Simplicity ZERO TURN TP 400-2169-01-ZT-SMA Parts Manual page 11

Engine Group
REF NO. PART NO.
1 1714065
2 *
2 *
3 1713846
4 1960536
5 1709055
6 1708725
7 1708405
8 1919381
9 1917356
10 1960405
11 1933263
12 1950021
13 1717664
14 1918199
15 1960351
16 1713502
17 1676183
18 1960483
19 1919326
20 1917372
21 1935255
22 1708416
23 1713557
24 1924856
25 1716080
26 1716024
27 1923735
28 1924874
29 1923300
30 1708264
31 1921333
Footnotes:
* See your local Kohler distributor for Service Parts.
The above parts group applies to the following Mfg. Nos.:
1692905 14HP, ZT Rider
1692906 16HP, ZT Rider
1692907 14HP, ZT Rider
1692908 16HP, ZT Rider
TP 400-2169-01-ZT-SMA
QTY.
1 THROTTLE CONTROL ASSEMBLY
1 ENGINE ASSEMBLY, 14 HP Kohler
1 ENGINE ASSEMBLY, 16 HP Kohler
1 KNOB, Throttle
2 SCREW, Plastite, 1/4-10 x 1/2
1 SEAL, Air Inlet
1 AIR DUCT
1 VALVE, Shut Off
3 WASHER, Plain, 5/16
5 LOCKWASHER, 5/16
2 SCREW, Hex, M08 - 1.25 x 30mm
2 WASHER, Plain
2 CAPSCREW, Hex Hd., M08 - 1.25 x 40mm
1 CLUTCH, Electric
1 LOCKWASHER, 7/16
1 CAPSCREW, Hex, 7/16-20 x 3-1/4
1 PIPE, Exhaust
1 CLAMP, Muffler
1 CARRIAGE BOLT, 5/16-18 x 3-1/4
4 WASHER, 5/16
2 NUT, Hex, 5/16-18
1 NUT, Speed, 5/16-18
1 MUFFLER ASSEM.
1 SUPPORT, Muffler
3 SCREW, Hex, Taptite, 5/16-18 x 1/2
1 AIR DUCT, Bottom
1 SHIELD, Muffler
4 SCREW, Hex, Thd. Form, #10-16 x 3/8
1 WASHER, Plain, 5/16
1 LOCKWASHER, Internal Tooth, 5/16
1 WASHER, Hex
1 CAPSCREW, Hex, 5/16-18
1692910 14HP, ZT Rider
1692911 16HP, ZT Rider
1693140 14HP, ZT Rider (Export)
1693143 16HP, ZT Rider (Export)
DESCRIPTION
1693286 14HP, ZT Rider
1693288 16HP, ZT Rider
1693290 14HP, ZT Rider (Export)
1693292 16HP, ZT Rider (Export)
9
1693296 14HP, ZT Rider
1693298 16HP, ZT Rider
1693300 14HP, ZT Rider
1693302 16HP, ZT Rider
