  5. YARD CRUISER YZ145333BVE
  6. Safety instructions & operator's manual

Snapper YZ145333BVE, YZ145383BVE Safety Instructions & Operator's Manual

Hydro drive series 3
Hide thumbs
Table of Contents

Advertisement

Quick Links

MODEL DESIGNATION
DRIVE SYSTEM TYPE
ENGINE HORSE POWER
CUTTING WIDTH
Y – Yard Cruiser
145 - 14.5 HP Engine
Z – Zero Turning Radius
Thank you for buying a SNAPPER Product! Before operating your YARD CRUISER, read this manual carefully
and pay particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Pages 2 & 3. Remember that all
power equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in
accordance with the operating instructions and common sense!
COPYRIGHT © 2001
SNAPPER INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
MODEL NUMBER EXPLANATION
Y
Z
145
33 - 33" Cutting Deck
38 - 38" Cutting Deck
YARD CRUISER
33
3
B
3 - Series Designation
MANUAL No. 7-4471 (Rev 1, 8/29/01)

HYDRO DRIVE

SERIES 3
MODELS
YZ145333BVE
YZ145383BVE
V
E
ENGINE OPTIONS
ENGINE TYPE
SERIES DESIGNATION
B - Briggs Engine
E - Electric Start
V – Over Head Valve
