1.
INSTRUCTIONS FOR SAFE AND PROPER USE________________ 4
2.
INSTALLATION __________________________________________ 6
3.
DESCRIPTION OF CONTROLS _____________________________ 9
4.
USE OF THE OVEN ______________________________________ 14
5.
AVAILABLE ACCESSORIES _______________________________ 15
6.
COOKING HINTS ________________________________________ 16
7.
CLEANING AND MAINTENANCE ___________________________ 19
8.
EXTRAORDINARY MAINTENANCE _________________________ 21
INSTRUCTIONS FOR THE INSTALLER: these are intended for the
qualified technician who must install the appliance, set it functioning
and carry out an inspection test.
INSTRUCTIONS FOR THE USER: these contain user advice,
description of the commands and the correct procedures for cleaning
and maintenance of the appliance.
Contents
3
Advertisement
Related Manuals for Smeg SA301X
Summary of Contents for Smeg SA301X
-
Page 1: Table Of Contents
INSTRUCTIONS FOR SAFE AND PROPER USE________________ 4 INSTALLATION __________________________________________ 6 DESCRIPTION OF CONTROLS _____________________________ 9 USE OF THE OVEN ______________________________________ 14 AVAILABLE ACCESSORIES _______________________________ 15 COOKING HINTS ________________________________________ 16 CLEANING AND MAINTENANCE ___________________________ 19 EXTRAORDINARY MAINTENANCE _________________________ 21 INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualified technician who must install the appliance, set it functioning and carry out an inspection test. -
Page 2: Instructions For Safe And Proper Use
AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE OVEN. WE ADVISE CAREFUL READING OF THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE USING THE OVEN. INSTALLATION MUST BE CARRIED... - Page 3 THIS APPLIANCE IS DESIGNED FOR COOKING FOOD AND IT SHALL NOT BE USED AS A SPACE HEATER. THE OVEN IS DESIGNED FOR USE BY ADULTS. DO NOT ALLOW CHILDREN TO GO NEAR OR PLAY WITH IT. IT’S NOT INTENDED FOR USE BY YOUNG CHILDREN OR INFIRM PERSONS WITHOUT SUPERVISION.
-
Page 4: Installation
2.1 Electrical connection Check that mains voltage and power cable ratings are as per the indications provided on the label attached to the oven door frame. This label must never be removed. It is obligatory for the electrical system to be grounded according to the methods required by safety rules. - Page 5 Instructions for the installer 2.2 Mounting the oven The oven is designed for mounting into any piece of furniture as long as heat-resistant. Proceed according to the dimensions shown in Figures 1, 2 and 3. For installing under a work top, follow the dimensions given in Figure 1-3.
- Page 6 Instructions for the installer Never use the oven door to lever the oven into place when fitting. Avoid exerting too much pressure on the oven door when open.
-
Page 7: Description Of Controls
Instructions for the user 3. DESCRIPTION OF CONTROLS 3.1 Front control panel All the oven controls are grouped together on the front panel. FUNCTION SWITCH KNOB Rotate the knob in either direction to select desired function from the following: NO FUNCTION SET... - Page 8 240°C. TIMER KNOB (ONLY ON SOME MODELS) Lets you choose manual cooking or the timer with automatic turn-off of the oven when done. For manual control of cooking time, turn the knob anticlockwise to the symbol To set cooking time turn the knob clockwise.
- Page 9 Instructions for the user 3.2.1 Setting the time When the oven is used for the first time, or after a power blackout, the display flashes on and off at regular intervals. Press the seconds to stop the display flashing and start setting of the current time.
- Page 10 When the end of the cooking time is reached, the timer will switch off the oven heating elements, the beeps will start and the numbers on the dial will flash. The cooking time can also be reset by deleting the program set;...
- Page 11 When the end of the cooking time is reached, the timer will switch off the oven heating elements, the beeps will start and the numbers on the dial will flash. To reset the entire program set, keep the central key...
-
Page 12: Use Of The Oven
During cooking, do not cover the bottom of the oven with aluminium or tin foil and do not place pans or oven trays on it as this may damage the enamel coating. If you wish to use greaseproof paper, place it so that it will not interfere with the hot air circulation inside the oven. -
Page 13: Available Accessories
Instructions for the user 5. AVAILABLE ACCESSORIES The oven features 4 support positions for plates and racks of different height. Some models do not feature all accessories. Grill: useful for holding cooking vessels. Plate grill: for placing above plate for cooking foods that might drip. -
Page 14: Cooking Hints
Place the food in the oven only after the thermostat indicator light has turned off. very fatty meats may be put in when the oven is still cold. Put frozen meat in immediately, without waiting for it to thaw. The only precaution you need to take is to set the temperature about 20°C lower and cooking time... - Page 15 This system is suitable for cooking on several levels, including different types of food (fish, meat etc.), without the tastes and smells mingling. Air circulation in the oven ensures a uniform distribution of heat. Pre-heating is not necessary. Multiple cooking is possible as long as the cooking temperature of the different foods is the same.
- Page 16 Ensures uniform heat distribution with greater heat penetration into the food. Food will be lightly browned on the outside and remain soft inside. Keep the oven door closed during cooking. Heating up time must not exceed 60 minutes. 6.5 Defrosting...
-
Page 17: Cleaning And Maintenance
Rinse thoroughly and dry with a soft cloth or deerskin. Do not allow residues of sugary foods (such as jam) to set inside the oven. If left to set for too long, they might damage the enamel lining of the oven. - Page 18 Rinse and dry. If there are still stains or drops, place a damp ammoniac-soaked cloth on the bottom of the oven, close the door and after a few hours wash the oven with hot water and liquid detergent. Rinse and dry.
-
Page 19: Extraordinary Maintenance
In case of tough spots, clean with a damp sponge using regular detergent. 8. EXTRAORDINARY MAINTENANCE The oven may require extraordinary maintenance or replacement of parts subject to wear such as seals, bulbs, and so on. The following instructions describe how to carry out these minor maintenance operations. - Page 20 B. Lift up the door forming an angle of about 45° and remove. To refit, slide the hinges A into slots in oven frame. Locate the grooves (C) over frame of oven in hinge cut out, lower the door and release the locking levers (B).
