Page 1 Avant d’installer et d’utiliser cet appareil, s’assurer de lire la section « Lire ces informations en premier ! » (pages 4, 28 à 30). FRANÇAIS Pour de plus amples informations, visiter le site Web de Panasonic (https://pro-av.panasonic.net/manual/en/index. html) et consulter le mode d’emploi et les instructions d’installation.
Page 2 Model number of unit manual • Adobe and Reader are either registered trademarks or ® ® AW-UE150WP trademarks of Adobe Systems Incorporated in the United States AW-UE150KP and/or other countries. AW-UE150 • The terms HDMI and HDMI High-Definition Multimedia Interface, AW-UE150WE...
Page 3: Table Of Contents
Read this first! ..................24 Accessories ..................43 Note on grounding ................24 Optional accessories ................43 Read this first! (For AW-UE150WP, AW-UE150KP) ......25 Operating precautions ................ 44 Read this first! (For AW-UE150WE, AW-UE150KE) ......26 Wireless remote control (optional accessory)........46 Lire ces informations en premier ! Parts and their functions ..............
Page 4: Installation Instructions
Panasonic modelo WV-Q105A. La utilización con otros aparatos puede causar inestabilidad y ADVERTENCIA: posibles lesiones.
Page 5: Bitte Lesen Sie Zuerst Diesen Hinweis
Um Verletzungen zu verhüten, muss dieser Apparat gemäß Diese Kamera ist nur für den Einsatz mit der mitgelieferten der Installationsanleitung sicher am Boden bzw. an der Wand Montagehalterung und der Panasonic Decken- befestigt werden. Direktmontagehalterung WV-Q105A vorgesehen. Wird die Kamera mit anderen Apparaten verwendet, kann es zu Instabilität kommen, die Verletzungen verursachen kann.
Page 6: Installation Precautions
Installation Instructions Installation precautions Panasonic does not accept any responsibility for accident or damage during installation if procedure in this manual is not followed. To installation personnel Read the “Installation Instructions” thoroughly and then perform the operation correctly and safely.
Page 7: Aw-Ue150Wp
Alternatively run each cable through its own metal conduit. Problems may result if the camera head is held or rotated. (The metal conduits must be grounded.) For AW-UE150WP, AW-UE150KP Do not attach a filter, hood, extender or other „ „...
Page 8: Before Installation
Installation Instructions Before installation Be sure to configure the switches on the connector panel and bottom of the unit before installing it. Configuring the switches after the unit is installed may prove difficult. IR ID switch settings Service switch settings The IR ID switches are located on the connector panel of the unit.
Page 9: How To Install And Connect The Unit
Installation Instructions How to install and connect the unit Be absolutely sure to read through the “Read this first!” (→ page 4) and “Installation precautions” (→ pages 6 to 7). The procedure given here is for the kind of installation where the unit is suspended from an overhead surface, but the same steps are followed for a stand-alone installation.
Page 10 Installation Instructions How to install and connect the unit (continued) Mount the mount bracket onto the installation surface. • Use the bracket mounting screws (M4, bind-head: 10 mm (13/32 inches) long) supplied with the unit. • For proper clamping torque, securely attach the screws using the specified tools. Screw Clamping torque diameter...
Page 11 Installation Instructions How to install and connect the unit (continued) Mount the unit. • Align the position of the hole for checking the positioning with the status display lamp. • Align the holes on the camera main unit used to insert the bottom panel with the protrusions on the mount bracket used for inserting the camera, push the bracket and camera firmly together, and rotate the main unit by about 20 degrees in the direction of the arrow.
Page 12 Installation Instructions How to install and connect the unit (continued) Connect the rear panel connectors. <NOTE> • Do not connect PoE cable to the RS-422 port. • When Optical output is to be used, connect the recommended optical fiber module. (→ page 49) •...
Page 13: When Using The Wv-Q105A (Optional Accessory)
Installation Instructions How to install and connect the unit (continued) When using the WV-Q105A (optional accessory) It is recommended that you provide an inspection opening or other such space for access purposes in the area near where the equipment is installed in order to facilitate installation and the wiring connections work.
