Page 13: Introduction
Introduction Whether the Accu-Chek Aviva Combo meter is your first blood glucose meter or you have used a meter for some time, please take the time to read the Getting Started Guide, the Standard Owner’s Booklet, and the Advanced Owner’s Booklet carefully before you use your new meter. To use it correctly and dependably, you need to understand its operation, screen displays, and all individual features.
Page 14 This booklet includes information about: • Understanding your new Accu-Chek Aviva Combo system • Testing your blood glucose • Control testing • Managing your data • Changing the meter settings • Understanding the icons, reminders, warnings, and errors • Care and maintenance •...
Page 15: The Accu-Chek Aviva Combo System
The Accu‑Chek Aviva Combo System The Accu-Chek Aviva Combo meter is for quantitative blood glucose testing using Accu-Chek Aviva test strips. The meter has many features including: • Controlling your Accu-Chek Spirit Combo pump • Administering a bolus • Bolus advice •...
Page 16 NOTE Blood glucose and bG are interchangeable and mean the same thing. 53895_00048010161_E.indb 10 9/4/15 9:34 AM...
Page 17 The Accu-Chek Aviva Combo blood glucose monitoring system is intended for the quantitative measurement of blood glucose. The Accu-Chek Aviva Combo system is intended for self-testing outside the body (in vitro diagnostic use) by people with diabetes and/or by professionals in a clinical setting as an aid to effective diabetes management.
Page 18 wWARNING • Any object coming into contact with human blood is a potential source of infection (see: Clinical and Laboratory Standards Institute: Protection of Laboratory Workers from Occupationally Acquired Infections; Approved Guideline – Third Edition; CLSI document M29-A3, 2005). • Choking hazard. Small parts. Keep away from children under the age of 3 years. 53895_00048010161_E.indb 12 9/4/15 9:34 AM...
Page 19 (in vitro) use. It should not be used to diagnose diabetes. • This meter requires Accu-Chek Aviva test strips. Other test strips will give inaccurate results. • The meter comes with the time and date preset. You may need to change the time to your time zone.
Page 20 53895_00048010161_E.indb 14 9/4/15 9:34 AM...
Page 21: Understanding Your New System
Understanding Your New System 1.1 Overview 1.2 The Accu-Chek Aviva Combo Meter at a Glance 1.3 The Accu-Chek Spirit Combo Insulin Pump at a Glance 1.4 Summary of Features 1.5 Screen Content and Navigation 53895_00048010161_E.indb 15 9/4/15 9:34 AM...
Page 22: Overview
NOTE • This booklet shows sample screens. The screens in this booklet may look slightly different from the screens on the meter. If you have any questions about the meter screens, contact Accu-Chek Customer Care at 1-800-688-4578. • On the meter display, the activation chip is referred to as a code key. Code key and activation chip are interchangeable and mean the same thing.
Page 23: The Accu-Chek Aviva Combo Meter At A Glance
1.2 The Accu‑Chek Aviva Combo Meter at a Glance 1. Display Shows menus, results, messages, and data stored in the diary 2. Left/Right Soft Keys Press to select the menu or option above the key 3. Buttons Press to enter menus or the diary,...
Page 24 7. Infrared (IR) Window Transfers data from the meter to a computer 8. Activation Chip Slot Activation chip is pre-inserted here 9. Battery Door Remove the battery door by pushing the tab and pulling up the door 53895_00048010161_E.indb 18 9/4/15 9:34 AM...
Page 25 10. Batteries Insert batteries according to the + and - symbols in the battery compartment. 11. Control Solution Bottle (for example) 12. Test Strip Container (for example) 13. Test Strip Insert this end of the test strip into the meter. 14.
Page 26 15. Top View Infrared (IR) Window 16. Activation Chip (for example) 17. Side View Pre-inserted activation chip NOTE Your meter is already coded and comes with a pre-inserted black activation chip that you never need to change. Even if you use test strips from boxes that contain another activation chip that is a different color or has different numbers, you never need to change the black activation chip again.
Page 27 The meter has seven buttons and two soft keys. 1. Left Soft Key 2. Up Arrow 3. Left Arrow 4. Down Arrow 5. Power On/Off 6. Right Soft Key 7. Right Arrow 8. Enter 9. Backlight NOTE • You hear a sound every time an active button/soft key is pressed unless you turned off the key sound. •...
Page 28 Table of Buttons and Soft Keys Button Name Function Left Arrow Move or scroll to the left in a screen. Right Arrow Move or scroll to the right in a screen. Up Arrow Move or scroll up in a screen. Down Arrow Move or scroll down in a screen.
Page 29 Button Name Function • Select a menu or option. Enter • Save changes and exit the entry fi eld. • Adjust the backlight level (low, medium, high). • Turn Bluetooth Backlight ® wireless technology on and off (press and hold in the BLUETOOTH screen).
Page 30 Table of Button Combinations Button Combination Name Function When the buttons are locked, press Unlock Keys Unlock the buttons. and hold until the Main Menu appears. With the meter turned off, press Meter/Pump Pairing Begin meter and pump pairing. and hold and then press 53895_00048010161_E.indb 24 9/4/15 9:34 AM...
Page 31: The Accu-Chek Spirit Combo Insulin Pump At A Glance
1.3 The Accu‑Chek Spirit Combo Insulin Pump at a Glance 1. Menu Key Cycles through menus, functions, and information screens 2. OK Key Selects current settings displayed on screen, saves changes, exits a screen, and allows the user to view the QUICK INFO screen 3.
Page 32 5. Adapter Connects the cartridge to the infusion set 6. Up Key Moves forward in an information screen, increases a setting, turns on the backlight, programs a Quick Bolus, cancels a Quick Bolus, and turns off the STOP-Warning 7. Down Key Moves backward in an information screen, decreases a setting, programs a Quick Bolus, cancels a Quick Bolus, and turns off the...
Page 33: Summary Of Features
1.4 Summary of Features Display The meter has a full-color graphic LCD (Liquid Crystal Display) that displays current and historical information. Backlight • The backlight helps you read the information on the meter display under different lighting conditions. • When the meter is turned on, the backlight is set to the medium level. •...
Page 34 Key Lock • The key lock feature allows you to lock all of the buttons on the meter, except for the power on/off button. • The key lock serves as a safety measure against unintentional activation of meter functions. • For more information, see Chapter 5, Changing Meter Settings. Signal Settings •...
Page 35 Bolus Advice (Optional) • The term “bolus” refers to the delivery of insulin all at once rather than slowly throughout the day, usually used to compensate for meals or high blood glucose. • Bolus advice calculates a bolus for you that is adapted to the time of day and your changing situations. •...
Page 36 Using the Meter with the Pump • The meter can communicate with and remotely control your pump. • Pump information is automatically downloaded to the meter when Bluetooth wireless technology is activated. • The meter must be paired with the pump. •...
Page 37 My Data • Your new meter stores 1,000 records in the diary. • You can view, modify, or add information to your diary. • You can view blood glucose test averages, trends, standard day, standard week, and target tables and graphs of the data in the diary.
Page 38 Warning Limits for Hyper and Hypo Blood Glucose Levels • You can select hyper (high) and hypo (low) blood glucose limits that best fit your needs. Whenever a blood glucose result is above or below this range, the meter displays a warning. •...
Page 39 Without bolus advice, you need to consider the following when setting up time blocks: • Determine the appropriate time range by reviewing the end time for each time block. • Review the acceptable blood glucose target range (low and high) for each time block. With bolus advice, you need to consider the following when setting up time blocks: •...
Page 40 Health Events Health events can be selected to indicate how you are feeling or what you are doing that might affect your diabetes. The meter allows you the option of setting a percentage for each health event, except for Fasting, if you set up bolus advice.
Page 41 Blood Glucose Test Reminders (Optional) The meter can be set up to remind you to retest your blood glucose after a high blood glucose result, after a low blood glucose result, or after a meal. An after high blood glucose test reminder example: •...
Page 42 Alarm Clock Reminders • The meter has alarm clock reminders which can be used as a helpful way to remind you when to test throughout the day. • In addition to “bG Test,” you can set reminders for “Other” for any other daily reminder. •...
Page 43: Screen Content And Navigation
1.5 Screen Content and Navigation This section provides an explanation of how to understand and navigate the screens on the meter. Each time the meter is turned on, this splash screen (Accu-Chek logo screen) is displayed for a short period of time.
Page 44 Features on the Main Menu 1. Sound Icon Appears when the beeper is turned on 2. Time 3. Vibrate Icon Appears when vibrate is turned on 4. Date 5. Low Battery Icon Appears when the meter batteries are low 6. Menu Options 7.
Page 45 NOTE • To select an item on a menu, press to highlight (blue) the menu item and then press . • When using the meter to remotely control the pump, the buttons of the meter have diff ering functions. For more information, see the Advanced Owner’s Booklet. 53895_00048010161_E.indb 39 9/4/15 9:34 AM...
Page 46 Bluetooth Wireless Technology Icon Communication States You may turn Bluetooth wireless technology on or off at any time using the meter. Icon Communication State Bluetooth wireless technology is on. The meter and pump are communicating. Bluetooth wireless technology is off. The meter and pump are not communicating. Bluetooth wireless technology is on.
Page 47 Connecting to the Pump screen during pairing: This screen appears when Bluetooth wireless technology is on and the meter is connecting to the pump. 53895_00048010161_E.indb 41 9/4/15 9:34 AM...
Page 48 Features on a screen 1. Title Bar Primary menu title is displayed here. 2. Highlighted Option When a menu choice or item is selected, it is highlighted in blue. 3. Left Soft Key Option Press to select the option above the button on the screen.
Page 49 Information can be entered on some screens. Numerical entry fields appear as pop-up entry fields. When an option must be selected, it appears as a pop-up menu. • To open a pop-up menu or entry fi eld, press . • Press to select the appropriate pop-up menu option or until the correct numerical entry is present, and then press .
