- Page 1 TruVision IP Compact PTZ Camera Installation Guide P/N 1073406-EN • REV C • ISS 23MAY18...
- Page 2 Copyright © 2018 United Technologies Corporation, Interlogix is part of UTC Climate, Controls & Security, a unit of United Technologies Corporation. All rights reserved. Trademarks and Trade names used in this document may be patents trademarks or registered trademarks of the manufacturers or vendors of the respective products.
- Page 3 undesired operation. ACMA compliance Notice! This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. Canada This Class A digital apparatus complies with CAN ICES-003 (A)/NMB-3 (A).
- Page 4 Contact For contact information and to download the latest information and manuals, tools, and firmware, go to the web site of manuals/ tools/ your region. firmware Americas: www.interlogix.com EMEA: www.firesecurityproducts.com Manuals are available in several languages. Australia/New Zealand: www.utcfs.com.au...
-
Page 5: Table Of Contents
Mounting the TVP-5101 PTZ camera 17 Mounting the TVP-5102 PTZ camera 24 Mounting the TVP-5103 PTZ camera 31 Using the camera with an Interlogix NVR or Hybrid DVR or another system 42 Using the camera with a TruVision Navigator 42... -
Page 6: Introduction
The Configuration manual is available on our web site. Contact information and manuals/tools/firmware For contact information and to download the latest manuals, tools, and firmware, go to the web site of your region. Americas: www.interlogix.com EMEA: www.firesecurityproducts.com Manuals are available in several languages. Australia/ www.utcfs.com.au... -
Page 7: Installation
Installation This section provides information on how to install the cameras. Installation environment When installing your product, consider these factors: The TVP-5101 or TVP-5103 were not designed to be mounted flat to a wall. They should be mounted to a ceiling. If mounted to a wall, the wall mount should be used. -
Page 8: Package Contents
Servicing: Do not attempt to service this camera • yourself. Any attempt to dismantle or remove the covers from this product will invalidate the warranty and may also result in serious injury. Refer all servicing to qualified service personnel. • Cleaning: Do not touch the sensor modules with fingers. - Page 9 Water joint: Provides Drill template • • water resistance to network cable connector. Installation guide CD with Configuration • • manual and TruVision Device Manager Equipment Disposal Battery Disposal sheet • • sheet Installation Guide...
- Page 10 TVP-5102 IR PTZ camera Camera Water joint: Provides • • water resistance to network cable connector. Installation guide CD with • • Configuration manual and TruVision Device Manager Equipment Disposal Battery Disposal • • sheet sheet Installation Guide...
- Page 11 TVP-5103 outdoor IR PTZ camera Camera Water joint: • • Provides water resistance to network cable connector. Drill template Screws: • • Drywall anchor 7.5 × 24.5 mm (4 pcs) Screw PA4 × 25 mm (4 pcs) Safety lanyard and 12 VDC power •...
- Page 12 Safety lanyard screw • CD with Configuration Installation guide • • manual and TruVision Device Manager Torx wrench Equipment • • Disposal sheet Battery Disposal sheet • Installation Guide...
-
Page 13: Camera Description
CAUTION: Use direct plug-in UL listed power supplies marked Class 2/CE certified or LPS (limited power source) of the required output rating as listed on the unit. CAUTION: Risk of explosion if the battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. - Page 14 Figure 2: TVP-5101 indoor IR PTZ camera 12 VDC power Ethernet RJ45 connector 1 alarm input (Yellow/Red) / 1 alarm output Power LED (Yellow/Green)/ audio Adapter plate input/output port (Pink) Installation Guide...
- Page 15 Plastic access panel area Dual function: Reset button and SD card slot WPS button (not used) Note: To reset the camera to default settings, press and hold the Reset button for 10 s and power on or reboot the camera. You can then restore the default settings, including the user name, password, IP address, port number., etc.
- Page 16 Figure 3: TVP-5102 IR PTZ camera ① ② ③ ④ ⑤ ⑥ Ethernet RJ45 connector RS-485 port Audio input (Pink)/ output 960H analog output (Purple) port 24 VAC power 2 alarm inputs (Yellow/Blue, Yellow/Orange) / 1 alarm output (White/Red) Installation Guide...
- Page 17 Figure 4: TVP-5102 IR PTZ camera – Accessing the reset button and SC card slot Remove the two Phillips SD card slot Reset button screws Note: To reset the camera to default settings, press and hold the Reset button for 10 s and power on or reboot the camera. You can then restore the default settings, including the user name, password, IP address, port number., etc.