Page 14: Removing The Camera
Installation Instructions Removing the camera Turn off the circuit breaker and power. Disconnect the cables. Disconnect the DC cable, LAN cable, and HDMI cable, etc. Remove the main unit mounting screw used to secure the unit and mount bracket. Push the unit (A). Turn it approximately 20 degrees away from the installed position (B), and remove it (C). Approx.
Page 15: Stand-Alone Installation (When The Mount Bracket Is Going To Be Used)
Installation Instructions Stand-alone installation (when the mount bracket is going to be used) The same steps are followed as for the kind of installation where the unit is suspended from an overhead surface (→ pages 9 to 12). Check the mounting space. <NOTE>...
Page 16 Installation Instructions Stand-alone installation (when the mount bracket is going to be used) (continued) Check the mounting. Connect the rear panel connectors. <NOTE> • Do not connect PoE cable to the RS-422 port. • When Optical output is to be used, connect the recommended optical fiber module. (→ page 49) •...
Page 17: Stand-Alone Installation (When The Mount Bracket Is Not Going To Be Used)
Installation Instructions Stand-alone installation (when the mount bracket is not going to be used) When installing the unit on a desktop Place the unit flat on the surface. <NOTE> • Install the unit in a stable location which will not be susceptible to shaking. If the unit is installed in a location which is susceptible to shaking, this will cause the unit’s images to shake in turn.
Page 18: Connections
Installation Instructions Connections Connecting an NDI|HX compatible switcher AW-UE150 AW-UE150 External DC power supply LAN cable Switching hub NDI|HX compatible switcher External DC Remote Camera Controller power supply AW-RP150 Monitor Monitor...
Page 19: Connections With A Controller (Aw-Rp150)
Installation Instructions Connections (continued) Connections with a controller (AW-RP150) Example of connection for the function for cropping 4K images to HD images „ „ AW-UE150 AW-UE150 3G SDI OUT MONI OUT External DC power supply Monitor LAN cable (Straight cable or cross cable) Max.
Page 20: System Example 1 (Serial Control)
Installation Instructions Connections (continued) System example 1 (Serial control) AW-UE150 AW-UE150 External DC power supply RS-422 connector Genlock signal generator Pan-tilt head and camera control signal (LAN straight cable) SDI video signal Monitor 1 Monitor 2 Monitor Monitor System TALLY Compact Live Switcher Accessory AW-HS50...
Page 21: System Example 2 (Ip Control)
Installation Instructions Connections (continued) System example 2 (IP control) AW-UE150 AW-UE150 External DC power supply LAN connector Genlock signal generator SDI video signal LAN cable Monitor 2 Switching hub Monitor 1 LAN cable Monitor Monitor Accessory Compact Live Switcher AC adaptor AW-HS50 External DC Remote Camera Controller...
Page 22: System Example 3 (Ip Image Transmission, Poe++)
Installation Instructions Connections (continued) System example 3 (IP image transmission, PoE++) AW-UE150 AW-UE150 connector LAN cable PoE++ compatible switching hub or PoE++ injector Personal computer...
Page 23: Appearance
Installation Instructions Appearance Unit: mm (inch) 177 (6-31/32) 86.95 (3-7/16) POWER STANDBY 182 (7-5/32) 90.9 (3-19/32) 213 (8-3/8) 219.6 (8-21/32) SERVICE LINK RS-422 3G SDI OUT G/L IN 12 V OPTICAL MONI OUT 12G SDI OUT IR ID AUDIO IN Rear panel view...
Page 24: Operating Instructions
Operating Instructions Read this first! Note on grounding • Ground the unit via the <SIGNAL GND> ground connector. IR ID AUDIO IN to ground connector on wall outlet, ground bar, etc. Ground connector...
Page 25: Read This First! (For Aw-Ue150Wp, Aw-Ue150Kp)
Operating Instructions Read this first! (For AW-UE150WP, AW-UE150KP) ENGLISH WARNING: CAUTION: • To reduce the risk of fire or electric shock, do not expose this In order to maintain adequate ventilation, do not install or place equipment to rain or moisture.