Page 50 General Navigation Steps To change the settings or enter information into the meter: Press to select a menu option and press Repeat the previous step as necessary. 53895_00048010161_E.indb 44 9/4/15 9:34 AM...
Page 51 Select Save by pressing save changes and return to the previous screen. Press to select the Press desired entry and press select an option or a desired entry field and press Repeat Steps 2 and 3, as necessary. 53895_00048010161_E.indb 45 9/4/15 9:34 AM...
Page 52 53895_00048010161_E.indb 46 9/4/15 9:34 AM...
Page 53: Testing Your Blood Glucose
Testing Your Blood Glucose 2.1 Overview 2.2 Using the Accu-Chek Aviva Combo System 2.3 Performing a Blood Glucose Test 2.4 Detailed Blood Glucose Results 2.5 Understanding Blood Glucose Results 2.6 Unusual Blood Glucose Results 2.7 Symptoms of High or Low Blood Glucose 53895_00048010161_E.indb 47...
Page 54: Overview
2.1 Overview It is important to understand how to perform a blood glucose test properly. You can perform a blood glucose test from your fingertip. NOTE Blood glucose and bG are interchangeable and mean the same thing. 53895_00048010161_E.indb 48 9/4/15 9:34 AM...
Page 55: Using The Accu-Chek Aviva Combo System
2.2 Using the Accu‑Chek Aviva Combo System Before You Start Testing Using Accu‑Chek Aviva Test Strips • Only use Accu-Chek Aviva test strips. • Store the unused test strips in their original container. Do not remove test strips from the test strip container and put them into another container, such as a plastic bag, pocket, purse, wallet, etc.
Page 56 WARNING Not following the precautions below can lead to inaccurate results: • Do not store test strips in extreme temperatures or moisture areas (bathroom, kitchen, laundry room, car, or garage). Heat and moisture can damage your test strips. • Do not bend, cut, or alter the test strips. •...
Page 57: Performing A Blood Glucose Test
• Do not change your treatment because of one blood glucose result. • NEVER ignore symptoms of high or low blood glucose. NOTE If you need to perform a control test, only use Accu-Chek Aviva control solutions. See Chapter 3, Control Testing for more information about control testing. 53895_00048010161_E.indb 51...
Page 58 Performing a Fingertip Blood Glucose Test Prepare > Check the Use By Date > Insert Test Strip > Test Blood Sample > bG Result Wash and dry your hands. Dirty hands could affect results. Prepare the lancing device for a fingertip test. Always use a new lancet with each test.
Page 59 The Apply Sample screen Fingerstick: Fingerstick: appears. The test strip is Gently squeeze your finger to Perform a fingerstick with the ready for testing. assist the flow of blood. This lancing device. helps you get a blood drop. 53895_00048010161_E.indb 53 9/4/15 9:34 AM...
Page 60 When the test strip has The result appears on the enough blood, the Analyzing display. screen appears. Touch the blood drop to the front edge of the yellow window of the test strip. Do not put blood on top of the test strip.
Page 61 Approximately 3 seconds later, the detailed bG Result screen appears. Remove and discard the used test strip. 53895_00048010161_E.indb 55 9/4/15 9:34 AM...
Page 62 NOTE • If the blood drop is too small, reapply pressure to get a sufficient blood drop. • For more information regarding blood glucose results, see Section 2.5, Understanding Blood Glucose Results. • To add detailed information to the blood glucose test (meal time, carbs, and health events) see Section 2.4, Detailed Blood Glucose Results.
Page 63 NOTE Other ways to start a blood glucose test: • From the Main Menu, select bG Test and press . Insert a test strip into the meter. • When a reminder notifi cation or the key lock icon is displayed, insert a test strip into the meter. •...
Page 64: Detailed Blood Glucose Results
2.4 Detailed Blood Glucose Results The detailed bG Result screen displays the following information: 1. Test Time 2. Meal Time 3. Carbohydrates 4. Health Event 5. Active Insulin Displayed only if bolus advice is activated and data has recently been read from the pump. 6.
Page 65 Detailed bG Results > Change Meal Time/Carbs/Health Events (Optional) The detailed bG Result screen allows you to view and to add information to a blood glucose result. 53895_00048010161_E.indb 59 9/4/15 9:34 AM...
Page 66 How to Add Information to a Blood Glucose Result To Change Meal Time: Active Insulin Display: Bolus Advice is not available Select the Meal Time entry The meter displays the field and press calculated amount of Active The blood glucose result is Select either Pre Meal, Post Insulin.
Page 67 NOTE • You can add information on the detailed bG Result screen for meal time, carbs, and health events. • Review and, if necessary, update information for meal time, carbs, and health events to receive an accurate bolus recommendation. • Active insulin is bolus insulin that has been given to lower your blood glucose, but has not yet been fully used.
Page 68: Understanding Blood Glucose Results
2.5 Understanding Blood Glucose Results The bG Result screen displays the following information: 1. Test Time 2. Blood Glucose Result 3. Test Date 4. Status Bar 5. Unit of Measure NOTE • If the dosed test strip is removed from the meter before results or errors are displayed, a blood glucose result will not appear.
Page 69 Status Bar The status bar on the bG Result screen indicates how the result compares to the target blood glucose range for the current time block. The following are status bar descriptions with sample displays: Green indicates the result is Yellow indicates the result is Red with “Hypo”...
Page 70 Light blue with “Hyper” Light blue indicates the result indicates the result is above is above the target range for the hyper warning limit. the current time block. The result is not above the hyper warning limit. 53895_00048010161_E.indb 64 9/4/15 9:34 AM...
Page 71 LO or HI Display If “LO” is displayed, the test If “HI” is displayed, the test result may be below the result may be above the measurement range. measurement range. Contact your healthcare Contact your healthcare professional. professional. 53895_00048010161_E.indb 65 9/4/15 9:34 AM...
Page 72 NOTE Blood Glucose Warnings If the blood glucose results are outside the hyper or hypo warning limits, or outside the measurement range of the meter, then the warning is displayed after the bG Result screen. Select OK to acknowledge the warning and continue.
Page 73: Unusual Blood Glucose Results
7. Are you still unsure of the problem? Contact Accu-Chek Customer Care at 1-800-688-4578. After performing a control test and repeating a blood glucose test, if your blood glucose results still do not match the way you feel, contact your healthcare professional immediately.
Page 74: Symptoms Of High Or Low Blood Glucose
LO or HI, contact your healthcare professional immediately. • The meter is designed to display blood glucose results from 0.6 to 33.3 mmol/L. If a result below 0.6 mmol/L or over 33.3 mmol/L appears on the display, call Accu-Chek Customer Care at 1-800-688-4578.
Page 75 Comparing Your Meter Result to a Lab Result A common question is how the blood glucose results on your meter compare to the lab results. Your blood glucose can change quickly, especially after eating, taking medication, or physical activity. If you test yourself in the morning and then go to the healthcare professional’s office for a blood glucose test, your results will probably not match, even if you are fasting.
Page 76 53895_00048010161_E.indb 70 9/4/15 9:34 AM...
Page 77: Control Testing
Control Testing 3.1 Overview 3.2 Why Perform Control Tests 3.3 About the Control Solutions 3.4 Performing a Control Test 3.5 Understanding Control Test Results 53895_00048010161_E.indb 71 9/4/15 9:34 AM...
Page 78: Overview
3.1 Overview This chapter describes how and when to perform a control test to ensure the accuracy of your blood glucose meter. It is recommended you complete a control test prior to performing a blood glucose test for the first time. NOTE Blood glucose and bG are interchangeable and mean the same thing.
Page 79: Why Perform Control Tests
3.2 Why Perform Control Tests Performing a control test lets you know the meter and test strips are working properly to give reliable blood glucose results. You should perform a control test when: • You open a new test strip box. •...
Page 80: About The Control Solutions
3.3 About the Control Solutions • Only use Accu-Chek Aviva control solutions. • The meter automatically recognizes the control solution. • The control test results are not displayed in the diary. • Write the date you opened the control solution bottle on the bottle label. The solution is good for 3 months from that date or until the use by date on the bottle label, whichever comes first.
Page 81: Performing A Control Test
3.4 Performing a Control Test The Control Result screen displays the following information: 1. Test Time 2. Control Result 3. Test Date 4. Unit of Measure You need the meter with a pre-inserted activation chip, a test strip, and control solution Level 1, Level 2, or both.
Page 82 Check the Use By Date > Insert Test Strip > Test Control Solution > Control Result Insert the test strip into the The Apply Sample screen Check the use by date on the appears. The test strip is test strip container. Do not meter in the direction of the arrow.
Page 83 Select the control solution to Remove the control bottle cap. Place the meter on a flat test. You will enter the level Wipe the tip of the bottle with surface, like a table. later in the test. a tissue. 53895_00048010161_E.indb 77 9/4/15 9:34 AM...
Page 84 When the test strip has The control result appears on enough control solution, the the display. Analyzing screen appears. Select Level to display the Wipe the tip of the bottle with control solution level pop-up a tissue and then cap the menu.
Page 85 Select the control solution Remove and discard the test level and press strip. For information on understanding control test results, proceed to the next section, or press to save this result and display the Main Menu screen. 53895_00048010161_E.indb 79 9/4/15 9:34 AM...
Page 86 NOTE • If a test strip error occurs, remove and discard the used test strip and repeat the test with a new test strip. • Be careful not to put any fluids into the test strip slot. • When the Control Level screen is displayed and you select Cancel without selecting a control solution level, then No Entry is chosen.
Page 87: Understanding Control Test Results
3.5 Understanding Control Test Results The detailed Control Result screen displays the following information: 1. Test Time 2. Control Result 3. Unit of Measure 4. Menu Press to save result and display Main Menu screen 5. Test Date 6. Control Solution Level 7.
