York MFSI Manual

York MFSI Manual

Mixed flow inline fan
Hide thumbs

Advertisement

Quick Links

Download this manual
Mixed Flow Inline Fan, Model MFSI

Advertisement

loading

Related Manuals for York MFSI

Summary of Contents for York MFSI

  • Page 1 Mixed Flow Inline Fan, Model MFSI...
  • Page 2 TABLE OF CONTENTS Introduction, Certifications & Listings Features & Benefits Options & Accessories Dimensional Data 10 Performance Data 27 Sound Data 44 Engineering Specifications...
  • Page 3 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI INTRODUCTION Fans are shown with cutaway sections to reveal interior and wheel. Actual fan models have totally enclosed sides. The YORK® by Johnson Controls MFSI, Mixed Flow Silent Air Performance & Sound Inliner fan, is a revolution in the fan industry. Its patented The outstanding air and sound performance of this fan al- design, combines the compact, high volume advantages lows it to outperform a wide range of competitors, including of axial fans with the low sound, high efficiency of tubular axial, inline centrifugal, and mixed flow fans. centrifugal fans. The outstanding air and sound performance of this fan set it apart from the competition. Its versatility al- Silent...
  • Page 4 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI FEATURES & BENEFITS Octave Band Product Type Size 8.60 73.2 1208 YORK MFSI 8.69 72.4 1476 1091 9.10 69.2 1795 1178 9.46 66.5 2232 Typical Axial 1472 9.71 64.8 2820 1950 10.91 57.6 3675 10.20 61.9...