Page 26: Read This First! (For Aw-Ue150We, Aw-Ue150Ke)
Operating Instructions Read this first! (For AW-UE150WE, AW-UE150KE) ENGLISH WARNING: CAUTION: • To reduce the risk of fire or electric shock, do not expose this In order to maintain adequate ventilation, do not install or place equipment to rain or moisture. this unit in a bookcase, built-in cabinet or any other confined •...
Page 27 For more information about collection and recycling, please contact your local municipality, dealer or supplier. Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation. Manufactured by: Panasonic Corporation, Osaka, Japan Importer’s name and address of pursuant to EU rules:...
Page 28: Lire Ces Informations En Premier ! (Pour Aw-Ue150Wp, Aw-Ue150Kp)
Operating Instructions Lire ces informations en premier ! (Pour AW-UE150WP, AW-UE150KP) FRANÇAIS AVERTISSEMENT: ATTENTION: • Pour réduire les risques d’incendie ou de choc électrique, Pour maintenir une bonne ventilation, ne pas installer ni placer évitez d’exposer cet appareil à la pluie ou à l’humidité.
Page 29: Lire Ces Informations En Premier ! (Pour Aw-Ue150We, Aw-Ue150Ke)
Operating Instructions Lire ces informations en premier ! (Pour AW-UE150WE, AW-UE150KE) FRANÇAIS AVERTISSEMENT: ATTENTION: • Pour réduire les risques d’incendie ou de choc électrique, Pour maintenir une bonne ventilation, ne pas installer ni placer évitez d’exposer cet appareil à la pluie ou à l’humidité. l’appareil dans une étagère, un meuble encastré...
Page 30 Le non-respect de la réglementation relative à l’élimination des déchets est passible d’une peine d’amende. Fabriqué par : Panasonic Corporation, Osaka, Japon Nom et adresse de l’importateur en accord avec les règlements de l’Union Européenne :...
Page 31: Lea Esto Primero! (Para Aw-Ue150Wp, Aw-Ue150Kp)
Operating Instructions Lea esto primero! (Para AW-UE150WP, AW-UE150KP) ESPAÑOL ADVERTENCIA: PRECAUCIÓN: • Para reducir el riesgo de producir un incendio o recibir una Para mantener unas buenas condiciones de ventilación, no descarga eléctrica, no exponga este equipo a la lluvia ni a la instale ni ponga este aparato en una librería, mueble empotrado...
Page 32: Lea Esto Primero! (Para Aw-Ue150We, Aw-Ue150Ke)
Operating Instructions Lea esto primero! (Para AW-UE150WE, AW-UE150KE) ESPAÑOL ADVERTENCIA: PRECAUCIÓN: • Para reducir el riesgo de producir un incendio o recibir una Para mantener unas buenas condiciones de ventilación, no descarga eléctrica, no exponga este equipo a la lluvia ni a la instale ni ponga este aparato en una librería, mueble empotrado humedad.
Page 33 Puede haber sanciones por una incorrecta eliminación de este residuo, de acuerdo con la legislación nacional. Fabricado por: Panasonic Corporation, Osaka, Japón Nombre y dirección del importador conforme a las normas de la UE: Panasonic Marketing Europe GmbH...
Page 34: Bitte Lesen Sie Zuerst Diesen Hinweis! (Für Aw-Ue150We, Aw-Ue150Ke)
Operating Instructions Bitte lesen Sie zuerst diesen Hinweis! (Für AW-UE150WE, AW-UE150KE) DEUTSCH WARNUNG: VORSICHT: • Zur Reduzierung der Gefahr von Brand und elektrischem Um eine ausreichende Belüftung zu gewährleisten, dieses Schlag dieses Gerät weder Nässe noch Feuchtigkeit Gerät nicht in einem Bücherregal, Einbauschrank oder an aussetzen.