Page 88 Example Control Results When the control test result Example is inside the range on the test Range (mmol/L) strip container, the test strips Level 1 1.4-3.1 and the meter are working Level 2 14.2-19.1 properly. If the control test result is The label on your test within the acceptable range, strip container shows the “Within range”...
Page 89 If the control test result is If “HI” is displayed, the control If “LO” is displayed, the outside of the acceptable test result may be above the control test result may be range, “Out of range” appears measurement range. below the measurement on the detailed Control Result range.
Page 90 If the meter stored No Entry for the control solution level, then “--- ” appears with no indication of in or out of range. 53895_00048010161_E.indb 84 9/4/15 9:34 AM...
Page 91 Repeat the control test with a properly stored test strip cool, dry place? and control solution. 6. Did you follow the directions? Read Chapter 3, Control Testing, and repeat the control test. If you still have problems, contact Accu-Chek Customer Care at 1-800-688-4578. 53895_00048010161_E.indb 85 9/4/15 9:34 AM...
Page 92 1 or 2, when you performed the control test? still compare the control result to the range printed on the test strip container. 8. Are you still unsure of the problem? Contact Accu-Chek Customer Care at 1-800-688-4578. 53895_00048010161_E.indb 86 9/4/15 9:34 AM...
Page 93: Managing Your Data
Managing Your Data 4.1 Overview 4.2 Viewing or Modifying Your Data 4.3 Adding New Data 4.4 Reporting Your Data 4.5 Downloading Your Data to a Computer 53895_00048010161_E.indb 87 9/4/15 9:34 AM...
Page 94: Overview
4.1 Overview Analyzing your blood glucose results stored in the meter is an effective way for you and your healthcare professional to determine how well you are controlling your diabetes. This analysis is a valuable tool for making improvements to your diabetes management. The reports the meter displays help you get the most from your meter.
Page 95 NOTE • You must be the only user of the meter, because the diary data will be incorrect if the meter is shared. • Blood glucose and bG are interchangeable and mean the same thing. 53895_00048010161_E.indb 89 9/4/15 9:34 AM...
Page 96 Storing Test Results The meter automatically stores up to 1,000 diary records with the time and date. You can review up to 250 diary records on the meter or up to 1,000 diary records using a computer with compatible software. Diary records are stored from the newest to the oldest. It is very important to have the correct time and date set. Having the correct time and date setting helps ensure accurate interpretation of blood glucose results by you and your healthcare professional.
Page 97 • Do not change your therapy based on one individual record or test result in the diary. • This chapter shows sample screens. The screens may look slightly different from the screens on the meter. If you have any questions about the meter screens, contact Accu-Chek Customer Care at 1-800-688-4578.
Page 98: Viewing Or Modifying Your Data
4.2 Viewing or Modifying Your Data The View Data screen displays the following information: 1. Date of Record(s) 2. Time of Blood Glucose Test 3. Blood Glucose Test Icon 4. Meal Time Icon 5. Unit of Measure 6. Blood Glucose Result 7.
Page 99 NOTE • If data are not available, the No Data Available screen is displayed. • The View Data screen displays the records in the order in which they occurred with the most recent record shown on top. • For the blood glucose result: −...
Page 100 Icon descriptions: Icon Icon Name Description bG Test Icon is displayed when information exists for this diary record regarding a blood glucose test. Meal Time Icon is displayed when information exists for this diary record regarding meal time. Carbs Icon is displayed when information exists for this diary record regarding carbs.
Page 101 Icon Icon Name Description Extended Bolus Not Confirmed Delivery has not been confirmed by the pump. Extended Bolus Confirmed Delivery has been confirmed by the pump. Manual Pump Delivery has not been confirmed by the pump. Pen/Syringe Bolus Pump does not deliver bolus. 53895_00048010161_E.indb 95 9/4/15 9:34 AM...
Page 102 You can view a diary record with its attributes (blood glucose value, meal time, carbs, health event, and bolus). Main Menu > My Data > View Data From the Main Menu, select Select View Data and press My Data and press 53895_00048010161_E.indb 96 9/4/15 9:34 AM...
Page 103 Bolus View Blood Glucose View Carb View Shown above are View Data screens that display values for blood glucose, bolus, or carbs. To choose another view, press (a pop-up menu appears). Select the view you want and press . Press view other records (the screen scrolls if there are additional records).
Page 104 To return to the previous screen, press To modify a diary record, press and continue to the next step. Press to view the previous record or press to view the next (newer) record. 53895_00048010161_E.indb 98 9/4/15 9:34 AM...
Page 105 NOTE To cancel changes or return to the View Detail screen, press Select the entry field to modify and press Make the change in the entry field and press Modify other fields, as needed. To save the changes and return to the View Detail screen, press 53895_00048010161_E.indb 99 9/4/15 9:34 AM...
Page 106 The following fields cannot be modified with the specified condition: Fields Cannot be modified if the … Bolus Bolus type is confirmed standard, extended, or multiwave Bolus Blood glucose result was below the hypo warning limit Meal Time Record has no blood glucose value Meal Time, Carbs, Health Event, Record has been used for bolus advice and Bolus...
Page 107: Adding New Data
4.3 Adding New Data You can add data to a diary record for carbs, health, and bolus. The Add Data screen displays the following information: 1. Time Entry Field 2. Date Entry Field 3. Carbs Entry Field 4. Health Entry Field 5.
Page 108 Main Menu > My Data > Add Data From the Main Menu, select Select Add Data and press Select an entry field and press My Data and press Make addition in the entry field and press Make additions to other entry fields, as needed.
Page 109 NOTE • The meter initially displays the current date and the current time. You can change the date and time when adding a diary record, although the date and time cannot be set in the future. • Before a diary record can be saved, data must be entered (not including date and time). “Save” is not displayed above until data has been entered.
Page 110: Reporting Your Data
4.4 Reporting Your Data 1. Time Range 2. Meal Times 3. Blood Glucose Standard Deviation Calculated for the time range 4. Number of Tests Used to calculate the averages and standard deviations 5. Blood Glucose Average Calculated for the time range 53895_00048010161_E.indb 104 9/4/15 9:34 AM...
Page 111 NOTE • If data are not available to calculate averages, the No Data Available screen is displayed. • Standard deviation measures how much the blood glucose results are scattered around the blood glucose average. A low standard deviation means the blood glucose results are tightly clustered around the blood glucose average;...
Page 112 Reporting Your Blood Glucose Averages The meter displays your blood glucose averages and standard deviations for the time range you choose (7, 14, 30, 60, or 90 days). Main Menu > My Data > Reports > bG Averages From the Main Menu, select Select Reports and press Select bG Averages and press My Data and press...
Page 113 The blood glucose averages are displayed. To display blood glucose averages for another time range (last 7, 14, 30, 60, or 90 days), press either to scroll the screen until you reach the time range you need. To return to the Reports screen, press 53895_00048010161_E.indb 107 9/4/15 9:34 AM...
Page 114 Reporting Your Data Trends The meter displays your blood glucose record trends for the time range you choose (last 8 hours, 24 hours, 48 hours, or 7 days). Main Menu > My Data > Reports > Trend Select Trend and press From the Main Menu, select Select Reports and press My Data and press 53895_00048010161_E.indb 108...
Page 115 Trend Graph Screen 1. Time Range 2. Meal Time Selection 3. Blood Glucose Unit of Measure 4. Blood Glucose Icon 5. Times or Days of Month 6. Bolus Icon 7. Bolus Unit of Measure 8. Maximum Bolus Amount Indicator 9. Maximum Carbs Amount Indicator 10.
Page 116 12. Arrow Indicates blood glucose data extends beyond screen 13. Bolus Value Blue bar: height shown is in relation to the bolus insulin amount 14. Each Blood Glucose Value Connected with lines 15. Carb Value Dark orange bar: height shown is in relation to the carbs amount 16.
Page 117 Follow these tips to get the most value from My Data reports • If you delivered a bolus directly on the pump, go to My Data on the meter to receive the bolus information automatically. Do this before your next blood glucose test. •...
Page 118 NOTE • If data are not available to display the trend graph, the No Data Available screen is displayed. • Trend graphs do not include corrupt results or control results. • Trend graph data is cleared if bolus advice data is cleared. •...
Page 119 NOTE • On the right side of the graph, the Maximum Bolus Amount Indicator is a horizontal line with the corresponding value shown above it. The purpose of this indicator is to scale the top portion of the graph for the Bolus Value blue bars. The Maximum Bolus Amount Indicator values available on the meter are 1, 5, 15, 30, and 60 U.
Page 120 Trend Graph Press to display the Table To display a trend graph for (proceed to the next section another meal time selection for more information). (Overall, Pre Meal, Post Meal, Bedtime, or Other), press To return to the Reports either to highlight screen, press the meal time selection field...
Page 121 NOTE The meter saves the current settings (time range, meal time, and graph view) when you select Back or when the meter powers off. 53895_00048010161_E.indb 115 9/4/15 9:34 AM...
Page 122 Trend Table Screen 1. Time Range 2. Meal Time Selection 3. Date of Records 4. Blood Glucose Icon with Blood Glucose Unit of Measure 5. Time Change Icon Only shown when meter time has been changed for this data 6. Carbs Icon with Carbs Unit of Measure 7.
Page 123 NOTE • If data are not available to display the trend table, the No Data Available screen is displayed. • Trend tables do not include corrupt results or control results. • If (time change icon) is shown at the bottom of the Trend Table screen, the time and date of one or more data points in the trend table may not match the time stamp in My Data because the meter clock has been changed.
Page 124 Trend Table To display a trend table To display a trend table for for another time range another meal time selection (last 8 hours, 24 hours, (Overall, Pre Meal, Post Meal, 48 hours, or 7 days), press Bedtime, or Other), press to highlight the time range either to highlight selection field (top of screen).