  • Page 5: Variable Inlet Vanes

    YORK® MIXED FLOW, INLINE FAN, MODEL MFSI OPTIONS & ACCESSORIES Bearings Totally Enclosed Belt Guard Bearings shall be designed for heavy-duty service with Protective cover surrounding the moving parts, provided for a minimum L10 life of 40,000 hours for Class I fans and personnel safety, are a standard accessory for MFSI fans. 120,000 hours for Class II fans. This performance is based Available with tachometer opening where specified. High Temperature Package Standard units without a weather cover are suitable for a irstream temperatures up to 200°F. Standard units with a weather cover are suitable for airstream temperatures up to Single Row Ball Bearing 150°F. See below for applications with elevated tempera- tures, including UL Smoke Control Systems UL Smoke Control For smoke control systems, Heat and Smoke Removal configured fans are listed per UL for emergency smoke removal, referencing UL705, UL793, Industrial Risk Insurers (IRI), and Southern Building Code Congress International (SBCCI).
  • Page 6 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI FAN DATA | Horizontal Ceiling Hung - Arrangement 9, Class I & II ‘H’ (SUPPORT BRACKET MTG. C/C SEE NOTE ** SEE NOTE † DISCHARGE VIEW Notes: 1. All units equipped with “J” diameter shaft and bearings. 2. All units equipped with adjustable motor base. 3. Size 600 and up are split into front and rear sections.
  • Page 7 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI FAN DATA | Horizontal Base Mounted - Arrangement 9, Class I & II Notes: 1. All units equipped with “J” diameter shaft and bearings. (4) ‘G’ DIA. (6) ‘G’ DIA. (8) ‘G’ DIA. 2. All units equipped with adjustable motor base. MTG HOLES MTG HOLES MTG HOLES 3. Size 600 and up are split into front and rear sections.
  • Page 8 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI FAN DATA | Vertical Mounted - Arrangement 9, Class II BELT GUARD BELT GUARD BELT GUARD VIEW SHOWS STANDARD VIEW SHOWS STANDARD VIEW SHOWS STANDARD MOUNTING CLIPS, MOUNTING CLIPS, END BRACKETS, (4) WILL BE FURNISHED & MOUNTED (6) WILL BE FURNISHED &...
  • Page 9 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI FAN DATA | Vertical Roof Mounted - Arrangement 9, Class II 150 - 490 CURB CAP 542 - 660 CURB CAP Notes: 1. Dimensions should not be used for construction. Certified drawings are available upon request. DIMENSIONS - INCHES MAX. SIZE MTR. FRAME 28 5/8 20 1/4 30 3/8 1 1/4 20 3/4 5-Jan 30 3/8 213T 30 5/8 21 1/2...
  • Page 10 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 18.25 in. 2.24 sq. ft. 4.78 x RPM .18 (RPM / 1000) 215T (MAX) Fan Weight Wheel Weight Max. Wheel RPM Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 11 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 20.0 in. 2.72 sq. ft. 5.74 x RPM .29 (RPM / 1000) 215T Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 12 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 22.25 in. 3.32 sq. ft. 5.83 x RPM .43 (RPM / 1000) 286T Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 13 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 24.5 in. 4.00 sq. ft. 6.41 x RPM .69 (RPM / 1000) 286T Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 14 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 27.0 in. 4.93 sq. ft. 7.07 x RPM 1.26 (RPM / 1000) 326T Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 15 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 30.0 in. 5.98 sq. ft. 7.86 x RPM 2.66 (RPM / 1000) 326T Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 16 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 33.0 in. 7.27 sq. ft. 8.64 x RPM 4.32 (RPM / 1000) 326T 13/16 Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 17 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 36.5 in. 8.97 sq. ft. 9.55 x RPM 7.16 (RPM / 1000) 365T Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 18 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 40.25 in. 10.8 sq. ft. 10.54 x RPM 11.68 (RPM / 1000) 365T 7/16 Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 19 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 44.5 in. 13.3 sq. ft. 11.65 x RPM 19.3 (RPM / 1000) 365T Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 20 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 49.0 in. 16.1 sq. ft. 12.83 x RPM 31.26 (RPM / 1000) 365T Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 21 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 54.25 in. 19.7 sq. ft. 14.2 x RPM 52.33 (RPM / 1000) 365T 15/16 Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 22 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 60.0 in. 23.9 sq. ft. 15.71 x RPM 86.59 (RPM / 1000) 365T Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 23 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 66.0 in. 29.3 sq. ft. 17.28 x RPM 139.46 (RPM / 1000) 405T Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 24 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 73.0 in. 35.9 sq. ft. 19.11 x RPM 230.85 (RPM / 1000) 405T Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 25 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 80.75 in. 43.4 sq. ft. 21.14 x RPM 382.32 (RPM / 1000) 405T Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 26 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI Wheel Dia. Outlet Area Tip Speed (FPM) Maximum BHP Max. Motor Frame Size 89.0 in. 53.1 sq. ft. 23.3 x RPM 621.82 (RPM / 1000) 405T Fan Weight Wheel Weight Max. Wheel RPM (MAX) Class (Lbs.) (Lbs.) (Lbs. Ft. (Steel or Aluminum)
