THESE INSTRUCTIONS ARE VALID ONLY FOR END USER COUNTRIES WHOSE
IDENTIFICATION SYMBOLS APPEAR ON THE COVER OF THIS MANUAL.
INSTRUCTIONS FOR THE INSTALLER: these are for the qualified
technician who must carry out a suitable check of the gas system,
install the appliance, set it functioning and carry out an inspection test.
INSTRUCTIONS FOR THE USER: these contain user advice,
description of the commands and the correct procedures for cleaning
and maintenance of the appliance.
Contents
3

Advertisement

Table of Contents
loading

Related Manuals for Smeg A2EA

Summary of Contents for Smeg A2EA

  • Page 1: Table Of Contents

    INSTRUCTIONS FOR SAFE AND PROPER USE________________ 4 INSTALLATION OF THE APPLIANCE_________________________ 6 ADAPTATION TO DIFFERENT TYPES OF GAS ________________ 9 FINAL OPERATIONS _____________________________________ 11 DESCRIPTION OF CONTROLS ____________________________ 13 USE OF THE COOKING HOB ______________________________ 18 USE OF THE OVENS_____________________________________ 19 AVAILABLE ACCESSORIES _______________________________ 21 COOKING HINTS ________________________________________ 22 CLEANING AND MAINTENANCE ___________________________ 28...

  • Page 2: Instructions For Safe And Proper Use

    Introduction 1. INSTRUCTIONS FOR SAFE AND PROPER USE THIS MANUAL IS AN INTEGRAL PART OF THE APPLIANCE AND THEREFORE MUST BE KEPT IN ITS ENTIRETY AND IN AN ACCESSIBLE PLACE FOR THE WHOLE WORKING LIFE OF THE COOKER. WE ADVISE READING THIS MANUAL AND ALL THE INSTRUCTIONS THEREIN BEFORE USING THE COOKER.
  • Page 3 Introduction THE I.D. PLATE WITH TECHNICAL DATA, REGISTRATION NUMBER AND BRAND NAME IS POSITIONED VISIBLY IN THE STORAGE COMPARTMENT. THE PLATE MUST NOT BE REMOVED. DO NOT INSTALL THIS APPLIANCE ON A RAISED PLATFORM. DURING USE THE APPLIANCE BECOMES VERY HOT. TAKE CARE NOT TO TOUCH THE HEATING ELEMENTS INSIDE THE OVEN.

  • Page 4: Installation Of The Appliance

    Instructions for the installer 2. INSTALLATION OF THE APPLIANCE It is the law that all gas appliances are installed by competent persons. Corgi gas installers are approved to work to safe and satisfactory standards. All gas installation, servicing and repair work must be in accordance with the gas safety regulations 1984 (installation and use) as amended 1990.

  • Page 5: Ventilation Requirements

    Instructions for the installer For operation on 380-415V3N H05RR-F-type five-core cable (5 x 1.5 mm For operation on 380-415V2N H05RR-F-type four-core cable (4 x 1.5 mm For operation on 220-240V H05RR-F-type three-core cable (3 x 2.5 mm The cable end to be connected to the appliance must be provided with an ground wire (yellow-green) at least 20 mm longer.
  • Page 6 Instructions for the installer 2.3 Connecting to natural and LPG gas diagram) Make the connection to the appliance using flexible bayonet style hose in accordance to B.S. 669. The hose connection at the rear of the appliance has a 1/2" BSP internal thread. Please use seal C between the flexible connection L and the appliance supply tube B.

  • Page 7: Adaptation To Different Types Of Gas

    Instructions for the installer 3. ADAPTATION TO DIFFERENT TYPES OF GAS Before performing any cleaning or maintenance work, detach the appliance from the electrical socket. The cooker hob is set for natural gas G20 (2H) at a pressure of 20 mbar. In the case of functioning with other types of gas the burner nozzles must be changed and the minimum flame adjusted on the gas taps.

