e
Remove the embossing tool holder cap.
Select the embossing tool according to the line thickness
that you want to emboss, and then insert the embossing
tool into the embossing tool holder so that on the tool
aligns with on the holder. After securing the holder
cap, insert the holder into the cartridge.
• Before inserting the holder into the cartridge, check if the tool
moves up and down in the holder. If the tool moves, remove
the cap, and then attach it again.
f
Select "Emboss" on the preview screen.
g
Touch
, and then specify the setting for "Emboss
Pressure".
• The recommended embossing pressure differs depending on
the material and embossing tool diameter. Refer to the
following table when adjusting the setting.
Material
Thickness
Paper (thick)
0.25 mm
-
Metal sheets
Paper (thin)
0.1 mm
• This table of values provides general guidelines. Before making
your project, perform trial embossing with the same material.
Embossing Pressure
1.5 mm tool
3 mm tool
4
4
0
0
-6
-4
4