Page 35 Sie sich bitte an Ihren örtlichen Abfallentsorgungsdienstleister, Händler oder Zulieferer. Gemäß Landesvorschriften können wegen nicht ordnungsgemäßer Entsorgung dieses Abfalls Strafgelder verhängt werden. Hergestellt von: Panasonic Corporation, Osaka, Japan Name und Adresse des Importeurs gemäß EU-Bestimmungen: Panasonic Marketing Europe GmbH...
Page 36: Leggere Prima Quanto Segue
Operating Instructions Leggere prima quanto segue! (Per AW-UE150WE, AW-UE150KE) ITALIANO AVVISO: PRECAUZIONE: • Per ridurre il rischio d’incendio o di scosse, non esporre questo Per assicurare una buona ventilazione, non installare o prodotto alla pioggia o all’umidità. sistemare questo apparecchio in uno scaffale, mobile •...
Page 37 Per ulteriori informazioni su raccolta e riciclaggio, vi invitiamo a contattare il vostro comune, rivenditore o fornitore. Lo smaltimento non corretto di questi rifiuti potrebbe comportare sanzioni in accordo con la legislazione nazionale. Fabbricato da: Panasonic Corporation, Osaka, Giappone Nome e indirizzo dell'importatore in conformità con le normative UE:...
Page 38: Прочитайте Нижеследующее До Начала Эксплуатации
Operating Instructions Прочитайте нижеследующее до начала эксплуатации! РУССКИЙ (Для AW‑UE150WE, AW‑UE150KE) ОСТОРОЖНО: ВНИМАНИЕ: • Для снижения риска возникновения пожара или Для обеспечения надлежащей вентиляции не удара электрическим током не подвергайте данное устанавливайте и не размещайте данное устройство на оборудование воздействию дождя или влаги. книжном...
Page 39 Действие этого символа распространяется только на Европейский Союз. Если Вы собираетесь выбросить данный продукт, узнайте в местных органах власти или у дилера, как следует поступать с отходами такого типа. Інформація для покупця Виробник: Panasonic Corporation Панасонік Корпорейшн Адреса виробника: Kadoma, Osaka, Japan Кадома, Осака, Японія...
Page 40: Before Use
SDI, so the unit can be used flexibly in a wide range of situations as a 4K-compatible remote camera. Mac OS 10.11 Safari 11 • Connection with a Panasonic camera controller is also possible via Google Chrome Panasonic's proprietary serial communication format. For iPhone, iPad: •...
Page 41: Disclaimer Of Warranty
Panasonic does not accept any responsibility for damage of this type. https://pro-av.panasonic.net/ • Use the unit in a network secured by a firewall, etc.
Page 42: Features
The unit can also be used together with the cameras and pan-tilt supply. The maximum length of the cable between the power head unit systems currently available from Panasonic Corporation supply unit and the unit is 100 meters (328 ft). Using a cable that...
Page 43: Accessories
Operating Instructions Accessories Check that the following accessories are present and accounted for. • After removing the product from its container, dispose of the power cable cap (if supplied) and packing materials in an appropriate manner. Mount bracket for installation surface Main unit mounting screw (with flat washer, spring (Hanging/Desktop) (1) washer)
Page 44: Operating Precautions
Operating Instructions Operating precautions Shoot under the proper lighting conditions. The unit comes with the safe mode. „ „ „ „ To produce pictures with eye-pleasing colors, shoot under the The safe mode is function designed to protect the unit from damage. proper lighting conditions.
Page 45 This product includes MIT Licensed software. This product includes BSD Licensed software. For details on obtaining the source codes, visit the following website. https://panasonic.biz/cns/sav/ However, do not contact Panasonic for questions regarding obtained source codes.
Page 46: Wireless Remote Control (Optional Accessory)
Operating Instructions Wireless remote control (optional accessory) This unit can be operated by remote control using a wireless <Layout of wireless remote control signal light-sensing areas> remote control (model number: AW-RM50G) purchased separately. Check out the following points before using the wireless remote <NOTE>...
