Section 1 - FAMILIARIZATION
WHEEL DRIVE
CONTROL
ENGINE
SPEED
CONTROL
ROPE
START
HANDLE
SINGLE POINT
HEIGHT OF CUT
ADJUSTING HANDLE
HANDLEBAR
SUPPORT
FUEL CAP
MOWER DECK
1.1 INTRODUCTION
This manual has been prepared for the operators of the
SNAPPER WALK BEHIND MOWERS. Its purpose,
aside from recommending operating and routine service
requirements, is to promote safety through the use of
accepted operating practices. Read, Understand and
Follow the "IMPORTANT SAFETY INSTRUCTIONS" on
Pages 2 & 3 of this manual and all safety messages on
the mower and attachments before operating the
mower.
HANDLEBAR
BLADE
CONTROL
GROUND SPEED
CONTROL
GRASS CATCHER
FIGURE 1.1
1.2 NOMENCLATURE
The nomenclature information above, Figure 1.1, shows
the essential parts of the SNAPPER WALK BEHIND
MOWERS. It is recommended that all operators of the
mower become thoroughly familiar with the controls,
parts and operation of the mower before operating.
Specific details involving the engine are found in the
separate engine owner's manual. Study these manuals
before operating and keep both handy for future
reference.
6
DISCHARGE
DOOR
OIL FILL/CHECK
