IMPORTANT:
If you are installing an LSP5GP8P0 (JG314A) interface card, make sure the rack depth is 800 mm (31.50
•
in) or 1000 mm (39.37 in). This card adds 69.75 mm (2.75 in) to the chassis depth (see
addition to the clearance required for installing transceiver modules and cables.
On the A5500-24G-4SFP HI (2 slots) switch, you can install the LSP5GP8P0 (JG314A) and LSP5GT8P
•
(JG313A) cards only in SLOT1.
To install an interface card in an interface card slot:
Wear an ESD-preventive wrist strap and make sure it makes good skin contact and is well
1.
grounded.
Loosen the mounting screws on the filler panel over the interface card slot with a Phillips
2.
screwdriver and remove the filler panel.
Put away the removed filler panel for future use.
Figure 21 Removing the filler panel over an interface card slot
Hold the captive screws on the front panel of the interface card, and gently push the interface card
3.
in along the slot guide rails until the interface card is in close contact with the switch chassis (see
callout 1 in Figure
Tighten the captive screws with a Phillips screwdriver to secure the interface card in the slot (see
4.
callout 2 in Figure
22.)
22).
18
Figure 24) in
