Simplicity CONQUEST Conquest / 2700 Parts Manual page 19

Engine Group - 20HP, 22HP & 23HP Briggs & Stratton, Vanguard Twin
REF NO PART NO.
1 1726920SM
1 1722625SM
2 *
3 1917356SM
4 2860660SM
5 1723165SM
6 *
6 *
6 *
6 *
7 1722949SM
8 1722388ASM
9 1925003SM
10 1727223SM
10 1734506SM
11 1701011SM
12 2860112SM
13 1718678SM
14 2834683SM
15 1722392ASM
16 1929000SM
17 1720463SM
18 1722288SM
19 1708264SM
20 1918199SM
21 1960648SM
22 1686883SM
22 1720532SM
23 2832747SM
24 2830598SM
25 2820427SM
26 1722414ASM
27 1960295SM
28 1924856SM
29 1960368SM
30 1935255SM
31 1722389ASM
32 1722390ASM
Footnotes
Note* See your local Briggs & Stratton distributor for parts and service.
The above parts group applies to the following Mfg. Nos.:
1695152 - Conquest
1695154 - 1723H
1695155 - 2723H
1695226 - Conquest
2690600 - Conquest
2690603 - 1723H
© Copyright 2008 Simplicity Manufacturing, Inc. All Rights Reserved.
QTY. DESCRIPTION
1 MUFFLER
1 MUFFLER (Only used on 20HP Models)
2 GASKET
4 LOCKWASHER, 5/16
4 CAPSCREW, Socket Head, 5/16-18 x 7/8, G8
1 HOSE, Oil Drain
1 ENGINE, 22HP Briggs & Stratton VANGUARD Twin, Model 386777, Type 0111E1
1 ENGINE, 23HP Briggs & Stratton VANGUARD Twin, Model 386777, Type 0111E1
1 ENGINE, 21HP Briggs & Stratton VANGUARD Twin, Model 385777, Type 0119-E1
1 ENGINE, 20HP Briggs & Stratton VANGUARD Twin, Model 358777, Type 0110-E1
1 SEAL, Circle
1 BULKHEAD
2 CAPSCREW, Hex Head Taptite, 1/4-20 x 1/2
1 CONTROL, Throttle Double 39" Long w/Knobs (Only used on 20HP Models)
1 CONTROL, Throttle Double
1 TIE
2 CLAMP, Hose Type E
1 HOSE, 59" Long
2 CLIP, Wire
2 SHIELD
8 SCREW, Hex Head Taptite, 1/4-20 x 3/8
1 KEY
1 PULLEY & HUB ASSEMBLY, 4-1/2 OD
1 WASHER, Hex
1 LOCKWASHER, 7/16
1 CAPSCREW, Hex Head, 7/16-20 x 2-3/4
1 CLUTCH, Electric, OGURA
1 CLUTCH, Electric, Big Brake OGURA
1 TIE
4 CAPSCREW, Hex Head Taptite, 3/8-16 x 1-1/2
1 LOCKWASHER, External Tooth, 3/8
1 SHIELD, Muffler Bottom
8 CAPSCREW, Hex Head Flange Lock, 1/4-20 x 5/8
2 CAPSCREW, Hex Head Taptite, 5/16-18 x 1/2
8 NUT, Speed, 1/4-20
2 NUT, Speed, 5/16-18
1 DUCT, Muffler Top
1 DUCT, Muffler Extension
2690605 - 2723H
2690656 - Conquest
19
TP 400-4593-A-CQ-SMA
