DLP PROJECTOR
SERVICE MANUAL
CHASSIS : RE-058A
MODEL : AN110B AN110W
MODEL :
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
AN110B-JD AN110W-JD
website:http://biz.LGservice.com
e-mail:http://www.LGEservice.com/techsup.html

Advertisement

Table of Contents
loading

Summary of Contents for LG AN110B

  • Page 1 DLP PROJECTOR SERVICE MANUAL CHASSIS : RE-058A MODEL : AN110B AN110W MODEL : AN110B-JD AN110W-JD CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
  • Page 2: Table Of Contents

    CONTENTS CONTENTS ........................2 SAFETY PRECAUTIONS ....................3 CONTROL DESCRIPTIONS .....................4 REPLACING OF LAMP ....................9 SPECIFICATIONS ......................11 ADJUSTMENT INSTRUCTION..................13 BLOCK DIAGRAM......................17 EXPLODED VIEW......................18 EXPLODED VIEW PARTS LIST ..................19 REPLACEMENT PARTS LIST..................20 SVC. SHEET ........................PRINTED CIRCUIT BOARD ....................- 2 -...
  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS IMPORT ANT SAFETY NOTICE Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.
  • Page 4: Control Descriptions

    CONTROL DESCRIPTIONS Part Descriptions Main Body * The projector is manufactured using high-precision technology. You may, however, see on the Projector screen tiny black points and/or bright points (red, blue, or green). This can be a normal result of the manufacturing process and does not always indicate a malfunction.
  • Page 5 Control Panel MENU Button SOURCE Button OK Button FOCUS +/- Button ZOOM +/- Button POWER Button - 5 -...
  • Page 6 Remote Control POWER POWER Button AUTO SOURCE AUTO Button (Refer to p.34) SOURCE Button Button Button STILL Button (Refer to p.33) MENU Button STILL MENU ARC Button (Refer to p.29) BLANK Button (Refer to p.31) OK Button BLANK KEYSTONE +/- Button (Refer to p.31) ZOOM +/- Button (Refer to p.21) KEYSTONE FOCUS...
  • Page 7 Projector Status Indicators * Lamp Indicator, operation indicator and temperature indicator at the top of the projector show the user the operating status of the projector. Operation Indicator Lamp Indicator Temperature Indicator Orange Standby. Lamp cooling until the lamp turn on. Green(flashing) On operation.
  • Page 8 Accessories POWER AUTO SOURCE STILL MENU BLANK KEYSTONE FOCUS ZOOM LIGHT 1.5V 2 Batteries (size AAA) Remote Control Power Cord Video Cable Wall mounting bracket Operating guide Computer Cable RCA to D-Sub Adaptor * Bolt and anchor are included in the wall bracket.
  • Page 9: Replacing Of Lamp

    - Never touch the lamp unit glass or otherwise image quality may be worse or lamp life may be reduced. To obtain a replacement Lamp unit Lamp model number is on page 47. Check the lamp model and then purchase it at LG Electronics Service Center. Using other lamp may cause damage to the projector.
  • Page 10 Replacing the Lamp Turn off the projector and unplug the power cable. Remove the two retaining screws on the lamp Carefully place the lens side down on a cover with a screwdriver or similar objects and then cushioned surface that will protect the lens lift off the lamp cover.
  • Page 11: Specifications

    NOTE : Specifications and others are subject to change without notice for improvement. Scope This standard can be applied to the DLP Projector(chassis : RE-058A) related to AN110B/W-JD Model. Test Condition 1) Temperature : 25°C ± 5°C (Only CST is 40°C ± 2°C ) 2) Relative Humidity: 65 ±...
  • Page 12 Feature and function Specification Item Remark Unit REMOCON NEC Code DVI Input Digital RGB DVI-D RGB Input Separate D-Sub 15 pin Component input Y, P D-Sub 15 pin 480i, 480p, 720p, 1080i, 576i,576p Composite input 480i, 576i RCA jack(Yellow) S-video input 480i,576i S-VIDEO jack RS232C Port...
  • Page 13: Adjustment Instruction

