Main controls and parts of the radio Operations Power on/off and volume adjustment Transmission Monitor Scan Voice announcement Squelch Keypad Beep Recharging the battery pack Battery save Adjusting the brightness of the hidden led display Firmware version indication Troubleshooting Technical specifications BR03 instruction guide...
The package includes • BR03 transceiver • Swivelling belt clip • Micro USB cable • Rechargeable Li-Ion battery pack 3.7V 2300mAh • Double desktop charger (to recharge tha radio+battery or the battery only) • Wall adaptor Main features • Compact radio with elegant design •...
12 Km. Maintenance Your BR03 was designed to fulfill any warranty obligations and to enjoy this product for many years. As for all the electronically devices, we recommend you to follow some suggestions: Do not attempt to open the unit.
Power/Volume knob: turn clockwise to power on and increase the volume level. Turn counter-clockwise to decrease the volume level and power off. BR03 instruction guide...
Page 8
12. Micro USB port: the radio’s battery can also be recharged via USB. Connect the USB cable supplied in the package into this port. 13. Li-Ion battery pack 3.7V 2300mAh BR03 instruction guide...
The Monitor feature is for temporarily excluding (opening) the Squelch, in order to listen to signals that are too weak to keep the Squelch perma- nently opened. Briefly press the Function key 1 to enable such function. BR03 instruction guide...
Pressing the PTT will stop the scan and the radio will transmit on the chan- nel in use. To start the scana gain, press the Function key 2. BR03 enables hands-free conversations through the VOX function: just speak in the direction of the microphone and the communication will be automatically activated.
The Squelch function suppresses noises on free channels and allows to receive even weak signals. BR03 has 10 different Squelch levels: 0 means that the Squelch is per- manently on; from level 1 to level 9 you will have different levels of noise reduction.
Keypad Beep With this function, BR03 emits an audio beep everytime a button is pres- sed. To activate/deactivate the keypad beep: Press the Function key 2. Push the Function key 1 for 5 times till the display will show and ).
Firmware version indication To show the firmware version of the radio follow this procedure: Press the the Function key 2. Premere the Function key 1 6 times. The firmware version will appear on the display. BR03 instruction guide | 11...
Move to another area. communicate with other from the party you are parties communicating with Check that the CTCSS tone or DCS code Incorrect CTCSS or corresponds to the one set by the parties you are communicating with. 12 | BR03 instruction guide...
Page 15
Logic related faults Incorrect setting caused (unreadable displayed Recharge the battery by a problem with the symbols, functions pack power supply. blocked, etc.) BR03 instruction guide | 13...
300Hz ÷ 3KHz Category Adjacent channel selectivity Within European legal terms Intermodulation rejection Within European legal terms Spurious emissions Within European legal terms Blocking Within European legal terms Specifications are subject to change without notice. 14 | BR03 instruction guide...
Page 18
If the product contains batteries: do not throw the battery into fire. To disperse after use, throw into the appropriate containers. Importado por: MIDLAND IBERIA, SA C/Cobalt, 48 - 08940 Cornellà de Llobregat (Barcelona - España) www.midland.es El uso de este equipo puede estar sujeto a la obtención de la correspondiente autorización administrativa.