Page 125 NOTE Press to display the Graph The meter saves the current settings (time range, meal time, and table (see previous section for more view) when you select Back or when the meter powers off. information). To return to the Reports screen, press 53895_00048010161_E.indb 119 9/4/15 9:34 AM...
Page 126 Reporting Your Standard Day The meter displays (for a standard day) your blood glucose averages, number of tests, and standard deviations within predetermined time blocks for the time range you choose (last 7, 14, 30, 60, or 90 days). Main Menu > My Data > Reports > Standard Day From the Main Menu, select Select Reports and press Select Standard Day and...
Page 127 Standard Day Graph Screen 1. Time Range 2. Meal Time Selection 3. Blood Glucose Unit of Measure 4. Blood Glucose Icon 5. Ending Time of Each Time Block Vertical dashed line 6. Arrow Indicates blood glucose average is off the top of the graph (“X” is not displayed) 7.
Page 128 NOTE • If data are not available to display the standard day graph, the No Data Available screen is displayed. • The standard day graph does not include corrupt results, control results, HI values, or LO values. 53895_00048010161_E.indb 122 9/4/15 9:34 AM...
Page 129 Standard Day Graph To display a standard day Press to display the Table graph for another meal (proceed to the next section time selection (Overall, Pre for more information). Meal, Post Meal, Bedtime, To return to the Reports or Other), press either screen, press to highlight the meal time selection field (immediately...
Page 130 NOTE The meter saves the current settings (time range, meal time, and graph view) when you select Back or when the meter powers off. 53895_00048010161_E.indb 124 9/4/15 9:34 AM...
Page 131 Standard Day Table Screen 1. Time Range 2. Meal Time Selection 3. Time Block 4. Blood Glucose Average 5. Standard Deviation (SD) 6. Number of Tests 53895_00048010161_E.indb 125 9/4/15 9:34 AM...
Page 132 NOTE • If data are not available to display the standard day table, the No Data Available screen is displayed. • Standard day table calculations do not include corrupt results, control results, or HI and LO results. • For a standard deviation to be displayed for a given time block, there must have been two or more tests recorded during the time block.
Page 133 Standard Day Table To display a standard day To display a standard day table for another time range table for another meal time (last 7, 14, 30, 60, or 90 days), selection (Overall, Pre Meal, press to highlight the time Post Meal, Bedtime, or range selection field (top of Other), press either screen).
Page 134 NOTE Press to display the Graph The meter saves the current settings (time range, meal time, and table (see previous section for more view) when you select Back or when the meter powers off. information). To return to the Reports screen, press 53895_00048010161_E.indb 128 9/4/15 9:34 AM...
Page 135 Reporting Your Standard Week The meter displays (for a standard week) your blood glucose averages, number of tests, and standard deviations for each day of the week for the time range you choose (last 7, 14, 30, 60, or 90 days). Main Menu >...
Page 136 Standard Week Graph Screen 1. Time Range 2. Meal Time Selection 3. Blood Glucose Unit of Measure 4. Blood Glucose Icon 5. Day of Week 6. Arrow Indicates blood glucose average is off the top of the graph (“X” is not displayed) 7.
Page 137 NOTE • If data are not available to display the standard week graph, the No Data Available screen is displayed. • The standard week graph does not include corrupt results, control results, HI values, or LO values. 53895_00048010161_E.indb 131 9/4/15 9:34 AM...
Page 138 Standard Week Graph To display a standard week Press to display the Table graph for another meal (proceed to the next section time selection (Overall, Pre for more information). Meal, Post Meal, Bedtime, To return to the Reports or Other), press either screen, press to highlight the meal time selection field (immediately...
Page 139 NOTE The meter saves the current settings (time range, meal time, and graph view) when you select Back or when the meter powers off. 53895_00048010161_E.indb 133 9/4/15 9:34 AM...
Page 140 Standard Week Table Screen 1. Time Range 2. Meal Time Selection 3. Blood Glucose Average 4. Day of Week 5. Standard Deviation (SD) 6. Number of Tests NOTE • If data are not available to display the standard week table, the No Data Available screen is displayed. •...
Page 141 Standard Week Table To display a standard week To display a standard week table for another time range table for another meal time (last 7, 14, 30, 60, or 90 days), selection (Overall, Pre Meal, select the time range selection Post Meal, Bedtime, or field (top of screen).
Page 142 NOTE Press to display the Graph The meter saves the current settings (time range, meal time, and table (see previous section for more view) when you select Back or when the meter powers off. information). To return to the Reports screen, press 53895_00048010161_E.indb 136 9/4/15 9:34 AM...
Page 143 Reporting Your Target The meter displays a pie chart illustrating your blood glucose records as “Above,” “Within,” “Below,” and “Hypo” for the time range you choose (last 7, 14, 30, 60, or 90 days). Main Menu > My Data > Reports > Target Select Target and press Select Reports and press From the Main Menu, select...
Page 144 Target Graph Screen 1. Time Range 2. Legend Blood glucose result categories 3. Meal Time Selection 4. Pie Chart Represents the percentages for the blood glucose result categories NOTE • If data are not available to display the target graph, the No Data Available screen is displayed. •...
Page 145 Target Graph To display a target graph for Press to display the Table another meal time selection (proceed to the next section (Overall, Pre Meal, Post Meal, for more information). Bedtime, or Other), press To return to the Reports either to highlight screen, press the meal time selection field...
Page 146 NOTE The meter saves the current settings (time range, meal time, and graph view) when you select Back or when the meter powers off. 53895_00048010161_E.indb 140 9/4/15 9:34 AM...
Page 147 Target Table Screen 1. Time Range 2. Legend Blood glucose result categories 3. Meal Time Selection 4. Percentage of Occurrence NOTE • If results or data are not available for the selected time period and meal time, the No Data Available screen is displayed.
Page 148 Target Table To display a target table for Press to display the Target another meal time selection Graph (see previous section (Overall, Pre Meal, Post Meal, for more information). Bedtime, or Other), press To return to the Reports either to highlight screen, press the meal time selection field (immediately below the time...
Page 149 NOTE The meter saves the current settings (time range, meal time, and table view) when you select Back or when the meter powers off. 53895_00048010161_E.indb 143 9/4/15 9:34 AM...
Page 150: Downloading Your Data To A Computer
4.5 Downloading Your Data to a Computer You can transfer your stored results to a computer to track, identify patterns, and print. Install the software according Run the software program and to the instructions. follow the instructions about how to download information. Connect the computer cable Ensure the software is ready according to the instructions.
Page 151 Infrared (IR) Window Locate the infrared (IR) Follow the prompts on your Select Data Transfer and press window on the top of the computer software to start the meter. data transfer. Locate the IR window on the computer’s infrared cable. Point the two IR windows toward each other.
Page 152 NOTE If the data did not transfer successfully, turn off the meter, turn the meter back on, and try again. If you still have problems, contact Accu-Chek Customer Care at 1-800-688-4578. Once the data transfer is complete, the Data Transfer Complete screen is displayed for 3 seconds and then the...
Page 153: Changing Meter Settings
Changing Meter Settings 5.1 Overview 5.2 Setting bG Test Reminders: After High bG, After Low bG, After Meal 5.3 Setting Alarm Clock Reminders: bG Test, Other 5.4 Setting Date Reminders: Dr. Visit, Lab Test, Infusion Set Change 5.5 Setting Bolus Advice for the First Time 5.6 Setting Time Blocks, Health Events, Advice Options: Bolus Advice Set Up 5.7 Setting Warning Limits: Hyper, Hypo 5.8 Turning Key Lock On or Off...
Page 154 5.14 Setting the Time Format, Time, Date 5.15 Setting Time Blocks: Bolus Advice Not Set Up 5.16 Backlight Settings 53895_00048010161_E.indb 148 9/4/15 9:34 AM...
Page 155: Overview
5.1 Overview You have the flexibility to change the meter settings that you initially selected during the Setup Wizard process. You can make adjustments to the meter settings in order to meet changing conditions. Consult with your healthcare professional to ensure the appropriate settings are selected. Settings: Important Information •...
Page 156: Setting Bg Test Reminders: After High Bg, After Low Bg, After Meal
5.2 Setting bG Test Reminders: After High bG, After Low bG, After Meal bG Test Reminders: Important Information • At the scheduled time, the meter turns on and displays the reminder (if a test strip has not been inserted). However, if the meter is already on when the reminder is scheduled and no blood glucose test was performed, the reminder is displayed when the meter powers down.
Page 157 Main Menu > Settings > Reminders > bG Test Reminders From the Main Menu, select Select Reminders and press Select bG Test Reminders and Settings and press press 53895_00048010161_E.indb 151 9/4/15 9:34 AM...
Page 158 To Change the bG Threshold: Select the bG Threshold entry field and press Set the bG Threshold level and press To Change the Remind After Time: Select the Remind After entry To Turn the After High bG Select either After High bG, field and press Reminder On or Off: After Low bG, or After Meal...
Page 159 To Change the Remind After Time: Select the Remind After entry field and press Set the amount of time after a low blood glucose result you want to be reminded to retest your blood glucose and To Turn the After Low bG To Turn the After Meal press Reminder On or Off:...
Page 160 To Change the Remind After Time: Select the Remind After entry field and press Set the amount of time after a meal (carb entry larger than the snack size) you want to be reminded to retest your blood If you changed the Snack glucose and press Size, the After Meal screen is To save the changes,...
Page 161 NOTE • Remind After is displayed as “HH:MM” (e.g., 1:30) where “H” is hour and “M” is minute. • When the meter is displaying the Remind After Meal screen for the fi rst time, if bolus advice has not been set up, the default for Snack Size is no entry (“---g”). If bolus advice has been set up, the default value is the value set for the Snack Size on the Advice Options screen.