    ADJUSTMENT INSTRUCTION 1. Application Object Top and bottom adjustment screw A This instruction is for the application to the DLP Projector (Chassis : RE-058A). 2. Notes Left and right adjustment screw C (1) The power source insulation of this DLP Projector is not charging type and you may not use the transformer for Left and right adjustment screw B...
  • Page 14 (4) Final Adjustment Fix the adjustment screw in position. (1), (2), (3) adjustment twice and find the optimum position. Check the image with the naked eye for optimum alignment. Step 1 Step 2 Step 3 <Fig.5> Illuminator Left/Right Adjustment Sequence 2 4-2.
  • Page 15 5. Caution for DMD 7. Component Gain/Offset adjustment (Digital Micro-mirror Device) 7-1. Required Test Equipment 5-1. Caution for DMD ESD (1) PC Pattern Generator 1EA (2) Remote control for user 1EA (1) Use proper grounding to prevent a damage of ESD (3) Remote control for adjustment 1EA (Electrostatic Discharge) when handing the DMD.
  • Page 16 9. CWI/White Balance Measurement (3) X coordinates usually get maximum value at X=0.637±0.02 and Y coordinates usually get minimum Condition value at Y=0.350±0.02. Adjust this value by pressing (1) CWI and White Balance is adjusted using the volume button on the remote control. Adjustment range is measurement of color coordinate.
  • Page 17: Block Diagram

    BLOCK DIAGRAM - 17 -...
  • Page 18: Exploded View

    EXPLODED VIEW - 18 -...
  • Page 19: Exploded View Parts List

    EXPLODED VIEW PARTS LIST Part No. Description 3110V00921A CASE BOTTOM RD-JS10 MG . 35509K0189A COVERAN110-JD REAR MG ASSY 0IZZ9G0001A IC,DRAWING X1276-6007 TEXAS INSTRUMENTS CLGA 205PIN DMD TRAY 0.65INCH 720P WXGA 4810V01235C BRACKET, COVER RD-JS10 RE058A MG EXIT 4980V01097H SUPPORTER, GUIDE BRASS 36.9 6871VSMZZHD PWB(PCB) ASSEMBLY,SUB DMD RE058A HAND INSERTION B AN110-JD - REV D 3300V00354B...
  • Page 20: Replacement Parts List

    CHIP 2SC3875S(ALY) BK KEC IC470 0IPMGSG018D LD1086DT18TR-LF 3P,DPAK R/TP Q557 0TR102009AJ KRC102S KEC REEL TAPING SOT23 50V 0.1A IC471 0ICTMLG018B LGDP4411 IEP2 LG IC 208P LQFP Q800 0TR387500AA CHIP 2SC3875S(ALY) BK KEC IC500 0IMCRTI011A 2503227-001(DDP1010) 529P EPBGA Q801 0TR387500AA CHIP 2SC3875S(ALY) BK KEC...
  • Page 21 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 22 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 23 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 24 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 25 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 26 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 27 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 28 LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION 6410VHH001B POWER CORD, SP502B+IS-034 3ASL/75 FILTER & CRYSTAL 6850F00005A CABLE,D-SUB TO RCA UL1354 AWG28 100MM L101 0LCML00003B MLB-201209-0120P-N2 5A 6852TAZ006Z CORD,A/V RCA 3000MM 1P UL2863AWG26 L201 6210TCE001A HB-1S2012-080JT CERATEC 2012MM 6866VA9001A CONNECTOR (CIRC),D-SUB 2990-9C AT L202...
  • Page 32 PRINTED CIRCUIT BOARD MAIN(TOP) DMD(TOP) KEYPAD(TOP) KEYPAD(BOTTOM) DMD(BOTTOM) SENSOR1 AV-JACK(TOP) RS-232C(TOP) SENSOR2 RS-232C(BOTTOM) AV-JACK(BOTTOM) MAIN(BOTTOM)
  • Page 33 Sep., 2005 P/NO : 3828VD0085Y Printed in Korea...
