Simplicity ZERO TURN TP 400-2169-01-ZT-SMA Parts Manual page 7

Frame, Body & Fuel System Group
REF NO. PART NO.
55 1708524
56 1704351
57 1660347
58 1718376
59 960208
60 1704626
61 1705249
62 1705248
63 1960373
64 1704628
65 1935255
66 1930591
67 1716038
68 1704867
69 921133
Footnotes:
Ref Nos 1-54 on previous page.
The above parts group applies to the following Mfg. Nos.:
1692905 14HP, ZT Rider
1692906 16HP, ZT Rider
1692907 14HP, ZT Rider
1692908 16HP, ZT Rider
TP 400-2169-01-ZT-SMA
QTY.
1 FOOTREST PAD, RH
14 FASTENER, Panel
1 FRAME ASSEMBLY
1 PANEL, Front
2 WASHER, Plain
2 SPACER, Hood, Plastic
2 SPACER
2 PIVOT, Hood
2 CAPSCREW, Taptite, 5/16-18 x 1
2 CLIP
4 NUT, Pal, 5/16-18
4 CAPSCREW, Hex Flange Whiz Lock, 5/16-18 x 3/4
2 BUSHING, Upper
2 BEARING, Lower
2 FITTING, Grease
1692910 14HP, ZT Rider
1692911 16HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693143 16HP, ZT Rider (Export)
DESCRIPTION
1693286 14HP, ZT Rider
1693288 16HP, ZT Rider
1693290 14HP, ZT Rider (Export)
1693292 16HP, ZT Rider (Export)
5
1693296 14HP, ZT Rider
1693298 16HP, ZT Rider
1693300 14HP, ZT Rider
1693302 16HP, ZT Rider