  • Page 27 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS 3409 3409 Do not select in shaded area. 3200 3200 60% WOV 60% WOV 3000 3000 70% WOV 2800 2800 70% WOV 2600 2600 7 1/2 HP 2400 2400 80% WOV...
  • Page 28 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 3111 2700 60% WOV 2500 70% WOV 2300 10 HP 2100 7 1/2 HP 80% WOV 1900 5 HP 1900 1700 3 HP 1500 90% WOV 2 HP...
  • Page 29 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 2796 2600 60% WOV 2400 10 HP 2200 70% WOV 7 1/2 HP 2000 5 HP 80% WOV 1800 1600 3 HP 1400 2 HP 90% WOV...
  • Page 30 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 2551 60% WOV 15 HP 2250 10 HP 70% WOV 2000 1850 7 1/2 HP 1700 80% WOV 5 HP 1550 1400 3 HP 1250 2 HP...
  • Page 31 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 2294 2100 60% WOV 1950 70% WOV 1800 1650 15 HP 80% WOV 1500 10 HP 1350 7 1/2 HP 1200 5 HP 90% WOV 1050 3 HP...
  • Page 32 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 20 HP 2082 15 HP 50% WOV 1900 60% WOV 10 HP 1750 70% WOV 7 1/2 HP 1600 80% WOV 1450 5 HP 1300 3 HP...
  • Page 33 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 1846 60% WOV 1700 1550 70% WOV 1400 25 HP 80% WOV 20 HP 1250 15 HP 1100 10 HP 90% WOV 7 1/2 HP 5 HP...
  • Page 34 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 1662 60% WOV 1500 70% WOV 1350 30 HP 1200 80% WOV 25 HP 1100 20 HP 1000 15 HP 90% WOV 10 HP 7 1/2 HP...
  • Page 35 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 1510 60% WOV 1350 1250 70% WOV 1150 40 HP 80% WOV 1050 30 HP 25 HP 20 HP 15 HP 90% WOV 10 HP 7 1/2 HP...
  • Page 36 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 1341 1240 60% WOV 1160 70% WOV 1080 50 HP 1000 40 HP 80% WOV 30 HP 25 HP 20 HP 15 HP 90% WOV 10 HP...
  • Page 37 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 1216 1130 60% WOV 1050 70% WOV 60 HP 50 HP 80% WOV 40 HP 30 HP 25 HP 20 HP 90% WOV 15 HP 10 HP...
  • Page 38 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 1100 1030 60% WOV 70% WOV 60 HP 80% WOV 50 HP 40 HP 30 HP 25 HP 90% WOV 20 HP 15 HP 10 HP 7 1/2 HP...
  • Page 39 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 1000 60% WOV 70% WOV 75 HP 80% WOV 60 HP 50 HP 40 HP 30 HP 90% WOV 25 HP 20 HP 15 HP 10 HP...
  • Page 40 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 60% WOV 70% WOV 100 HP 80% WOV 75 HP 60 HP 50 HP 40 HP 30 HP 90% WOV 25 HP 20 HP 15 HP 10 HP...
  • Page 41 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 60% WOV 70% WOV 125 HP 100 HP 80% WOV 75 HP 60 HP 50 HP 40 HP 90% WOV 30 HP 25 HP 20 HP 15 HP...
  • Page 42 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 60% WOV 70% WOV 150 HP 80% WOV 125 HP 100 HP 75 HP 60 HP 50 HP 90% WOV 40 HP 30 HP 25 HP 20 HP...
  • Page 43 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI SOUND POWER LEVELS SOUND POWER LEVELS 60% WOV 70% WOV 200 HP 150 HP 80% WOV 125 HP 100 HP 75 HP 60 HP 90% WOV 50 HP 40 HP 30 HP 25 HP...
  • Page 44 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI ENGINEERING SPECIFICATIONS Model MFSI Color Discharge Cap Unit Size 0 = None 0 = None 150,165, 182, 200, 222, 245, 270, 300, 00 = Standard Grey A = Discharge Cap with Fuse Link 330, 365, 402, 445, 490, 542, 600, 660, 50 = Chrome Green...
  • Page 45 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI ENGINEERING SPECIFICATIONS MFSI C = Horizontal 304 SS Furnish and install as shown on the plans YORK® by Johnson Controls MFSI D = Hinged 304 SS Inline fans of the non-overloading design and of the Arrangement 9. Unless other- E = Horizontal 316 SS wise directed, fans shall conform to the layout as shown on the drawings. F = Hinged 316 SS Fans shall be constructed of low carbon steel and painted with an approved Drain coating. Each fan shall receive a documented inspection by a qualified inspector before leaving the factory. The inspection will include the welding, dimensions, 0 = None bearings and overall workmanship. D = Drain P = Drain with Plug Performance...
  • Page 46 YORK® MIXED FLOW, INLINE FAN, MODEL MFSI ENGINEERING SPECIFICATIONS Accessories Accessories shall be provided as called for in the plans and specifications. Optional accessories include bolted access door, quick open access door, drain, variable inlet vanes with stainless steel rods, inlet companion flange, discharge companion flange, inlet screen, discharge screen, shaft seal, discharge cap, curb cap, belt tube, spark resistant construc- tion and vibration isolators. Submittals Submittals for approval of equipment shall include _________ copies of outline drawings, sound power ratings and pressure volume curves showing point of operation. Sound Power Levels Manufacturer shall provide sound power ratings in the eight octave bands. Sound power levels shall be based on AMCA Standard 301. Sound power ratings shall be in decibels, referenced to 10 watts. General Construction Housings shall be of heavy gauge steel, structurally rein- forced and suitably braced to prevent vibration or pulsa- tion, and shall be arc welded throughout. Lifting lugs shall be welded to the housing to facilitate handling of the fans. Straightening vanes shall be standard construction to assure maximum efficiency and lowest noise levels.
  • Page 48 Printed on recycled paper. Johnson Controls, the Johnson Controls logo, YORK® and Heresite® are trademarks of Johnson Controls, Inc., or its affiliates, in the United States of American and/or other countries. ©2017 Johnson Controls, Inc., P.O. Box 423, Milwaukee, WI 53201...
