATCH, Height
GRIP, Latch
ARM, Right Wheel (Round Hole)
ARM, Left Wheel (Square Hole)
RETAINER, 5/16 Bolt
NUT, 5/16-18 Hex Flange Lock, Grade 5
BRACKET, Front Wheel
AXLE
15
Note
(Consists of Items 2,3,4,5A,6)
(Consists of Items 2,3,4,5B,6)
(Not shown)
Was 91070
Was 41770
Manual No. 7006059
TP 400-5137-7-WB-N