Page 47: Parts And Their Functions
Operating Instructions Parts and their functions Camera unit Mount bracket for installation surface (supplied accessory) Mount this bracket onto the installation surface, and then attach the camera main unit to the bracket. Drop-prevention wire This wire is screwed down to the bottom panel of the camera main unit.
Page 48 Operating Instructions Parts and their functions (continued) RS-422 connector <RS-422> Service switches <SERVICE> This RS-422 connector (RJ-45) is connected when exercising serial Perform switch settings before turning the unit on. control over the unit from an external device. Use a cable with the following specifications for the connection to this connector.
Page 49 Operating Instructions Parts and their functions (continued) G/L IN connector <G/L IN> • Make sure of the pin alignment of the DC output terminal of the This is the external sync signal input connector. external DC power supply and the camera DC IN connector, and This unit supports BBS (Black Burst Sync) and tri-level connect the polarity correctly.
Page 50 Operating Instructions Parts and their functions (continued) Output conditions for each video format „ „ Frequency System Format HDMI 12G SDI OUT OPTICAL 3G SDI OUT MONI OUT 1080/59.94p 2160/59.94p 2160/59.94p 2160/59.94p 2160/59.94p 1080/59.94i 1080/59.94i 1080/29.97p 1080/29.97p 2160/29.97p 2160/29.97p 2160/29.97p 2160/29.97p 1080/29.97PsF 1080/29.97PsF...
Page 51 Operating Instructions Parts and their functions (continued) IP video transmission output (multi-channel display) „ „ • When “Streaming mode” is set to “H.265 (UHD)” Settings H.265 H.264(1) H.264(2) H.264(3) H.264(4) JPEG(1) JPEG(2) JPEG(3) 3840×2160 1920×1080 Resolution — — — — 1280×720 640×360 640×360...
Page 52 Operating Instructions Parts and their functions (continued) • When “Streaming mode” is set to “H.264 (UHD)” Settings H.265 H.264(1) H.264(2) H.264(3) H.264(4) JPEG(1) JPEG(2) JPEG(3) 3840×2160 1920×1080 Resolution — — — — 1280×720 640×360 640×360 640×360 320×180 320×180 320×180 60fps 30fps 30fps 30fps...
Page 53 Operating Instructions Parts and their functions (continued) • When “Streaming mode” is set to “RTMP” Settings H.265 H.264(1) H.264(2) H.264(3) H.264(4) JPEG(1) JPEG(2) JPEG(3) 1920×1080 1920×1080 1280×720 1280×720 Resolution — — — — 640×360 640×360 640×360 320×180 320×180 320×180 60fps 30fps 30fps 30fps...
Page 54: Wireless Remote Control: Aw-Rm50G (Not Supplied)
Operating Instructions Parts and their functions (continued) CAM1 to CAM4 buttons Wireless remote control: AW-RM50G (not <CAM1> <CAM2> <CAM3> <CAM4> supplied) Selects a camera to be operated. Once a button has been selected, the unit corresponding to the selected button can be operated. SET button <SET>...
Page 55 Operating Instructions Parts and their functions (continued) Pan-tilt buttons and menu operation buttons HOME button <HOME> <4> <5> <b> <a> <M> When this is pressed for 2 seconds, the unit’s direction (panning or tilting) returns to the reference position. 1) These are used to change the unit’s direction. The unit is tilted in the up/down direction using the <4>...
Page 56: Setting The Remote Control Ids
Operating Instructions Setting the remote control IDs The wireless remote control (optional accessory) is capable of operating up to four units. IDs are used to set which units are selected when the <CAM1>, <CAM2>, <CAM3> and <CAM4> buttons on the wireless remote control have been pressed.
Page 57: Network Settings
Easy IP Setup Software. You can obtain Easy IP Setup Software (EasyIPSetup.exe) by downloading it from the following website. https://pro-av.panasonic.net/ To establish the settings for a multiple number of units, the settings must be selected for each camera involved. If the settings cannot be established using the Easy IP Setup Software, select the settings separately for the unit and personal computer on the Network setup screen [Network] of the setting menu.