- Page 18 Figure 5: TVP-5103 IR PTZ camera Audio input/output port 2 alarm inputs 12 VDC power supply. 2 alarm outputs Power cord not included Ground (yellow/green) Ethernet RJ45 connector Installation Guide...
-
Page 19: Ir Illuminators
Figure 6: TVP-5103 IR PTZ camera – Location of the reset button Reset button Note: To reset the camera to default settings, press and hold the Reset button for 10 s and power on or reboot the camera. You can then restore the default settings, including the user name, password, IP address, port number., etc. -
Page 20: Alarm Input And Output Connections
adjustment, and camera settings. Please refer to the camera datasheet for the standard IR range. Note: Avoid installing the IR camera in close proximity to a solid object, such as a tree or wall. The reflection will cause over-exposure and loss of detail in the field of view. Alarm input and output connections The alarm output can be used to turn on and off an external alarm device. -
Page 21: Mounting The Tvp-5101 Ptz Camera
Mounting the TVP-5101 PTZ camera Note: Make sure that the wall is strong enough to withstand more than eight times the weight of the PTZ camera and its accessories. The PTZ was not designed to be mounted flat to a wall. It should be mounted to a ceiling. - Page 22 Open View of the adapter plate when View of the adapter plate that mounted to the PTZ goes towards the PTZ Align the cable access hole on the adapter plate with the access hole in the wall mount. Install the adapter plate to the wall mount using screw B.
- Page 23 Align the PTZ camera with the adapter plate. Rotate the PTZ clockwise to secure the camera to the adapter plate. The three clips on the adapter plate lock the camera into place. Open Lock Using the supplied drill template or wall mount mounting plate, mark and drill four holes in the mounting surface.
- Page 24 Connect the corresponding cables. Install the camera assemnbly to the mounting plate by lining up the two slots in the top of the wall mount with the two metal clips at the top of the mounting plate. Push down on the wall mount/PTZ until it snaps into place. Tighten the screw at the base of the wall mount to lock it in place.
- Page 25 To mount the TVP-5101 PTZ camera on the ceiling: Note: Make sure the ceiling is strong enough to withstand more than four times the weight of the PTZ camera and its accessories. The PTZ was not designed to be mounted flat to a wall. It should be mounted to a ceiling.
- Page 26 ? 83.5 3- ? 4.5 ? 30 均布 22.48 Remove the cable slot cover (as shown) if you want to route the cable harness along the surface of the ceiling. Installation Guide...
- Page 27 Attach the adapter plate to the ceiling and secure it with the three supplied screws. Make sure that the front arrows on the drill template and adapter plate are aligned. Route the cables. Align the PTZ camera with the adapter plate. Rotate the PTZ camera clockwise to secure the PTZ to the adapter plate.
-
Page 28: Mounting The Tvp-5102 Ptz Camera
Open Lock Mounting the TVP-5102 PTZ camera Note: Make sure that the wall is strong enough to withstand more than eight times the weight of the PTZ camera and its accessories. To wall mount the TVP-5102: Refer to the Wall Mount Installation Guide for details. Attach the wall mount TVP-WMB (not included with the PTZ) to the wall by aligning the four screw holes of the mount with expansion anchors. - Page 29 Clip the safety lanyard from the wall mount to the metal loop at the top of the PTZ, as shown. Installation Guide...
- Page 30 Install the PTZ camera to the wall mount, and secure the PTZ camera using the screws enclosed with the mount. Installation Guide...
- Page 31 To corner mount the TVP-5102: Refer to the Wall Mount and Corner Mount Adapter Installation Guide for details. Mark the surface and drill four mounting holes on the surface. Route the interconnect cables prior to mounting the corner adapter. Install the PTZ corner mount adapter to the corner of a building using the four expansion anchors.
- Page 32 Install the PTZ wall mount on the corner mount adapter with four screws. Clip the safety lanyard from the wall mount to the metal loop at the top of the PTZ, as shown. Installation Guide...
- Page 33 Install the PTZ camera to the wall mount. Secure the PTZ using the screws enclosed with the wall mount. To pole mount the TVP-5102: Route the interconnect cables prior to installing the pole mount adapter. Attach the PTZ pole mount adapter to the pole using the three hose clamps.
- Page 34 Clip the safety lanyard from the wall mount to the metal loop at the top of the PTZ, as shown. Installation Guide...