Page 162: Setting Alarm Clock Reminders: Bg Test, Other
5.3 Setting Alarm Clock Reminders: bG Test, Other Alarm clock reminders are a helpful way to remind you to test your blood glucose, or for any other daily appointment. You can set up to eight reminders per day. Alarm Clock Reminders: Important Information •...
Page 163 Main Menu > Settings > Reminders > Alarm Clock From the Main Menu, select Select Reminders and Select Alarm Clock and Settings and press press press 53895_00048010161_E.indb 157 9/4/15 9:34 AM...
Page 164 To Turn Off a Reminder: Select the type of Reminder entry field (i.e., bG Test or Other) and press Select Off and press Repeat the above steps to turn off additional reminders. To Turn On or Change a To save the changes and Reminder: return to the Reminders Select the time entry field for...
Page 165 NOTE • To cancel changes or return to the Reminders screen, select Cancel. • Time for the Alarm Clock reminders can be set in 15 minute increments, where “HH” is hour, “MM” is minutes, and with “am” or “pm” for the 12-hour format. •...
Page 166: Setting Date Reminders: Dr. Visit, Lab Test, Infusion Set Change
5.4 Setting Date Reminders: Dr. Visit, Lab Test, Infusion Set Change Date reminders are a helpful way to remind you of an upcoming Dr. visit or lab test. In addition, you can set up an ongoing reminder for an infusion set change for the interval you choose (1 day, 2 days, or 3 days). Date Reminders: Important Information •...
Page 167 Main Menu > Settings > Reminders > Date Reminders Select Date Reminders and From the Main Menu, select Select Reminders and press Settings and press press 53895_00048010161_E.indb 161 9/4/15 9:34 AM...
Page 168 To Set the Date: Select the Date entry field and press Set the Day and press Set the Month and press Set the Year and press To Set the Time (Optional): Select either Dr. Visit, Lab Test, To Turn the Dr. Visit Select the Time entry field and or Infusion Set Change and Reminder On or Off:...
Page 169 To Set the Date: Select the Date entry field and press Set the Day and press Set the Month and press Set the Year and press To Set the Time (Optional): To save the changes To Turn the Lab Test Select the Time entry field and and return to the Date Reminder On or Off:...
Page 170 NOTE To Turn the Infusion Set • Setting a time for a Date Reminder is optional. If you choose not to Change Reminder On or Off: set a time, ensure the Time entry fi eld value is “--:--” (no entry). Select the Reminder entry field and press •...
Page 171: Setting Bolus Advice For The First Time
5.5 Setting Bolus Advice for the First Time Set Up Bolus Advice If you did not set up bolus advice when you went through the Setup Wizard and have now decided to utilize bolus advice, proceed with this section. Once you do set up bolus advice, you cannot turn it off. It is suggested that you review the information in the Getting Started Guide before continuing.
Page 172 Time Blocks–Bolus Advice Screen 1. Time Block Start Time 2. Target Range Lower Limit Value 3. Carb Ratio–Number of Insulin Units 4. Time Block End Time 5. Target Range Upper Limit Value 6. Carb Ratio–Number of Carbs scroll down 7. Insulin Sensitivity–Number of Insulin Units 8.
Page 173 Main Menu > Settings > Bolus Advice From the Main Menu, select Select Bolus Advice and If you do NOT want to set up Settings and press press bolus advice, press return to the Settings screen. To set up bolus advice, press and continue to the next step.
Page 174 scroll down To continue, press To Change Time Blocks: Select a time block to edit and press To Change the End Time: Select the End Time entry field and press Set the End Time and press 53895_00048010161_E.indb 168 9/4/15 9:34 AM...
Page 175 To Change the Target Range: To Change the Carb Ratio: To Change the Insulin Sensitivity: Select the entry field for the Select the entry field for the lower value of the Target number of Insulin Units and Select the entry field for the Range and press press number of Insulin Units and...
Page 176 The carb ratio and insulin Return to Step 5 to change To Add a Time Block: sensitivity are copied to all another Time Block. Select the last time block and time blocks. You may edit the press Continue in order to add target range, carb ratio, and Select the End Time entry field or remove Time Blocks,...
Page 177 Add another Time Block, or To save the changes and return to the Time Blocks proceed to Step 8. screen, press To Remove a Time Block: Remove another Time Block, Select the Time Block you or proceed to Step 8. want to remove and press Select the End Time entry field and press Set the End Time to match the...
Page 178 To Change the Acting Time: Select the Acting Time entry field and press Set the Acting Time duration and press To Change the Offset Time: Select the Offset Time entry field and press To Change the Health To Change the Meal Rise: Set the Offset Time duration and Events: Select the Meal Rise entry...
Page 179 To return to the Settings Press screen, press 53895_00048010161_E.indb 173 9/4/15 9:34 AM...
Page 180 Bolus Advice Options Meal Rise, Snack Size, Acting Time, and Offset Time are Bolus Advice Options. Below are detailed descriptions of each of these settings. Meal Rise During or after meals, an increase in blood glucose level is considered normal within a certain range, even though a bolus has been delivered.
Page 181: Setting Time Blocks, Health Events, Advice Options: Bolus Advice Set Up
5.6 Setting Time Blocks, Health Events, Advice Options: Bolus Advice Set Up If bolus advice has been set up, use this section for: • Adding or removing time blocks • Changing the time of day when time blocks occur • Changing the values for target range, carb ratio, and insulin sensitivity for any time block •...
Page 182 Setting Time Blocks–Bolus Advice is Set Up Main Menu > Settings > Bolus Advice > Time Blocks From the Main Menu, select Select Bolus Advice and Select Time Blocks and Settings and press press press 53895_00048010161_E.indb 176 9/4/15 9:34 AM...
Page 183 To Add a Time Block: To Remove a Time Block: Select the last time block and Select the Time Block you press want to remove and press To Add or Remove Time Blocks: If you do not need to add or remove time blocks, then proceed to To Change the Select the End Time entry field...
Page 184 To Change the Time Blocks: To Change the Carb Ratio: Select a Time Block to edit Select the entry field for the and press number of Insulin Units and press Set the number of Insulin Units and press Select the entry field for the amount of Carbs and press To Change the End Time: Set the amount of Carbs...
Page 185 Set the Insulin Sensitivity level and press Press To change another time block, select the time block and press . Return to Step 5. To return to the Bolus Advice screen, press 53895_00048010161_E.indb 179 9/4/15 9:34 AM...
Page 186 Setting Health Events–Bolus Advice is Set Up Main Menu > Settings > Bolus Advice > Health Events Select Health Events and From the Main Menu, select Select Bolus Advice and press Settings and press press 53895_00048010161_E.indb 180 9/4/15 9:34 AM...
Page 187 To Change the Health Events: Select the entry field of the Health Event to be changed and press Set the percentage and press Repeat the previous steps to change other Health Events. To save the changes and return to the Bolus Advice screen, press 53895_00048010161_E.indb 181 9/4/15 9:34 AM...
Page 188 Setting Bolus Advice Options–Bolus Advice is Set Up Main Menu > Settings > Bolus Advice > Advice Options From the Main Menu, select Select Bolus Advice and Select Advice Options and Settings and press press press 53895_00048010161_E.indb 182 9/4/15 9:34 AM...
Page 189 To Change the Acting Time: Select Acting Time entry field and press Set the Acting Time duration and press To Change the Offset Time: Select the Offset Time entry field and press If you did not change the To Change the Meal Rise: Set the Offset Time duration Snack Size, the meter returns Select the Meal Rise entry...
Page 190: Setting Warning Limits: Hyper, Hypo
5.7 Setting Warning Limits: Hyper, Hypo You can set blood glucose warning limits for hyperglycemia (Hyper) or hypoglycemia (Hypo) conditions. Once these blood glucose limit values have been set, if your test result is above the hyper warning limit, the meter displays the Above Hyper Warning Limit message: “Consider checking for ketones, bG and insulin regularly.”...
Page 191 Main Menu > Settings > Meter > Warning Limits Select Warning Limits and From the Main Menu, select Select Meter and press press Settings and press 53895_00048010161_E.indb 185 9/4/15 9:34 AM...
Page 192 To Change the Hypo Blood Glucose Level: Select the Hypo entry field and press Set the Hypo (lower) blood glucose level and press To save the changes and return to the Meter Menu To Change the Hyper Blood screen, press Glucose Level: Select the Hyper entry field and press...
Page 193: Turning Key Lock On Or Off
5.8 Turning Key Lock On or Off The key lock feature allows you to lock all of the buttons on the meter, except for the power on/off button. This serves as a safety measure against unintentional activation of meter functions. 53895_00048010161_E.indb 187 9/4/15 9:34 AM...
Page 194 Main Menu > Settings > Meter > Key Lock From the Main Menu, select Select Meter and press Select Key Lock and press Settings and press 53895_00048010161_E.indb 188 9/4/15 9:34 AM...
Page 195 Key Lock: Important Information When the buttons are locked, you can still turn the meter on and off. You can also adjust the backlight. The buttons are unlocked when: Press to display the Key If the buttons are locked when •...
Page 196: Setting The Language
5.9 Setting the Language You can select a language from the predefined list. 53895_00048010161_E.indb 190 9/4/15 9:34 AM...
Page 197 Main Menu > Settings > Meter > Language From the Main Menu, select Select Meter and press Select Language and press Settings and press 53895_00048010161_E.indb 191 9/4/15 9:34 AM...
Page 198 Press to display the Language options. Select the desired Language and press To save the change and return to the Meter Menu screen, press 53895_00048010161_E.indb 192 9/4/15 9:34 AM...
Page 199: Setting Units: Carbs
5.10 Setting Units: Carbs You can set up the meter for a specific carbohydrates (Carbs) unit (Grams, BE, KE, or CC). Once the Carbs unit is set and bolus advice is activated, the Carbs unit cannot be changed. 53895_00048010161_E.indb 193 9/4/15 9:34 AM...
Page 200 Main Menu > Settings > Meter > Units From the Main Menu, select Select Meter and press Select Units and press Settings and press 53895_00048010161_E.indb 194 9/4/15 9:34 AM...
Page 201 • Once the Carbs unit (Grams, BE, KE, or CC) is set and bolus advice is activated the Carbs unit cannot be changed. If you need to change the Carbs unit contact the Accu-Chek Customer Care Service Center at 1-800-688-4578.
