- Page 1 Express Business Park, Shipton Way Rushden, NN10 6GL, United Kingdom +44 (0) 1933 35 2000 +44 (0) 1933 31 2000 fax © 2006 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. 5-Port Gigabit Switch 8-Port Gigabit Switch Belkin Ltd.
-
Page 2: User Manual
Share large files at faster network speeds, with maximum efficiency User Manual 5-Port Gigabit Switch 8-Port Gigabit Switch ����� ������� �� ��������� F5D5141-5 F5D5141-8... -
Page 3: Table Of Contents
5 Placement of the Switch ........ -
Page 4: Introduction
Compatible with existing 10/100 networks and major operating systems, your 5- or 8-Port Gigabit Switch from Belkin delivers error- free transfers at maximum networks speeds. -
Page 5: Features
Introduction Introduction Features High-speed, dedicated 10/100/1000 Ethernet ports • 5 ports (Belkin 5-Port Gigabit Switch F5D5141-5) • 8 ports (Belkin 8-Port Gigabit Switch F5D5141-8) Standards • IEEE 802.3 z/ab 1000Base-T • IEEE 802.3u 100Base-Tx • IEEE 802.3 10Base-T 1U chassis, place on your desk or mount on a wall... -
Page 6: Getting To Know Your Switch
Getting to Know your Switch Front-Panel LEDs Belkin 5- or 8-Port Gigabit Switches feature two rows of LEDs that provide information about connection speed and activity, plus a separate Power LED. (a) Power (POWER) LED • Green – Switch is operating normally •... -
Page 7: Connecting Networking Devices To Your Switch
10Base-T, 100Base-Tx, and 1000Base-T network devices. Connect the power adapter cord into the power adapter socket in the rear of the Switch; now plug the adapter into a power source (wall jack or power strip). -
Page 8: Connecting Networking Devices To Your Switch
(wall jack or power strip). Power down all your computers. Connect a Category 5e or 6 Ethernet cable between each computer’s NIC and one of the numbered ports on the rear of the Switch. Power up all your computers connected to your Belkin Switch. - Page 9 Connecting your Switch to another Switch Connect a Category 5e or 6 cable between one of the numbered ports on the front of the Switch and one of the numbered ports on the other Switch to which you are cascading or connecting.
-
Page 10: Applications
This scheme ensures data integrity and provides a clean data stream. Sample Application – This Switch is designed to operate as a small workgroup switch. It can provide 10-, 100-, or 1000Mbps connections to workstations, or 1000Mbps full-duplex links to high-speed servers. It can also provide... -
Page 11: Placement Of The Switch
Placement on a Flat Surface Affix the four rubber feet shipped with the Switch on the bottom of the Switch in the area that is clearly marked on each of the four corners. Make sure the Switch is placed in an area that allows for proper ventilation. -
Page 12: Product Specifications
FCC Class B, CISPR Class B, EN 61000-3-2/3 CSA/CUS (CSA 60950-1 & UL 60950-1) TÜV/GS (EN 60950-1) CB (IEC 60950-1) F5D5141-5: 5.15 x 3.38 x 1.26 in. (13 x 8.56 x 3.19cm) F5D5141-8: 6.9 x 3.4 x 1.3 in. (17.46 x 8.6 x 3.29cm) -
Page 13: Switching Criteria
Product Specifications Switching Criteria Network Bridging Function Switching Method MAC Address Table Packet Buffer Filtering, forwarding, and learning Store-and-forward F5D5141-5: 8K entries F5D5141-8: 8K entries F5D5141-5: 80Kbits F5D5141-8: 128Kbits... -
Page 14: Troubleshooting
Probable Causes Switch port, network card, or cable may be defective. Possible Solutions • Check that the Switch and attached device are both powered on. • Be sure the network cable is connected to both devices. • Verify that Category 5 or better cable is used for 10/100Mbps connections;... -
Page 15: Power And Cooling Problems
877-736-5771. Technical support is available 24 hours a day, 7 days a week. Before you Call If possible, turn on your system before you call Belkin for technical assistance and call from a telephone at or near the computer. You may be asked to describe detailed information... -
Page 16: Information
Information EMI Certification FCC Class B Certification (USA) Warning: This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for a Class B digital device pursuant to Subpart B of Part 15 of FCC Rules, which are designed to provide reasonable protection against such interference when operated in a commercial environment. - Page 17 Information Information Immunity: • Product family standard according to EN 55024:1998 • Electrostatic Discharge according to EN 61000-4-2:1995 (Contact Discharge: ±4kV, Air Discharge: ±8kV) • Radio-frequency electromagnetic field according to EN 61000-4- 3:1996 (80–1000MHz with 1kHz AM 80% Modulation: 3V/m) •...
- Page 18 Information Safety Compliance Please read the following safety information carefully before installing the Switch: Warning: Do not plug a phone-jack connector into the RJ45 port. This may damage this device. Warning: This product does not contain any serviceable user parts.
- Page 19 (except for shipping charges for the product). What is not covered by this warranty? All above warranties are null and void if the Belkin product is not provided to Belkin Corporation for inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin Corporation determines that the Belkin product has been improperly installed, altered in any way, or tampered with.
- Page 20 Belkin Corporation reserves the right to review the damaged Belkin product. All costs of shipping the Belkin product to Belkin Corporation for inspection shall be borne solely by the purchaser. If Belkin determines, in its sole discretion, that it is impractical to ship the damaged equipment to Belkin Corporation, Belkin may designate, in its sole discretion, an equipment repair facility to inspect and estimate the cost to repair such equipment.
