Si00-876
Step
2. Remove the stop valve
cover.
1
Remove the screw of
the stop valve cover.
Pull the stop valve
2
cover downward to
unfasten the hooks and
remove it.
Removal Procedure
Procedure
Removal of Outer Panels
Stop valve cover
(R5252)
(R16679)
The stop valve cover has 6
hooks.
(R16680)
Points
5