Page 202: Turning Bluetooth ® Wireless Technology On Or Off
5.11 Turning Bluetooth Wireless Technology On or Off ® Main Menu > Settings > Meter > Bluetooth From the Main Menu, select Select Meter and press Select Bluetooth and press Settings and press 53895_00048010161_E.indb 196 9/4/15 9:34 AM...
Page 203 To turn Bluetooth wireless technology either On or Off, press and hold until the Bluetooth wireless technology icon changes. Release To save the change and return to the Meter Menu screen, press 53895_00048010161_E.indb 197 9/4/15 9:34 AM...
Page 204: Pairing The Meter And Pump
5.12 Pairing the Meter and Pump For complete pairing instructions, see the Advanced Owner’s Booklet. 53895_00048010161_E.indb 198 9/4/15 9:34 AM...
Page 205: Setting The Beeper, Vibrate, Key Sound
5.13 Setting the Beeper, Vibrate, Key Sound You can set up the meter for sound mode and/or vibrate mode. The meter features different sound (beeper) tones. Sounds may occur for: • Button presses • Errors • Warnings • Reminders NOTE •...
Page 206 Main Menu > Settings > Sound/Vibrate From the Main Menu, select Select Sound/Vibrate and To Change the Beeper Sound Settings and press press Level: Select the Beeper entry field and press Select the Beeper sound level (Off, Low, Medium, or High) and press 53895_00048010161_E.indb 200 9/4/15 9:34 AM...
Page 207 To Turn Vibrate On or Off: Select the Vibrate entry field and press . Select the Vibrate mode (On or Off) and press To Change the Key Sound: Select the Key Sound entry field and press Select the Key Sound mode (On or Off) and press To save the changes and return to the Settings Menu...
Page 208: Setting The Time Format, Time, Date
5.14 Setting the Time Format, Time, Date NOTE • It is recommended you set the date and time on the pump (the date and time on the meter will automatically synchronize to match the pump). • Changing the date and time will impact the Trend Graph and the Trend Table (see Reporting Your Data Trends in Section 4.4, Reporting Your Data).
Page 209 Main Menu > Settings > Time/Date To Change the Time Format: From the Main Menu, select Select Time/Date and Settings and press press Select the Time Format entry field and press Select 12-hr or 24-hr Time Format and press 53895_00048010161_E.indb 203 9/4/15 9:34 AM...
Page 210 To Change the Time: Select the Time entry field and press Set the Hour and press Set the Minutes and press If Time Format is 12-hour, select am or pm and press To Change the Date: Select the Date entry field and press Set the Day and press Set the Month and press...
Page 211: Setting Time Blocks: Bolus Advice Not Set Up
5.15 Setting Time Blocks: Bolus Advice Not Set Up This section is for changing, adding, and removing time blocks only if bolus advice has not been set up. For each time block, you can set up different blood glucose target ranges. It is suggested that you review the Getting Started Guide before continuing.
Page 212 Change End Time, Target Range Lower Value, and/or Target Range Upper Value Main Menu > Settings > Time Blocks From the Main Menu, select Time Blocks does not appear Select the time block to edit Settings and press if bolus advice has been set and press Select Time Blocks and press...
Page 213 To Change the Target Range: Select the entry field for the lower value of the Target Range and press Set the value and press Select the entry field for the upper value of the Target Range and press To Change the End Time: Repeat Steps 3 and 4 to Set the value and press change another time block.
Page 214 NOTE • When you set the end time, the meter sets this end time as the start time for the next time block. • The end time can be set in 30-minute increments. • To cancel changes press . 53895_00048010161_E.indb 208 9/4/15 9:34 AM...
Page 215 Add a Time Block Main Menu > Settings > Time Blocks From the Main Menu, select Time Blocks does not appear Select the last time block and press Settings and press if bolus advice has been set Select Time Blocks and press 53895_00048010161_E.indb 209 9/4/15 9:34 AM...
Page 216 Update the End Times and Target Ranges for all time blocks, as needed. See Change End Time, Target Range Lower Value, and/or Target Range Upper Value in this section. Select the End Time entry field and press Set the End Time of the selected Time Block and press .
Page 217 Remove a Time Block Main Menu > Settings > Time Blocks From the Main Menu, select Select the Time Block you Time Blocks does not appear if Settings and press bolus advice has been set up. want to remove and press Select Time Blocks and press 53895_00048010161_E.indb 211...
Page 218 Update the End Times and Target Ranges for the remaining time blocks, as needed. See Change End Time, Target Range Lower Value, and/or Target Range Upper Value, in this section. Select the End Time entry field and press Set the End Time to match the start time of the Time Block and press To save the changes and...
Page 219: Backlight Settings
5.16 Backlight Settings The backlight on your meter helps you read the information on the meter display under different lighting conditions. You can adjust the backlight level by pressing the backlight button on the front of the meter. The backlight adjusts from low, to medium, to high, and back to low again. 1.
Page 220 NOTE • When the meter is turned on, the backlight is set to medium. • When the backlight is set to high or medium and no button activity has occurred for approximately 15 seconds, the meter goes to low backlight (to conserve battery life). The meter restores the original backlight setting when you press a button, insert a test strip, or when the meter displays the bG Results screen.
Page 221: Icons, Reminders, Warnings, And Errors
Icons, Reminders, Warnings, and Errors 6.1 Overview 6.2 List of Icons 6.3 Confirming a Reminder, Warning, or Error 6.4 List of Reminders 6.5 List of Warnings 6.6 List of Errors 53895_00048010161_E.indb 215 9/4/15 9:34 AM...
Page 222: Overview
6.1 Overview This chapter provides you with detailed listings of all the icons, reminders, warnings, and errors included in the meter. NOTE Blood glucose and bG are interchangeable and mean the same thing. 53895_00048010161_E.indb 216 9/4/15 9:34 AM...
Page 223: List Of Icons
6.2 List of Icons The icons and icon names in the meter are: Icon Name Icon Icon Name Icon Active Insulin Control Test Add Data Date Analyzing Download (Data Transfer) Beeper Error Blood Glucose Averages Extended Bolus Not Confirmed Blood Glucose Test Extended Bolus Confirmed Bluetooth Wireless Technology Enabled Health...
Page 224 Icon Name Icon Icon Name Icon Meter (Settings) Sound/Vibrate (Settings) Multiwave Bolus Not Confirmed Standard Bolus Not Confirmed Multiwave Bolus Confirmed Standard Bolus Confirmed My Data Time Pen/Syringe Bolus Time Block (Settings) Pump Time Change Reminder Time/Date (Settings) Reminder (Settings) Vibrate Reports View Data...
Page 225: Confirming A Reminder, Warning, Or Error
6.3 Conﬁ rming a Reminder, Warning, or Error To confirm (or dismiss) most reminders or warnings, press . Some error messages require a different confirmation, such as “Retest with new Strip” or “Replace batteries now.” To place some reminders in the snooze mode, press .
Page 226: List Of Reminders
6.4 List of Reminders Reminder Screen Example 1. Reminder Icon 2. Snooze Reschedule the reminder. This is not available for all reminders. 3. Reminder Title 4. Reminder Message 5. Dismiss NOTE • The meter beeps when it displays any reminder if the beeper setting is on. •...
Page 227 For instructions on how to set up meter reminders, see Chapter 5, Changing Meter Settings. The reminders available on the meter are: Reminder Title Reminder Message Left Soft Key Right Soft Key Snooze Time Carbs entry higher than Snack Size After Meal Retest Snooze Dismiss 5 minutes...
Page 228 Reminder Title Reminder Message Left Soft Key Right Soft Key Snooze Time Displayed the next time Infusion Set Change It is time to change your Infusion Set Snooze Dismiss the meter is powered-on If the lab test time has been set: You have a Lab Test today at (Settings Lab Test Time) Lab Test Today...
Page 229 Reminders: Important Information When two or more event reminders occur at the same time, the meter displays the event reminder with the highest priority first: 1. bG Test Reminders (After High bG, After Low bG, and After Meal) 2. Alarm Clock Reminders (bG Test and Other) 3.
Page 230 Low bG Retest Reminder • When your blood glucose result is less than the low blood glucose threshold setting you have set up (see Chapter 5, Changing Meter Settings), then the meter schedules a Low bG Retest reminder for the time duration you have set up.
Page 231 High bG Retest Reminder • When your blood glucose result is greater than the high blood glucose threshold setting you have set up (see Chapter 5, Changing Meter Settings), then the meter schedules a High bG Retest reminder for the time duration you have set up. The meter maintains the duration of this scheduled reminder regardless of meter time and date changes.
Page 232 After Meal Reminder • When you enter carbohydrates into the diary through one of the following screens and the carbohydrates entered are greater than the Snack Size setting, then the meter schedules an After Meal reminder for the time duration you have set up (see Chapter 5, Changing Meter Settings). The meter maintains the duration of this scheduled reminder regardless of meter time and date changes.
Page 233 Alarm Clock Reminders for bG Test and Other • At the scheduled time, the meter turns on and displays the reminder (if a test strip has not been inserted). • When the meter displays an Alarm Clock reminder and you do not press any meter buttons, after 30 seconds the meter turns off and displays the reminder again in 2 minutes.
Page 234: List Of Warnings
6.5 List of Warnings Warning Screen Example 1. Warning Icon 2. No Only shown on a few warning screens 3. Warning Title 4. Warning Message 5. Yes or OK NOTE The meter beeps when it displays a warning if the beeper setting is on. 53895_00048010161_E.indb 228 9/4/15 9:34 AM...
Page 235 The warnings the meter may display are: Warning Title Warning Message Left Soft Key Right Soft Key Consider checking for ketones, bG and Above Hyper Warning Limit insulin regularly Beep and Vibrate settings cannot both be Beep/Vibrate Off turned off at same time Eat fast carbs of at least (number of carbs).
Page 236 Warning Title Warning Message Left Soft Key Right Soft Key Bolus below allowed amount. Bolus set to Bolus Too Low minimum. Calculation Out of Range No Bolus Advice available Carbohydrate Ratio Carb Ratio seems unusual. Check entries. Code Key Missing Turn off Meter and insert valid Code Key Communication Lost See Pump...
