COPYRIGHT © 2005
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
19" WALK-BEHIND MOWERS
McDonough, GA, 30253 U.S.A.
Revision 3,
Parts Manual for
SERIES 0, 1, 3, & 5
9/20/2005
MODEL
19300
19300-2
19301-2
19301D
19301D-2
19301T
19303
19303-2
19303-2T
19303B
19303D
19303D-2
19303D-2T
19303DB
19305-2T
19305B
19305DB
G19355
Manual No. 7006031
TP 400-5101-3-WB-N
Advertisement
Table of Contents
Related Manuals for Snapper 19300-2
Summary of Contents for Snapper 19300-2
- Page 1 COPYRIGHT © 2005 SNAPPER PRODUCTS, INC. ALL RIGHTS RESERVED. 19" WALK-BEHIND MOWERS SERIES 0, 1, 3, & 5 McDonough, GA, 30253 U.S.A. Revision 3, 9/20/2005 Parts Manual for MODEL 19300 19300-2 19301-2 19301D 19301D-2 19301T 19303 19303-2 19303-2T 19303B 19303D...
-
Page 3: Table Of Contents
PAGE GROUP Upper & Middle Handles & Controls - Series 0, 1 & 3 Upper & Middle Handles & Controls - Series 5 Lower Handles (19300, 19301 Series) Lower Handles - Series 3 & 5 Cutting Deck, Blade, Interlock Wheels, Guard, Axles Accessory - Side Chute, Adapter, Grass Catcher - Series 0 &... -
Page 4: Upper & Middle Handles & Controls - Series 0, 1 & 3
Upper & Middle Handles & Controls - Series 0, 1 & 3 Manual No. 7006031 19" WALK-BEHIND MOWERS TP 400-5101-3-WB-N SERIES 0, 1, 3, & 5... - Page 5 Upper & Middle Handles & Controls - Series 0, 1 & 3 Item Part No Description 7036153 HANDLE, Upper 7036029 HANDLE, Upper 7014343 BUSHING 14310 DECAL, Blade Controls 7019714 CONTROL, Blade 7033904 CLIP (Left Hand-Tecumseh, Right Hand-Briggs) 7014305 CABLE, Control (Briggs) 7014306 CABLE, Control (Tecumseh) 7090898...
-
Page 6: Upper & Middle Handles & Controls - Series 5
Upper & Middle Handles & Controls - Series 5 Manual No. 7006031 19" WALK-BEHIND MOWERS TP 400-5101-3-WB-N SERIES 0, 1, 3, & 5... - Page 7 Upper & Middle Handles & Controls - Series 5 Item Part No Description 7036204 HANDLE, Upper 7036202 HANDLE, Middle 7019714 CONTROL, Blade 7033904 CLIP (Left Hand-Tecumseh, Right Hand-Briggs) 7014305 CABLE, Control (Briggs & Stratton) 7014306 CABLE, Control (Tecumseh) 7014343 BUSHING 7023813 CLIP 7015693...
-
Page 8: Lower Handles (19300, 19301 Series)
Lower Handles (19300, 19301 Series) Manual No. 7006031 19" WALK-BEHIND MOWERS TP 400-5101-3-WB-N SERIES 0, 1, 3, & 5... - Page 9 Lower Handles (19300, 19301 Series) Item Part No Description 7039746 HANDLE, Lower 7015693 NUT, 1/4-20 Wing 7090015 BOLT, 1/4-20 x 1-3/4" Square Neck Carriage 7091303 BOLT, 5/16-18 x 1" Short Neck Carriage, Grade 5 7090189 WASHER, 5/16" Internal/External Tooth Lock 7090188 WASHER, 5/16"...
-
Page 10: Lower Handles - Series 3 & 5
Lower Handles - Series 3 & 5 Manual No. 7006031 19" WALK-BEHIND MOWERS TP 400-5101-3-WB-N SERIES 0, 1, 3, & 5... -
Page 11: Handle, Lower
Lower Handles - Series 3 & 5 Item Part No Description 7038209 HANDLE, Lower 7038246 HANDLE, Lower R.H. 7038247 HANDLE, Lower L.H. 7035342 HANDLE, Lower R.H. 7046502 HANDLE, Lower L.H. 7090015 BOLT, 1/4-20 x 1-3/4" Short Neck Carriage 7015693 NUT, 1/4-20 Wing 7090799 BOLT, 5/16-18 x 5/8"... -
Page 12: Cutting Deck, Blade, Interlock
Cutting Deck, Blade, Interlock Manual No. 7006031 19" WALK-BEHIND MOWERS TP 400-5101-3-WB-N SERIES 0, 1, 3, & 5... - Page 13 Cutting Deck, Blade, Interlock Item Part No Description 40525 *DECK, Structure (Short engine mount) 7019711 BLADE, Cutter 7090167 SCREW, 3/8-24 x 2" Hex Head Cap, Grade 5 7012063 WASHER, Cone 7010783 KEY, Hi-Pro 7012927 HUB, Blade Drive 7032137 SPRING, Interlock 7012048 INSULATOR, Interlock 7090385...
