LCD Projector
8960WUSS/8951WUSS
8960WSS/8951WSS
User's Manual (concise)
Thank you for purchasing this product.
Visit Dukane AV website at www.dukaneav.com and look for the downloads
pertaining to this model. The manuals , specifications, and links to the software
for this product, will be listed.
The web site SUPPORT page has the Product Downloads for all Data Video
Projectors
Before using this product be sure to read all manuals for this product. After
reading them, store them in a safe place for future reference.
Heed all the warnings and cautions in the manuals or on the product.
Follow all the instructions in the manuals or on the product.
NOTE • In this manual, unless any comments are accompanied, "the manuals" means
all the documents provided with this product, and "the product" means this projector and
all the accessories came with the projector.
Contents
First of all ...........................................2
Laser warning ..................................5
with recycling systems ...................6
Contents of package..........................7
Arrangement ......................................9
Turning on the power .......................13
8951WUSS-8960WUSS-8951WSS-8960WSS-Concise User Manual-00
WARNING
Displaying the picture ......................15
Turning off the power .......................16
Cleaning and replacing
the internal clock battery ...............19
for the product software ................22
1
.....................................17
..................................20

Advertisement

Table of Contents
loading

Related Manuals for Dukane 8960WUSS

Summary of Contents for Dukane 8960WUSS

  • Page 1: Table Of Contents

    8960WSS/8951WSS User's Manual (concise) Thank you for purchasing this product. Visit Dukane AV website at www.dukaneav.com and look for the downloads pertaining to this model. The manuals , specifications, and links to the software for this product, will be listed.

  • Page 2: First Of All

    First of all Graphical symbols explanation The following entries and graphical symbols are used for the manuals and the product as follows, for safety purpose. Know their meanings beforehand and heed them. WARNING This entry warns of a risk of serious personal injury or even death. CAUTION This entry warns of a risk of personal injury or physical damage.
  • Page 3 Important safety instructions (continued) WARNING Do not modify the projector or accessories. Do not let any things or any liquids enter to the inside of the product. Do not get the product wet. are used. Oil may harm the product, resulting in malfunction, or falling from the mounted position.

  • Page 4: Electro-Magnetic Interference

    Electro-magnetic interference This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. This product may cause interference if used in residential areas. Such use must be avoided unless the user takes special measures to reduce electromagnetic emissions to prevent interference to the reception of radio and television broadcasts.

  • Page 5: Laser Warning

    Top view RG2 IEC 62471-5:2015 Laser evaluation standard IEC60825-1: 2007, IEC60825-1: 2014, EN60825-1: 2014 Max. Output: 115W (8960WUSS/8960WSS) 95W (8951WUSS/8951WSS) Wave Length: 449 - 461nm LASER ENERGY – EXPOSURE NEAR APERTURE MAY CAUSE BURNS • 1:2014 and JIS C 6802:2014, and as a class 3R laser product that complies with IEC60825-1:2007.

  • Page 6: Disposal Of Old Equipment And Batteries Only For European Union And Countries With Recycling Systems

    Disposal of old equipment and batteries only for European Union and countries with recycling systems The above mark is in compliance with the Waste Electrical and Electronic Equipment Directive 2012/19/EU (WEEE). The mark indicates the requirement NOT to dispose the equipment including any spent or discarded batteries as unsorted municipal waste, but use the return and collection systems available.

  • Page 7: Contents Of Package

    Contents of package Your projector should come with the items shown below. Check that all the items are included. Contact your dealer immediately if any items are missing. Remote control with two AA batteries (2) Power cord (x2) MYBUTTON INPUT ASPECT PbyP AUTO...

  • Page 8: Preparing For The Remote Control

    Preparing for the remote control Insert the batteries into the remote control before using it. Use the appropriate AA carbon-zinc or alkaline batteries (non-rechargeable) in accordance with laws and regulations. If the remote control starts to malfunction, try to replace the batteries. If you will not use the remote control for long period, remove the batteries from the remote control and store them in a safe place.