Page 237 Warning Title Warning Message Left Soft Key Right Soft Key Diary Results Expired New data cannot be saved with this record HI bG Warning Consider checking bG, ketones and insulin Pump time/date incorrect. Set time/date on Incorrect Pump Time/Date the Pump. Infrequent Pump Two weeks since last communication with Communication...
Page 238 Warning Title Warning Message Left Soft Key Right Soft Key Invalid PIN Reenter PIN shown on Pump display Record time/date must be older than the Invalid Record Time/Date current meter time/date Lower target range value above upper target Invalid Target Range range value Range selected conflicts with Hyper and/or Invalid Target Range...
Page 239 Warning Title Warning Message Left Soft Key Right Soft Key Test Strips Expiring Change Code Key and Strips soon Meter time has been changed by more than Time Mismatch 5 minutes to match Pump The meter displays a recommended amount of fast carbohydrates. On the meter display, the activation chip is referred to as a code key.
Page 240: List Of Errors
6.6 List of Errors Error Screen Example 1. Error Icon 2. Menu This option is not available for all errors. 3. Error Title 4. Error Message NOTE The meter beeps when it displays an error, even if the beeper setting is turned off. 53895_00048010161_E.indb 234 9/4/15 9:34 AM...
Page 241 The errors the meter may display are: Error Title Error Message Left Soft Key Right Soft Key E-51 Reinsert or replace with new Strip Bad Strip Error E-52 Turn Meter off, reinsert or replace Code Key Menu Code Key Error E-53 Retest with new Strip Bad Test Error...
Page 242 “Menu” is only displayed when the meter is in a bG test screen. “OK” is only displayed after the splash screen (Accu-Chek logo screen). If the meter is powering up, then “OK” is displayed above the right soft key and “Menu” is not displayed above the left soft key.
Page 243: Care And Maintenance
Care and Maintenance 7.1 Overview 7.2 Changing the Batteries 7.3 Power-Saving Tips 7.4 Cleaning the Meter 7.5 Maintenance and Testing 53895_00048010161_E.indb 237 9/4/15 9:34 AM...
Page 244: Overview
7.1 Overview It is important to properly care for and maintain your meter. If you have any questions about the care and maintenance of your meter, contact Accu-Chek Customer Care at 1-800-688-4578. 53895_00048010161_E.indb 238 9/4/15 9:34 AM...
Page 245: Changing The Batteries
7.2 Changing the Batteries Put the battery door back in Remove the old batteries from Remove the battery door place and snap it closed. from the back of the meter the meter. by pushing the tab in the Insert three AAA batteries with direction of the arrow and the + and - ends matching pulling up the door.
Page 246 WARNING • Using batteries other than those supplied or recommended for use with the meter may significantly reduce the life of the batteries. Batteries other than those recommended may leak and corrode the battery contacts within the meter. Using batteries not supplied or recommended may void the warranty. •...
Page 247 NOTE • Alkaline batteries are recommended for use with the meter. • After you change the batteries, the meter prompts you to confirm the time and date settings. • It is a good idea to have spare, packaged batteries available. •...
Page 248: Power-Saving Tips
7.3 Power‑Saving Tips To conserve battery life: • Use the low beeper setting • Only turn on the vibrate feature when it is needed • Turn off the meter when you are finished rather than utilizing the auto power off feature 53895_00048010161_E.indb 242 9/4/15 9:34 AM...
Page 249: Cleaning The Meter
7.4 Cleaning the Meter Caring for the meter is easy: just keep it free of dust. If you need to clean it, follow these guidelines carefully to help you get the best performance possible: • Ensure the meter is off •...
Page 250: Maintenance And Testing
• To test the meter display, turn off the meter, and then press and hold . The display cycles through colors (red, blue, green, and white). If any part of the display does not change colors, contact Accu-Chek Customer Care at 1-800-688-4578.
Page 251: Troubleshooting
Troubleshooting 8.1 Overview 8.2 Troubleshooting the Accu-Chek Aviva Combo Meter 53895_00048010161_E.indb 245 9/4/15 9:34 AM...
Page 252: Overview
For most problems, the meter displays a message with a short description of the symptom and, along with it, a proposed solution. This chapter goes into more detail by describing the symptom, the possible cause, and the possible solution. If the possible solutions do not fix the problem, contact Accu-Chek Customer Care at 1-800-688-4578.
Page 253: Troubleshooting The Accu-Chek Aviva Combo Meter
8.2 Troubleshooting the Accu‑Chek Aviva Combo Meter Display Shows Possible Cause(s) Possible Solution(s) The display is Batteries are dead. Install new batteries. See Chapter 7, Care and Maintenance. blank or the meter will not turn on. Display is damaged. Contact Accu-Chek Customer Care at 1-800-688-4578.
Page 254 Display Shows Possible Cause(s) Possible Solution(s) Beep/Vibrate Off Beep and Vibrate settings cannot Ensure that either the Beep or Vibrate setting is turned be turned off at the same time. on. See Chapter 5, Changing Meter Settings. Below Hypo Your test result is below the hypo •...
Page 255 Display Shows Possible Cause(s) Possible Solution(s) Bolus Delivery The meter cannot communicate • Retry or set to Manual Pump. • Ensure the meter and pump have Bluetooth Unavailable with the pump. wireless technology turned on. • Ensure the meter and pump are within communication range.
Page 256 Display Shows Possible Cause(s) Possible Solution(s) Code Key Missing The activation chip is not Turn the meter off and insert the activation chip. If you inserted. need an activation chip, please contact Roche. Communication Pump is out of range of the •...
Page 257 Display Shows Possible Cause(s) Possible Solution(s) • Ensure the meter and pump have Bluetooth Communication • Communication of bolus Warning data from the pump was not wireless technology turned on. successful. Therefore, pump • Ensure the meter and pump are within data are not available and communication range.
Page 258 Display Shows Possible Cause(s) Possible Solution(s) Diary Entry Used The diary entry selected has Carefully confirm all information involving bolus For Advice been used for bolus advice and advice. You cannot modify bolus advice related entries modifications are not allowed. on the meter.
Page 259 Display Shows Possible Cause(s) Possible Solution(s) E-52 The activation chip is incorrect. Please contact Roche. Code Key Error E-53 A meter or test strip error has Discard the test strip and repeat the test. Bad Test Error occurred. Your blood glucose may be If this matches how you feel, contact your healthcare extremely high.
Page 260 Insert a black activation chip. Make sure the time and date in the meter are correct. If you need a black activation chip, please contact Accu-Chek Customer Care at 1-800-688-4578. E-56 Blood or control solution was Discard the test strip and repeat the test with a new...
Page 261 Display Shows Possible Cause(s) Possible Solution(s) E-58 The temperature is above or Move the meter to an area within the proper Temp. Error below the proper range for the temperature range indicated for test strip use meter. in the test strip package insert. Wait 5 minutes before turning on the meter.
Page 262 Display Shows Possible Cause(s) Possible Solution(s) • Ensure the meter and pump have Bluetooth Infrequent Pump At least 2 weeks have passed Communication since the meter and pump have wireless technology turned on. communicated. • Ensure the meter and pump are within communication range.
Page 263 Display Shows Possible Cause(s) Possible Solution(s) Invalid Hyper The hyper warning limit value • Reset the hyper warning limit or revise the target Values must be greater than all of your ranges in time blocks and re-enter the hyper target ranges in the time block warning limit.
Page 264 Display Shows Possible Cause(s) Possible Solution(s) Invalid Target The lower target range value is • Reset the target range values. Range above the upper target range • Enter the correct lower target range value and value. upper target range value. See Chapter 5, Changing Meter Settings.
Page 265 Display Shows Possible Cause(s) Possible Solution(s) No bG with Bolus You have not tested your bG and It is recommended to test bG before delivering insulin. are attempting to deliver a bolus. Pairing Failed The attempt to pair the meter Restart the pairing process.
Page 266 Insert a black activation chip. Make sure the time and date in the meter are correct. If you need a black activation chip, please contact Accu-Chek Customer Care at 1-800-688-4578. • Ensure the time and date are correct. If the time or date are not correct, change the time and date on the pump.
Page 267 • If you have a question or if you see any other error screen, please contact Accu-Chek Customer Care at 1-800-688-4578. 53895_00048010161_E.indb 261 9/4/15 9:34 AM...
Page 268 53895_00048010161_E.indb 262 9/4/15 9:34 AM...
Page 269: Technical Information
Technical Information 9.1 Overview 9.2 Product Limitations 9.3 Specifications 9.4 Product Safety Information 9.5 Disposing of the Meter, Strips, Lancets, and Batteries 9.6 Warranty 9.7 Additional Supplies 9.8 Information for Healthcare Professionals 53895_00048010161_E.indb 263 9/4/15 9:34 AM...
Page 270: Overview
9.1 Overview This chapter provides you with important performance information regarding the meter. 53895_00048010161_E.indb 264 9/4/15 9:34 AM...
Page 271: Product Limitations
9.2 Product Limitations Please read the literature packaged with your test strips to find the latest information on product specifications and limitations. 53895_00048010161_E.indb 265 9/4/15 9:34 AM...
Page 272: Specifications
9.3 Specifications Blood volume Refer to the test strip package insert. Sample type Fresh whole blood Measuring time Refer to the test strip package insert. Measuring range Refer to the test strip package insert. Test strip storage conditions Refer to the test strip package insert. Meter storage conditions (with batteries -20 ºC to 50 ºC inserted)
Page 273 Dimensions 94 x 55 x 25 mm LWH Weight Approximately 103 g with batteries inserted Construction Hand-held Protection class The Accu-Chek Aviva Combo Meter is suitable for continuous Meter type operation. Control solution storage conditions 2 °C to 32 °C Interface IR; LED/IRED – Class 1 53895_00048010161_E.indb 267...
Page 274: Product Safety Information
9.4 Product Safety Information WARNING Choking hazard. Small parts. Keep away from children under the age of 3 years. Bluetooth Wireless Technology The meter and the pump utilize Bluetooth wireless technology to communicate and transfer information. Bluetooth wireless technology is a form of radio frequency (RF) technology that operates in the unlicensed industrial, scientific, and medical band at 2.4 to 2.485 GHz.
