Snapper NR205012, R204513E, R205012 Safety Instructions & Operator's Manual

Snapper NR205012, R204513E, R205012 Safety Instructions & Operator's Manual

20” steel deck walk mowers series 12
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PREFIX
N
R
20
SERIES
CUTTING
DESIGNATION
WIDTH
Thank you for buying a SNAPPER Product! Before operating your Walk Behind, read this manual carefully and pay
particular attention to the "IMPORTANT SAFETY INSTRUCTIONS" on Page 2. Remember that all power equipment can be
dangerous if used improperly. Also keep in mind that SAFETY requires careful use in accordance with the operating
instructions and common sense.
COPYRIGHT © 1996
SNAPPER INC.
ALL RIGHTS RESERVED
Safety Instructions & Operator's Manual for
MODEL NUMBER EXPLANATION
BODY
SUFFIX
50
12
ENGINE
SERIES
HP
DESIGNATION
20" STEEL DECK
WALK MOWERS
SERIES 12
PREFIX EXPLANATION
R - Recycling Mower
N - California Model
BODY EXPLANATION
20 - 20" Cutting Width
SUFFIX EXPLANATION
12 - Series Designation
MANUAL No. 3-5806 (I.R. 8/96)
MODELS
R205012
NR205012
50 - 5.0 HP Engine