  • Page 8: Burner And Nozzle Characteristics Table

    Instructions for the installer 3.2 Burner and nozzle characteristics table Rated Burner heating capacity (kW) 1.05 Auxiliary Semi rapid Rapid Triple crown Rated heating Burner capacity (kW) Auxiliary 1.05 Semi rapid Rapid Triple crown 3.3 Arrangement of burners on cooking hob LPG –...

  • Page 9: Final Operations

    Instructions for the installer 4. FINAL OPERATIONS After replacing the nozzles, reposition the flame-spreader crowns, the burner caps and the grids. After adjustment to a different kind of gas from the one for which the cooker has been tested, replace the plate inside the storage compartment with one corresponding to the new kind of gas.
  • Page 10 Instructions for the installer Mounting the rear top upstand • Position the upstand above the top, taking care to align holes A with holes B. • Secure the upstand to the top by tightening screws C.

  • Page 11: Description Of Controls

    Instructions for the user 5. DESCRIPTION OF CONTROLS 5.1 Front control panel All the cooker controls and commands are on the front panel. Before using the main oven check that the electronic programmer is showing the symbol (see paragraph “5.2.1 Clock adjustment”). DESCRIPTION OF SYMBOLS BACK LEFT BURNER FRONT LEFT BURNER...
  • Page 12 Instructions for the user AUXILIARY OVEN THERMOSTAT KNOB Selection of cooking temperature is carried out by turning the knob clockwise to the required temperature, between 50° and 220°C. The tell-tale light comes on to indicate that the oven is warming up. When it goes out it means that the required temperature has been reached.
  • Page 13 Instructions for the user 5.2 Electronic Programmer The programmer user instructions are valid only for the main oven. LIST OF FUNCTIONS MINUTE-COUNTER KEY COOKING TIME KEY END-OF-COOKING KEY DECREASE TIME KEY INCREASE TIME KEY 5.2.1 Clock adjustment When using the oven for the first time, or after a power failure, the display flashes regularly and indicates same time the keys minute either up or down.
  • Page 14 Instructions for the user 5.2.2 Semiautomatic cooking Use this setting for automatic oven switch-off at the end of cooking time. By pressing key pressed and at the same time, press keys time. Release key will now show the right time together with symbols A and 5.2.3 Automatic cooking Use this setting to automatically start and stop the oven.
  • Page 15 Instructions for the user 5.2.5 Adjusting alarm volume The acoustic alarm has three different settings. These can be operated, while the alarm is sounding, by pressing key 5.2.6 Switching off the alarm The alarm switches off automatically after seven minutes. They can be manually de-activated by pressing the keys 5.2.7 Minute Counter The programmer can also be used as a simple minute counter.

  • Page 16: Use Of The Cooking Hob

    Instructions for the user 6. USE OF THE COOKING HOB 6.1 Lighting of the cooking hob burners Before lighting the hob burners check that the flame caps are in the correct position and that their burner caps are in place, making sure that the holes A in the flame caps correspond to the spark plugs and thermocouples.

  • Page 17: Use Of The Ovens

    Instructions for the user 7. USE OF THE OVENS 7.1 Warnings and general advice Before using the oven for the first time, pre-heat it to maximum temperature (250°C) long enough to burn any manufacturing oily residues which could give the food a bad taste. Before using the oven for the first time, pre-heat it to maximum temperature (250°C) long enough to burn any manufacturing oily residues which could give the food a bad taste.
  • Page 18 Instructions for the user 7.4 Storage compartment The storage drawer is at the bottom of the cooker, underneath the oven. For access, pull the bottom of the door. Never store inflammable materials such as rags, paper or the like. The compartment is intended only holding...

  • Page 19: Available Accessories

    Instructions for the user 8. AVAILABLE ACCESSORIES The oven features 4 support positions for plates and racks of different height. Oven grill: for cooking food on plates, small cakes, roasts or food requiring light grilling. Plate grill: for placing above plate for cooking foods that might drip.

