Operation/Repair/Parts
FinishPro
For professional use only. For portable spray applications of fine finish coatings.
Not approved for use in explosive atmospheres or hazardous locations.
FinishPro HVLP 7.0/9.0 Standard
FinishPro HVLP 7.0/9.0/9.5 ProContractor
FinishPro HVLP 9.5 ProComp
See page 3 for additional model information
1
0 psi (0.07 MPa, 0.7 bar) Maximum Working Pressure
ProComp Models: 50 psi (0.35MPa, 3.5 bar) Maximum Fluid Working Pressure
Important Safety Instructions
Read all warnings and instructions in this manual and in related manuals.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
Related Manuals:
3A4980
FIRE AND EXPLOSION HAZARD
•
The turbine motor generates sparks.
Keep sprayer at least 20 feet (6m)
from spray area. Use additional hose if
necessary.
•
Spraying flammable or combustible
materials in a factory or fixed location
must comply with NFPA 33 and OSHA
1910.94(c) requirements in the USA
and with all similar local regulations in
other countries.
www.graco.com/techsupport
™
HVLP 7.0/9.0/9.5
Gun
48
3A4967C
EN
ti30622a
