- Page 1 SHINDAIWA OWNER’S/OPERATOR’S MANUAL LE231/EVC LAWN EDGER LE231 Minimize the risk of injury to yourself and others! Read this manual and familiarize yourself with the contents. Always wear eye and hearing protection WARNING! when operating this unit. Part Number 62719-94310 Rev. 11/06...
-
Page 2: Table Of Contents
2-cycle engine technology, delivering exceptionally high power with remarkably low displacement and weight. As an owner/operator, you’ll soon discover for yourself why Shindaiwa is simply in a class by itself! IMPORTANT! The information contained in this owner's/ operator's manual describes units available at the time of publication. - Page 3 WARNING! Minimize the Risk of Fire NEVER smoke or light fires near the trimmer or edger. ALWAYS stop the engine and allow it to cool before refueling. Avoid overfill- ing and wipe off any fuel that may have spilled.
- Page 4 Make sure all information labels are undamaged and readable. Immediately replace damaged or missing information labels. New labels are available from your local authorized Shindaiwa dealer. Make sure bystanders or observers outside the 50-foot “danger zone” wear eye protection. Reduce the risk of bystanders being struck by flying debris.
-
Page 5: Product Description
Maximum Power ... 1.1 HP/0.8 kW @ 7500 RPM (min Fuel/oil Ratio ... 50:1 with ISO-L-EGD or JASO FC class 2-cycle Mixing Oil Shindaiwa ONE is a registered JASO FC classified oil and also meets or exceeds ISO-L-EGD performance requirements. Fuel Tank Capacity ... 22.7 oz./670 ml Carburetor Type ...Walbro WYL-122, diaphragm-type... -
Page 6: Assembly
Driveshaft/Powerhead Connect the Outer Tube to the Powerhead. 1. Place the powerhead on a clean, flat sur- face, spark plug facing up. See Figure 5. Tube Clamp Wrench Figure 5 2. Use the 4 mm hex wrench to loosen the tube clamp screw. - Page 7 Throttle Linkage and Ignition Leads Assemble and Adjust the Throttle Cable. 1. Insert the throttle cable housing into the notch on the fan cover, and clamp the black wire’s connector between the fan cover and the cable outer adjuster nut. See Figure 10.
-
Page 8: Engine Fuel
Mixed with 50:1 Shindaiwa ISO-L-EGD or JASO FC class 2-cycle mixing oil at a gasoline/ratio of 50:1 (1 gallon of gaso- line to 2.6 ozs mixing oil). Shindaiwa One meets or exceeds these requirements. Examples of 50:1 mixing quantities ... -
Page 9: Starting The Engine
Starting the Engine IMPORTANT! Engine ignition is controlled by a two position switch mounted on the throttle housing labeled, “I” for ON or START and “O” for OFF or STOP. Figure 14 1. Slide the ignition switch to the “I” posi- tion (engine ON). -
Page 10: Adjusting Engine Idle
Shindaiwa dealer for inspection. Use only authorized Shindaiwa parts and accessories with your Shindaiwa trimmer. Do not make modifications to your unit without the written approval of Shindaiwa Inc. -
Page 11: Maintenance
NOTE: Guide wheel adjustment is also required to compensate for blade wear. WARNING! Use only Shindaiwa replacement edger blades. Edger Blades Check the edger blades condition frequent- ly. If an edger blade’s performance changes suddenly, stop the engine and check the blade for cracks or other damage. - Page 12 Daily Maintenance Prior to each work day, perform the following: Check for loose or missing screws or components. Make sure the tool and cut- ting attachment are securely fastened. Check the entire unit for leaking fuel or grease. 10-Hour Maintenance Every 10 hours of operation (more frequently in dusty or dirty conditions):...
- Page 13 Remove the filler plug from the side of the gearcase and press new grease into the gearcase until grease is pushed out. Use only lithium-base grease such as Shindaiwa Gear Case Lubricant or equivalent. See Figure 25. Grease Grease Output...
-
Page 14: Long Term Storage
135-Hour Maintenance Ever y 135 hours of operation, remove and clean the muffler. WARNING! Never operate the machine with a damaged or missing muffler or spark arrester! Operating with missing or damaged exhaust components is a fire hazard and could also damage your hearing. -
Page 15: Troubleshooting Guide
What To Check Does the engine crank? Good compression? Does the tank contain fresh fuel of the proper grade? Is fuel visible and moving in the return line when priming? Is there spark at the spark plug wire terminal? Check the spark plug. What To Check Is the engine overheating? Engine is rough at all speeds. - Page 16 Symptom Poor acceleration. Engine stops abruptly. Engine difficult to shut off. Cutting attachment rotates at engine idle. Excessive vibration. Cutting attachment will not rotate. ADDITIONAL PROBLEMS Possible Cause Clogged air cleaner element. Clogged fuel filter. Lean fuel/air mixture. Idle speed set too low. Switch turned off.
-
Page 17: Emission System Warranty
You are responsible for presenting your small off-road engine to an authorized Shindaiwa Dealer as soon as a problem ex- ists. The warranty repairs should be completed in a reasonable amount of time, not to exceed 30 days. - Page 18 NOTES...
- Page 19 NOTES...
- Page 20 Fax: 503 692-6696 www.shindaiwa.com Shindaiwa Corporation Head Office: 6-2-11, Ozuka-Nishi Asaminami-Ku, Hiroshima 731-3167, Japan Telephone: 81-82-849-2220 Fax: 81-82-849-2481 ©2006 Shindaiwa, Inc. Part Number 62719-94310 Revision 11/06 Shindaiwa is a registered trademark of Shindaiwa, Inc. Specifications subject to change without notice.
