Simplicity ZERO TURN TP 400-2169-01-ZT-SMA Parts Manual page 13

Electrical Group With Module
REF NO. PART NO.
1 1714320
2 1701580
3 1675043
4 1715976
5 1715955
6 1701011
7 1716332
8 1716061
9 1717549
10 1717550
11 1717163
12 1931211
13 920427
14 1707056
15 1922586
16 1916622
17 1916964
18 1921319
19 1923341
20 1612103
21 1685215
22 1667805
23 1665872
24 1703851
25 1709086
26 1708882
27 1713642
28 1665238
29 1925003
30 1665237
31 1685290
32 1709088
33 122023
34 1920263
35 1917356
36 1715956
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1692905 14HP, ZT Rider
1692906 16HP, ZT Rider
1692907 14HP, ZT Rider
1692908 16HP, ZT Rider
TP 400-2169-01-ZT-SMA
QTY.
1 SWITCH, Seat
1 SWITCH, Neutral Start
2 POP-RIVET
1 WIRE ASSEMBLY, Neutral
1 HARNESS, Wiring
3 TIE, Self-Locking
1 SWITCH, PTO, Electric Clutch
1 SWITCH, Ignition (6 pole)
1 NUT, Hex
1 COVER, Keyswitch
1 KEYS (Set of 2 Keys)
1 NUT, Hex Flange Whiz Lock, 3/8-16
1 WASHER, Lock, External Tooth, 3/8
1 CABLE, Battery Ground
1 CAPSCREW, Hex Head, 3/8-16 x 5/8
2 NUT, Hex, 1/4-20
2 WASHER, Lock, 1/4
2 WASHER
2 CAPSCREW, Hex Head, 1/4-20 x 3/4
1 TUBE, Vent
1 BATTERY
1 BRACE, Battery
1 STRAP, Battery
1 CABLE, Battery to Solenoid
1 BOOT, Insulator
1 WIRE ASSEMBLY, Clutch
1 MODULE, Interlock
1 CIRCUIT BREAKER
2 CAPSCREW, Hex Washer Head, Taptite, 1/4-20 x 1/2
1 WIRE ASSEMBLY
1 SOLENOID
1 CABLE, Solenoid to Starter
3 COVER, Terminal
2 NUT, Hex, 5/16-24
2 WASHER, Lock, 5/16
1 CLIP
1692910 14HP, ZT Rider
1692911 16HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693143 16HP, ZT Rider (Export)
DESCRIPTION
11