Page 58: Setting The Initial Account
Operating Instructions Network settings (continued) Setting the initial account Installing the plug-in viewer software To view IP images from the unit on Windows Internet Explorer 11, the Set the initial account. "Network Camera View 4S" plug-in viewer software (ActiveX ) must be ®...
Page 59: How To Turn The Power On And Off
Operating Instructions How to turn the power on and off Turning the power on Turning the power off When performing operations from a wireless When performing operations from a wireless remote control remote control Set all the power switches of the units and devices Press one of the <CAM1>...
Page 60: Troubleshooting
• It may be necessary to upgrade the version of the controller so that controller the controller will support the unit. – – – → For details on upgrading, visit the support page on the following website. https://pro-av.panasonic.net/ Operating Instructions (PDF) → “Camera menu items” → “Pan/Tilt screen” → “Install Position”...
Page 61 Operating Instructions Troubleshooting (continued) Symptom Cause and solution Reference pages • Has a LAN cable of category 5e or above been connected to the LAN pages 20 to 22 connector for IP control <LAN LINK/ACT>? • Is the [LINK] LED of the LAN connector for IP control lit? →...
Page 62 Operating Instructions Troubleshooting (continued) Symptom Cause and solution Reference pages For Windows: • Press the [F5] key on the keyboard of the personal computer to request that the settings be acquired. – – – For Mac: • Press the [Command] + [R] key on the personal computer's keyboard to request that the settings be acquired.
Page 63 Operating Instructions Troubleshooting (continued) Symptom Cause and solution Reference pages Operating Instructions (PDF) → “Camera menu items” → “Output 5/6 screen” → “Status Lamp” • Is the [Status Lamp] setting set to [Disable]? Status display lamp does not Operating Instructions (PDF) →...
Page 64 Operating Instructions Troubleshooting (continued) Video „ „ Symptom Cause and solution Reference pages • Has the unit been connected properly to the other connected devices? pages 18 to 22 • If the system is configured in such a way that the picture is also Operating Instructions (PDF) switched when the unit to be operated is selected, has the correct unit →...
Page 65 Operating Instructions Troubleshooting (continued) Symptom Cause and solution Reference pages • This is normal operation. 1080/29.97PsF images appear → In the PsF (Progressive segmented Frame) format, an identical image – – – jerky is captured to fields 1 and 2 in order to output the same image as progressive.
Page 66 Operating Instructions Troubleshooting (continued) IP images „ „ Symptom Cause and solution Reference pages For Windows: • Is the plug-in viewer software installed? page 58 → Install the plug-in viewer software. For Windows: • If [Check for newer versions of stored pages] is not set to [Every time I visit the webpage] in the temporary Internet file settings, IP images may not appear in the live screen [Live].
Page 67 Operating Instructions Troubleshooting (continued) Symptom Cause and solution Reference pages • If the “Network Camera View 4S” plug-in viewer software is deleted in an environment where the “Network Camera View 3” plug-in viewer software is installed, display of H.264 images will become impossible. –...
Page 68 "This website wants to run the • Select [Allow]. – – – following add-on: 'WebVideo Module' from 'Panasonic System Networks Co., Ltd.'." The following message appears in the information bar. "This website wants to • Select [Install]. When the security warning window appears, click the –...
Page 69: Specifications
Operating Instructions Specifications For details on specifications, visit the Panasonic website (https://pro-av.panasonic.net/manual/en/index.html) and refer to the Operating Instructions. The symbols on this product (including the accessories) represent the following: Power requirements: 12 V DC (10.8 V to 13.2 V) 42 V to 57 V DC...
Page 70: Index
Index Numerics 3G SDI ACTIVE THRU OUT ............... Tally lamp .................... 3G SDI OUT connector ............... Tilt head ....................12G SDI OUT connector ..............Tripod screw holes ................Accessories ..................Ventilation holes .................. AUDIO IN connector ................Wireless remote control ............Camera head ..................
Page 71 MEMO...