  • Page 9: Arrangement

    Arrangement Refer to the table T-1 to T-2 in Supplement (at the end of this manual) to determine the screen size and projection distance. The values shown in the table are calculated for a full size screen. Tilt 360° (combination of horizontal and vertical) Horizontal 360°...

  • Page 10: Connecting With Your Devices

    Arrangement (continued) CAUTION Place the projector - Keep a space of 50 cm or more between a side of the projector and other objects such as walls. - Do not stop up, block nor cover the projector’s vent holes. so can cause the cooling fans inside the projector to malfunction.
  • Page 11 Connecting with your devices (continued) WARNING damage the projector and devices. projector’s manufacturer. It may be regulated under some standards. - Neither disassemble nor modify the projector and the accessories. - Do not use the damaged accessory. Be careful not to damage the accessories.

  • Page 12: Connecting To A Power Supply

    Connecting to a power supply Put the connector of the power cord into the POWER/STATUS1 indicator AC (AC inlet) of the product. Firmly plug the power cord’s plug into the outlet. In a couple of seconds after the power supply connection, the POWER/STATUS1 indicator lights up in steady orange.

  • Page 13: Turning On The Power

    Turning on the power POWER/STATUS1 indicator STANDBY/ON button correctly connected to the projector and the outlet. Make sure that the POWER/STATUS1 indicator is steady orange. Then remove the lens cover. Press the STANDBY/ON button on the projector or the remote control. The projection light source will light up, and the POWER/STATUS1 indicator will begin blinking in green.

  • Page 14: Adjusting The Projector's Elevator

    Adjusting the projector's elevator Lengthening or shortening the each elevator foot shifts the projection position and the projection angle. Turn the elevator foot to adjust its length. When the place to put the projector is slightly Front foot uneven to the left or right, use the rear elevator feet to place the projector horizontally.

  • Page 15: Displaying The Picture

    Displaying the picture STOPPER (8960WUSS/8951WSS only) Activate your signal source. Turn the FOCUS ring signal source on, and make it send the signal to the projector. ZOOM ring Use the VOLUME + / VOLUME - INPUT button buttons to adjust the volume. To turn off the sound, press the MUTE button on the remote control.

  • Page 16: Turning Off The Power

    Turning off the power Press the STANDBY/ON button on the projector POWER/STATUS1 indicator or the remote control. STANDBY/ON button The message “Power off?” appears on the screen for about 5 seconds. Press the STANDBY/ON button again while the message appears. The light source will go off, and the POWER/ STATUS1 indicator will begin blinking in orange.
  • Page 17 Turn the projector off, and unplug the power cord. Allow the projector to Filter cover Press up slightly the bottom side knobs to unlock the while holding it so it will not be sucked in. Filter cover knobs it with the new one. the following type number from your dealer when purchasing a new one.
  • Page 18 WARNING projector. d by dust and so malfunction to the projector. NOTE • Reset th • The projector may display the message such as the “CHECK THE AIR FLOW” or turn off the projector, to prevent the internal heat level rising.

  • Page 19: Inserting Or Replacing The Internal Clock Battery

    Inserting or replacing the internal clock battery This product has an internal clock. The battery for the internal clock is not contained at the time of factory shipment. When you use the function that requires "Event Scheduling" in the Network Guide), install a new the internal clock ( battery according to the following procedure.
  • Page 20 1,024,000 pixels (1280 horizontal x 800 vertical) Light source Laser diode Speaker 16 W mono 8960WUSS: 4.3A (AC 100V-120V), 2.1A (AC 220V-240V) 8951WUSS: 3.8A (AC 100V-120V), 1.9A (AC 220V-240V) Power supply/ 8960WSS: 4.1A (AC 100V-120V), 2.1A (AC 220V-240V) Rated current 8951WSS: 3.6A (AC 100V-120V), 1.8A (AC 220V-240V)
  • Page 21 Manufacturing year: 8 = 2018, 9 = 2019, 0 = 2020, ... Country of manufacture: China Note: The Dukane models described in this document are manufactured by Maxell and uses the same firmware, software programs, control code, and accessory parts. The equivalent Dukane to Maxell models are 8951WUSS (MP-WU5503), 8951WSS (MP-WX5503), 8960WUSS (MP-WX5603) and 8960WSS (MP-WX5603).