-
Page 35: Mounting The Tvp-5103 Ptz Camera
Install the PTZ camera to the mount. Secure the PTZ camera using the screws enclosed with the wall mount. Mounting the TVP-5103 PTZ camera Note: Make sure that the wall is strong enough to withstand more than eight times the weight of the PTZ camera and its accessories. - Page 36 Place the metal PTZ adapter plate on the cup base wall mount. The arrow that states FRONT should be pointing away from the base of the wall mount. Using screw A, secure the adapter plate to the wall mount. Tighten screw A fully. Otherwise, the dome will not slide properly into place over the three standoffs.
- Page 37 Clip the safety lanyard on the metal tab inside of the cup base of the wall mount, as shown. Installation Guide...
- Page 38 Route the PTZ cable harness through the wall mount. If you are not using all the features/cables, you may want to tuck them behind the PTZ adapter plate to keep them out of the way so they do not interfere when you install the PTZ on the wall mount.
- Page 39 To ceiling mount the TVP-5103: Ceiling mounting without a back box The camera can be ceiling mounted to indoor and outdoor solid ceiling construction. The following are the mandatory preconditions for ceiling mounting: The thickness of the ceiling must be between 5 to 40 mm. ...
- Page 40 Attach the drill template (supplied) to the location where you want to install the PTZ camera. Make sure the front arrow points to the mounting area. Drill a cable access hole in the ceiling according to the circle on the template if you want to route the cables through the ceiling.
- Page 41 Attach the adapter plate to the ceiling and secure it with the four supplied screws. Tighten screw A fully. Otherwise, the dome will not slide properly into place over the three standoffs. The screw head will block the rotation. Make sure that the front arrows on the drill template and adapter plate are aligned.
- Page 42 Torx screw Open Lock In-ceiling mounting Notes: There must be at least 250 mm of height for in-ceiling mounting. The thickness of the ceiling must be between 5 to 40 mm. Make sure the ceiling is strong enough to withstand more ...
- Page 43 on the base of the PTZ camera and rotate the metal adapter plate counterclockwise to separate it from the PTZ camera. Cut a hole in the mounting surface using the supplied template. Installation Guide...
- Page 44 Align the cable access hole in the mounting plate with cable access in the flush mount. Install the mounting plate to the flush mount with the A screw. Tighten screw A fully. Otherwise, the dome will not slide properly into place over the three standoffs.
- Page 45 Torx screw Open Lock Remove the plastic decorative trim ring from the flush mount. It is held into place with six small magnets. Insert the camera assembly and flush mount into the mounting surface. While holding the camera and mount in place, use a Phillips screwdriver to lock the camera in place.
-
Page 46: Using The Camera With An Interlogix Nvr Or Hybrid Dvr Or Another System
Using the camera with a TruVision Navigator A camera must be connected to an Interlogix NVR or hybrid DVR to be operated by TruVision Navigator. Please refer to the TruVision Navigator user manual for instructions on operating the camera with the TruVision Navigator. - Page 47 Change the administrator password once the set-up is complete. Only authorized users should be able to modify camera settings. To access the camera online: In the web browser enter the camera’s IP address (default is 192.168.1.70). The Login dialog box appears. Enter your user name and password.
-
Page 48: Specifications
Specifications TruVision TVP-5101 indoor IR IP PTZ camera Electrical Voltage input 12 VDC, PoE (802.3af) Power consumption Max. 9 W Miscellaneous Connectors 12 VDC, Audio, Alarm In/Out, Ethernet RJ45 connector Operating temperature -10 to +50 °C (-14 to +122°F) Dimensions 125 ×... -
Page 49: Truvision Tvp-5103 Ir Ip Ptz Camera
Dimensions 185 × 330 mm (7.28 × 2.99 in.) Weight 4 kg (8.82 Ib.) Environmental rating IP66 TruVision TVP-5103 IR IP PTZ camera Electrical Voltage input 12 VDC, PoE+ (802.3at) Power consumption Max. 18 W Miscellaneous Connectors 12 VDC, Alarm In/Out, Ethernet RJ45 connector, Audio in/out Operating temperature -30 to +65 °C (-22 to 149°F) -
Page 50: Pin Definitions
Pin definitions There are eight wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and color of straight and crossover cable connection: Figure 8: Straight-through cable White/Orange White/Orange Orange Orange White-Green White-Green Blue Blue White/Blue... - Page 51 Please make sure your connected cables have the same pin assignment and color as above before deploying the cables in your network. Installation Guide...
