Simplicity CONQUEST Conquest / 2700 Parts Manual page 23

Transmission Group
REF NO PART NO.
1 1960676SM
2 1722174SM
3 1722173SM
4 1960636SM
5 1704351SM
6 1928352SM
7 1960637SM
8 1931350SM
9 1960686SM
10 1721728ASM
11 1676148SM
12 1924940SM
13 1922130SM
14 1722460SM
15 1722151SM
16 1918267SM
17 1721360SM
18 1716289SM
19 1669105SM
20 1723126SM
21 1721622SM
22 1921210SM
23 1722903SM
24 1919326SM
26 1960590SM
27 1722152SM
28 1921333SM
29 1722383SM
30 1733941SM
30 1733208SM
31 1918447SM
32 1721424SM
33 1722684SM
34 8191045SM
35 1960687SM
36 1960667SM
37 1732088SM
38 1732191SM
39 1721392SM
40 1722194SM
41 1719968SM
42 1719233SM
43 1933958SM
Footnotes
The above parts group applies to the following Mfg. Nos.:
1695152 - Conquest
1695153 - Conquest
1695154 - 1723H
1695155 - 2723H
1695226 - Conquest
2690598 - Conquest
© Copyright 2008 Simplicity Manufacturing, Inc. All Rights Reserved.
QTY. DESCRIPTION
2 SCREW, Pan Head Torx Taptite, 1/4-20 x 1-1/4
1 PAD, Footrest, LH, Differential Lock
1 PAD, Footrest, RH
1 NUT, Hex KEPS, 5/16-18
15 FASTENER, 11/16" Long, Stem Plastic
2 NUT, Hex Flange Whiz Lock, 3/8-16, Large
6 NUT, Hex KEPS, 3/8-16
6 CARRIAGE BOLT, 3/8-16 x 1
6 NUT, Hex Flagne ESNA, 5/16-18
2 SUPPORT
2 BUSHING, 5/8 x 3/4 x 13/32, Powder Metal
3 WASHER, 3/8
1 CAPSCREW, Hex Head, 3/8-16 x 2-1/4
7 PIN, Quick
1 ROD, Differential Lock, 15-3/16 Long
3 WASHER, 7/16
1 ROD & TUBE ASSEMBLY, Differential Lock Pedal
1 KNOB
1 SPACER, 25/64 x 5/8 x 1-1/2, Hardened
1 KNOB, 3 Sided Soft
1 ROD, Free Wheel, 18-3/16 Long
1 CAPSCREW, Hex Head, 3/8-16 x 1, Black
1 PIVOT ASSEMBLY, Differential Lock
2 WASHER, 5/16, Black
4 CAPSCREW, Hex Head, 5/16-18 x 3
1 ROD, Differential Latch, 2 Bends, 6-3/16 Long
1 CAPSCREW, Hex Head, 5/16-18 x 1
1 ARM, Differential Lock
1 TRANSMISSION ASSEMBLY, K66L Transmission (Used on models with tranmission
expansion tank, attached or mounted to transmission.)
1 TRANSMISSION ASSEMBLY, K66AC Transmission (Used on models with remote
expansion tank Ref. No. 51)
1 PIN, Cotter, 3/4, Black
1 ROD, Brake, 17-27/64 Long
1 SPRING, Compression
1 SPRING, Compression
2 NUT, Hex Flange ESNA, 3/8-16
1 SCREW, Whiz 5/8-18 x 1
1 SPACER
1 ARM & WELD PINS ASSEMBLY, Control K66
1 V-BELT
1 PULLEY & HUB ASSEMBLY, Transmission
1 NUT, Hex Flange, M10-1.5, Nylon Insert
1 FAN, 5 Blades, 3 Holes
3 CAPSCREW, Hex Washer Head Taptite, 1/4-20 x 1-1/8
2690600 - Conquest
2690603 - 1723H
2690605 - 2723H
2690656 - Conquest
23
TP 400-4593-A-CQ-SMA