Page 275 Radio Frequency Communication The device complies with the United States Federal Communications Commission (FCC) standards. The device complies with FCC Part 15 Rules. Operation of the device is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 276 Interference from the meter to other electrically driven equipment is not to be anticipated. Performance Analysis The performance data for the Accu-Chek Aviva Combo System (Accu-Chek Aviva Combo Meter with Accu-Chek Aviva Test Strips) were obtained using capillary blood from diabetic patients (method comparison, accuracy), venous blood (repeatability), and control solution (reproducibility).
Page 277: Disposing Of The Meter, Strips, Lancets, And Batteries
9.5 Disposing of the Meter, Strips, Lancets, and Batteries WARNING • Any product coming in contact with blood is considered contaminated (potentially infectious).* • During blood glucose measurement, the meter itself may come into contact with blood. • Lancing devices may also be considered sharps. Disposal of sharps is regulated by law in many jurisdictions.
Page 278: Warranty
Roche Diagnostics Canada, a member of the Roche Group warrants to the original purchaser of the meter that your Accu-Chek Aviva Combo Meter will be free from defects in materials and workmanship for 5 years from the date of purchase. If during this 5-year period, the meter does not work properly because of a defect in materials or workmanship, Roche Diagnostics Canada will replace it with a new Accu-Chek Aviva Combo Meter or equivalent product free of charge.
Page 279 FOR A LONGER DURATION THAN FIVE YEARS FROM THE DATE OF PURCHASE. Warranty Instructions All requests for return of Accu-Chek Aviva Combo Meters under the preceding warranty must be made to Accu-Chek Customer Care. You will be mailed a return authorization label, which must be affixed to your carton for shipping the system to Roche Diagnostics Canada.
Page 280: Additional Supplies
9.7 Additional Supplies The following supplies and accessories are available from your authorized Roche Diabetes Healthcare Center, pharmacies, or your medical/surgical supply dealer: Test Strips Accu-Chek Aviva Test Strips Control Solutions Accu-Chek Aviva Control Solutions 53895_00048010161_E.indb 274 9/4/15 9:34 AM...
Page 281: Information For Healthcare Professionals
9.8 Information for Healthcare Professionals NOTE Healthcare Professionals: Follow the infection control procedures appropriate for your facility. A drop of fresh, whole blood is required to perform a blood glucose test. Refer to the test strip package insert for additional healthcare professional information. 53895_00048010161_E.indb 275 9/4/15 9:34 AM...
Page 282 53895_00048010161_E.indb 276 9/4/15 9:34 AM...
Page 283: Appendices
Appendices Appendix A: Abbreviations Abbreviation Definition Ante Meridiem (12-hour clock notation for “before noon”) Bread Equivalent (equal to 12 grams of carbohydrates) Blood Glucose °C Degrees Celsius (or Centigrade) Carbs Carbohydrates Carbohydrate Choice (equal to 15 grams of carbohydrates) Federal Communications Commission (United States) Grams Gigahertz Hyper...
Page 284 Abbreviation Definition Hypo Hypoglycemia (low blood glucose) Industry Canada Infrared International Organization for Standardization Kohlenhydrateinheit (equal to 10 grams of carbohydrates) Liquid Crystal Display mmol/L Millimoles per Liter Not Applicable NIST National Institute of Standards and Technology (United States) Personal Identification Number Post Meridiem (12-hour clock notation for “after noon”) 53895_00048010161_E.indb 278 9/4/15 9:34 AM...
Page 285 Abbreviation Definition Radio Frequency Standard Deviation Units (bolus insulin units) 53895_00048010161_E.indb 279 9/4/15 9:34 AM...
Page 286: Appendix B: Carb Units
Appendix B: Carb Units For carbohydrates, the following units of measure are available on the meter. Abbreviation Unit of Measurement Gram Equivalent Grams* 1 gram Kohlenhydrateinheit 10 grams Bread Equivalent 12 grams Carbohydrate Choice 15 grams *Standard unit of measure in Canada. 53895_00048010161_E.indb 280 9/4/15 9:34 AM...
Page 287: Appendix C: Explanation Of Symbols
Appendix C: Explanation of Symbols You may encounter the following symbols on the packaging, on the type plate (back of meter), and in the instructions for the meter, shown here with their meaning. Consult instructions for use Caution, refer to safety-related notes in the instructions for use accompanying this product. A NOTE is used to provide additional information.
Page 288: Appendix D: Meter Settings And Range Limits
Appendix D: Meter Settings and Range Limits mmol/L Data Type Unit of Measurement Increments Default Setting Acting Time hours:minutes 1:30 8:00 0:15 4:00 Active Insulin Units 99.9 bG Threshold (High) mmol/L 19.5 Hyper Warning Limit bG Threshold (Low) mmol/L Hypo Warning Limit grams No entry (“--- g”) No entry (“--- BE”)
Page 289 Data Type Unit of Measurement Increments Default Setting Exercise 1 (health event) Exercise 2 (health event) Extended Bolus Units (insulin) Hyper Warning Limit mmol/L 19.5 16.5 Hypo Warning Limit mmol/L Illness (health event) No entry Insulin Sensitivity (bG) mmol/L 55.4 (“--- mmol/L”) Insulin Sensitivity Units (insulin)
Page 290 Units (insulin) Stress (health event) Target Range Upper mmol/L Value Target Range Lower mmol/L Value The maximum that can actually be delivered may be less due to the Accu-Chek Spirit Combo Pump’s maximum insulin amount. 53895_00048010161_E.indb 284 9/4/15 9:34 AM...
Page 291 The following are the default settings for bG test reminders. To turn on a bG test reminder, see Setting Alarm Clock Reminders: bG Test, Other in Chapter 5, Changing Meter Settings. Test Reminder Default Time of Day 7:00 9:00 11:00 12:00 14:00 16:00 19:00...
Page 292 The following are the default settings for the time blocks. Talk to your healthcare professional about setting up time blocks to help you manage your diabetes. To adjust the time blocks, see Chapter 5, Changing Meter Settings. Time Block 24‑Hour Format 0:00–5:30 5:30–11:00 11:00–17:00...
Page 293: Glossary
Glossary Term Definition 7-day average Includes results generated today and the previous 6 days. Acting Time The period of time from the start of the meal rise or the delivery of a correction bolus until your blood glucose level is expected to return to the target level.
Page 294 Term Definition Alarm Audible or vibrating (silent) notification indicating a reminder, warning, or error. bG Test Reminders Reminders to retest your blood glucose after a high blood glucose result, after a low blood glucose result, or after a meal. bG Threshold A bG test reminder setting.
Page 295 Term Definition Bolus Delivery Start Delay The Standard Bolus icon blinks for 5 seconds and then the meter communicates to the pump to begin delivery of the bolus amount. During this delay you are able to cancel the bolus delivery by pressing or .
Page 296 Term Definition Period of time starting at 00:00 and ending at 23:59. End Time The end time of a time block. Extended Bolus A bolus delivered over a period of time. The Extended Bolus might be helpful, for example, during long meals, dinners, or receptions, or when you have meals that are digested slowly or may also be appropriate for people who have gastroparesis (delayed digestion).
Page 297 Term Definition Hypo Warning Limit When your blood glucose result is below the hypo warning limit, a warning is displayed. Insulin Pump A device that delivers a continuous supply of insulin into the body. Insulin Sensitivity The amount of insulin necessary to lower your blood glucose by a certain amount.
Page 298 Term Definition Meter Blood glucose meter. Multiwave Bolus A bolus designed to better simulate the body’s insulin delivery. It combines an immediate bolus delivery followed by an Extended Bolus delivery. A Multiwave Bolus might be helpful, for example, when you have meals that include both rapidly and slowly absorbed carbohydrates.
Page 299 Term Definition Remind After A bG test reminder setting. The amount of time after a high blood glucose result, after a low blood glucose result, or after a meal you want the reminder to occur. Reminder When enabled, reminders occur to remind you to test your blood glucose, to retest your blood glucose or of an event or activity.
Page 300 Term Definition Start Time The start time of a time block. Target Range The desired upper and lower limits of your blood glucose level considered acceptable as set by your healthcare professional. Time Blocks Up to eight time periods within one day to facilitate your changing insulin needs throughout the day.
Page 301: Index
Index abbreviations batteries, low acting time 172, batteries, type activation chip 16, activation chip slot beeper, setting active insulin bG threshold advice options blood glucose averages after high bG test reminder 150, 220, blood glucose testing 52, 53, 54, 55, after low bG test reminder 150, 220, blood glucose test, performing after meal bG test reminder 150, 220,...
Page 302 carbohydrates, units of measure disposing, meter carb ratio 169, dr. visit reminder 160, 221, cleaning meter communication 247, 250, electromagnetic compatibility control solution 19, 74, errors, list of control test, performing 73, control test, results 78, control test, results, troubleshooting g (grams) graph, standard day graph, standard week...
Page 303 icons, listing 94, maintenance, meter infrared (IR) window 18, meal rise 172, 174, infusion set change reminder 222, meal time 56, 58, insulin pump meter 7, insulin sensitivity meter, summary of features navigation key lock 24, 28, key sound, setting offset time 172, lab test reminder lancing device 52,...
Page 304 reminders, blood glucose test table, standard day reminders, list of table, standard week reminders, other table, target reminders, priority table, trend target range 169, target, reporting safety information test results, storing screen, features 38, 42–43 test results, unusual scroll bar test strip 17, 19, 20, 52, 53, 54, 55, 56, snack size 153, 172, time blocks 32, 165, 175, 205,...
Page 305 vibrate, setting warnings, list of warranty, 53895_00048010161_E.indb 299 9/4/15 9:34 AM...
Page 306 53895_00048010161_E.indb 300 9/4/15 9:34 AM...

Accu-Chek Aviva Combo Standard Owner’s Booklet

Before You Start Testing

Introduction

1 Understanding Your New System

2 Testing Your Blood Glucose

3 Control Testing

4 Managing Your Data

5 Changing Meter Settings

6 Icons, Reminders, Warnings, and Errors

7 Care and Maintenance

8 Troubleshooting

9 Technical Information

Appendices

Appendix A: Abbreviations

Appendix B: Carb Units

Appendix C: Explanation of Symbols

Appendix D: Meter Settings and Range Limits

Glossary

Index

Quick Links

Troubleshooting

Related Manuals for Accu-Chek Aviva Combo

Summary of Contents for Accu-Chek Aviva Combo

Table of Contents