-
Page 14: Wheels, Guard, Axles
Wheels, Guard, Axles Manual No. 7006031 19" WALK-BEHIND MOWERS TP 400-5101-3-WB-N SERIES 0, 1, 3, & 5... -
Page 15: Washer, 5/16" Flat
Wheels, Guard, Axles Item Part No Description 7026160 WHEEL, Front 7 x 1.50 7013024 HUB-CAP, Wheel 7013320 BUSHING, Height Adjustment 7013307 SPRING, Front Axle 7090122 WASHER, 3/8" Flat 7034357 AXLE, 3/8 x 19-3/8" 7029399 WHEEL, Rear 8 x 1.75 7032118 CLIP, Rear Guard 7013027 SPRING, Rear Axle... -
Page 16: Accessory - Side Chute, Adapter, Grass Catcher - Series 0 & 1
Accessory - Side Chute, Adapter, Grass Catcher - Series 0 & 1 Manual No. 7006031 19" WALK-BEHIND MOWERS TP 400-5101-3-WB-N SERIES 0, 1, 3, & 5... - Page 17 Accessory - Side Chute, Adapter, Grass Catcher - Series 0 & 1 Item Part No Description 7060422 KIT, Grass Catcher 7018413 BAG, Grass 7050711 ASSEMBLY, Rope & Slider 7053681 ADAPTER, Bag 7047876 CONNECTOR, Bag 7018412 WIRE, Rear Bag 7090375 WING-NUT, 5/16-18 7035771 CHUTE, Side 20"...
-
Page 18: Accessory - Grass Bag
Accessory - Grass Bag Manual No. 7006031 19" WALK-BEHIND MOWERS TP 400-5101-3-WB-N SERIES 0, 1, 3, & 5... -
Page 19: Screw, 5/16-18 X 1/2" Hex Head Cap, Grade
Accessory - Grass Bag Item Part No Description 7060738 KIT, KWIN-N-EZY Catcher 7060933 KIT, KWIN-N-EZY Catcher 7051636 ASSEMBLY, Grass Bag 7016005 BAG, KWIK-N-EZY 7051889 ASSEMBLY, Bag Wire 7047876 CONNECTOR, Grass Bag 7053681 ADAPTER, Bag 7023152 DEFLECTOR, Muffler (Briggs) 7023023 SCREW, #8-18 x 3/8" Hex Head Cap Footnotes: 19"... -
Page 20: Accessory - Mulcherizer
Accessory - Mulcherizer Manual No. 7006031 19" WALK-BEHIND MOWERS TP 400-5101-3-WB-N SERIES 0, 1, 3, & 5... -
Page 21: Nut
Accessory - Mulcherizer Item Part No Description 60457 KIT, Mulcherizer 7019690 LINER 7013870 HUB, 7/8" I.D. 7019673 BLADE, Mulcherizer 7090483 SCREW, 3/8-24 x 1-3/4" Hex Head Cap, Grade 5 7012063 WASHER, Cone 7090100 SCREW, 1/4-28 x 5/8" Hex Head Cap, Grade 5 7091294 WASHER, 1/4"... -
Page 22: Decals
Decals Manual No. 7006031 19" WALK-BEHIND MOWERS TP 400-5101-3-WB-N SERIES 0, 1, 3, & 5... - Page 23 Decals Item Part No Description 7013010 DECAL, Danger (Keep Hands & Feet Away) 7011160 DECAL, Cranking 7012929 FOOT-PAD 7013298 DECAL, Stop Warning 13297 DECAL, Stop Warning 7013312 DECAL, Caution (Side Chute-Grass Catcher) 7023870 DECAL, Start-Stop 7024211 DECAL, Blade Control 7014898 DECAL, Warning - Discharge Opening Footnotes: 19"...
-
Page 26: 19" Walk-Behind Mowers Series 0, 1, 3
Parts Manual for 19" WALK-BEHIND MOWERS SERIES 0, 1, 3, & 5 IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