  • Page 20: Cooking Hints

    Instructions for the user 9. COOKING HINTS In fan-assisted mode preheating should be carried out at 30/40°C above the cooking temperature. This considerably shortens cooking times and reduces power consumption, as well as giving better cooking results. Keep the oven door closed during cooking 9.1 Traditional cooking (main and auxiliary ovens) FUNCTION SWITCH THERMOSTAT SELECTOR SWITCH FROM...
  • Page 21 Instructions for the user 9.2 Hot-air cooking (main oven) FUNCTION SWITCH THERMOSTAT SELECTOR SWITCH FROM 50° TO 250°C This system is suitable for cooking on several levels, including different types of food (fish, meat etc.), without the tastes and smells mingling. Air circulation in the oven ensures a uniform distribution of heat.
  • Page 22 Instructions for the user 9.4 Hot-air grilling (main oven) FUNCTION SWITCH THERMOSTAT SWITCH FROM 50° TO 200°C Ensures uniform heat distribution with greater heat penetration into the food. Food will be lightly browned on the outside and remain soft inside. Keep the oven door closed during cooking.
  • Page 23 Instructions for the user 9.6 Defrosting (main oven) FUNCTION SWITCH THERMOSTAT SWITCH IN POSITION 0 The flow of air produced by the fan ensures quicker defrosting. The air circulating inside the oven is at room temperature. The advantage of defrosting at room temperature is that it does not alter the taste and appearance of the food.

  • Page 24: Traditional Cooking

    Instructions for the user 9.7 Recommended cooking table Cooking times, especially meat, vary according to the thickness and quality of the food and to consumer taste. FIRST COURSES LASAGNE OVEN-BAKED PASTA MEAT ROAST VEAL ROAST BEEF ROAST PORK CHICKEN DUCK GOOSE - TURKEY RABBIT LEG OF LAMB...
  • Page 25 Instructions for the user FIRST COURSES LASAGNE OVEN-BAKED PASTA CREOLE RICE MEAT ROAST VEAL ROAST PORK ROASTED BEEF FILLET OF BEEF ROAST LAMB ROAST BEEF ROAST CHICKEN ROAST DUCK ROAST TURKEY ROAST RABBIT ROAST HARE ROAST PIGEON FISH PIZZA DESSERTS (PASTRIES) CIAMBELLA FRUIT CAKE SPONGE-CAKE...

  • Page 26: Cleaning And Maintenance

    Instructions for the user CLEANING AND MAINTENANCE 10.1 Cleaning stainless steel Before performing any operations requiring access to powered parts, switch off the power supply to the machine. To keep stainless steel in good condition it should be cleaned regularly after use.
  • Page 27 Instructions for the user 10.2.2 Burner caps, flame cap crowns and burners To facilitate cleaning, caps, flame cap crowns, and burners are all removable. To remove the flame separating crown of the fish hob, loosen the two screws exposed after having removed the cap. Wash all parts with warm water and non-abrasive detergent taking care to remove all tough spots.
  • Page 28 Instructions for the user For easier cleaning, the storage drawer underneath the oven can be completely removed. Pull it right out and raise the front (as for an ordinary drawer). 10.3.1 Assembling the self-cleaning liners Remove all accessories from the oven; Remove the side grilles (fig.1);...

  • Page 29: Extraordinary Maintenance

    Instructions for the user 11. EXTRAORDINARY MAINTENANCE Ovens periodically require replacement of parts subject to wear and tear such as gaskets, electric bulbs etc. Specific instructions for each intervention of this type appear below. Before performing any operations requiring access to powered parts, switch off the power supply to the machine.
  • Page 30 Instructions for the user 11.2 Removing the door Open the door completely and fit the pins (supplied) into the holes from the inside. Close the door to an angle of about 45°, lift it and remove it from its seat. To replace, fit the hinges into the grooves provided, then lower the door until it comes to rest and extract the pins.
  • Page 32 914773043/ A...