  • Page 22: End User License Agreement For The Product Software

    End user license agreement for the product software Software in the product consists of the plural number of independent software modules and there exist our copyright and/or third party copyrights for each of such software modules. The product also uses software modules that we have developed and/or produced.

  • Page 23: Troubleshooting - Warranty And After-Service

    • The manufacturer assumes no responsibility for any errors that may appear in this manual. • The reproduction, transfer or copy of all or any part of this document is not permitted without express written consent. DUKANE CORP AV SERVICE DEPT 2900 Dukane Drive St Charles, IL 60174 800-...
  • Page 24 Screen size and projection distance H x V : Screen a : Projection distance Projector top Projector bottom Elevator feet T-1: 8960WUSS/8951WUSS (1920 x 1200, ±10%) 16 : 10 16 : 9 4 : 3 Screen Size Projection distance Screen Size...
  • Page 25 Supplement - Connection Connection COMPUTER IN 2 HDBaseT MONITOR OUT WIRELESS COMPUTER IN 1 CONTROL AUDIO OUT AUDIO IN 1 HDMI 1 AUDIO IN3 R HDMI 2 AUDIO IN 2 AUDIO IN3 L VIDEO Computer AUDIO HDMI DISPLAY RS-232C...
  • Page 26 Supplement - Connection (continued) Access point Computer External device USB wireless RS-232C RS-232C adapter (optional) VCR/DVD/Blu-ray Disc player AUDIO COMPONENT HDMI VIDEO Cr/Pr Cb/Pb Y Speakers Monitor RGB IN...
  • Page 27 Supplement - Dimension Dimension 8960WUSS/8951WUSS [unit: mm] 8960WSS/8951WSS...
  • Page 28 Supplement - License agreement of each software License agreement of each software GNU GENERAL PUBLIC LICENSE Version 2, June 1991 Copyright © 1989, 1991 Free Software Foundation, Inc. 51 Franklin St, Fifth Floor, Boston, MA 02110-1301 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. Preamble (Hereinafter, translation is included without limitation in the The licenses for most software are designed to take away your...
  • Page 29 Supplement - License agreement of each software (continued) Program with the Program (or with a work based on the Program) conditions are imposed on you (whether by court order, on a volume of a storage or distribution medium does not bring agreement or otherwise) that contradict the conditions of this the other work under the scope of this License.
  • Page 30 Supplement - License agreement of each software (continued) DEFECTIVE, YOU ASSUME THE COST OF ALL NECESSARY Yoyodyne, Inc., hereby disclaims all copyright interest in the SERVICING, REPAIR OR CORRECTION. program `Gnomovision' (which makes passes at compilers) written by James Hacker. 12.
  • Page 31 Supplement - License agreement of each software (continued) GNU LESSER GENERAL PUBLIC LICENSE Version 2.1, February 1999 Copyright © 1991, 1999 Free Software Foundation, Inc. 51 Franklin St, Fifth Floor, Boston, MA 02110-1301 USA Everyone is permitted to copy and distribute verbatim copies of this license document, but changing it is not allowed. the version number 2.1.].
  • Page 32 Supplement - License agreement of each software (continued) you must do one of these things: 9. You are not required to accept this License, since you have not signed it. However, nothing else grants you permission to modify a) Accompany the work with the complete corresponding or distribute the Library or its derivative works.
  • Page 33 Supplement - License agreement of each software (continued) which is copyrighted by the Free Software Foundation, write to the redistribution under these terms (or, alternatively, under the terms Free Software Foundation; we sometimes make exceptions for of the ordinary General Public License). this.
  • Page 34 DUKANE CORP AV SERVICE DEPT 2900 Dukane Drive St Charles, IL 60174 800- 800-676-2487 / 630-762- Fax 630-584-5156 avservice@dukane.com www.dukaneav.com 8951WUSS-8960WUSS-8951WSS-8960WSS-Concise User Manual-00...
