NOTE:
The E100/E100S/E125/E150 must be traveling up to 5kmh (3mph) before
motor will engage. Kick start up to 5kmh (3mph) while applying throttle to engage motor.
Owner's Manual
Read and understand this entire manual before riding!
This does not affect your statutory rights.
NOTE: Manual illustrations are for demonstration purposes only. Illustrations
may not reflect exact appearance of actual product. Specifications subject to
CUSTOMER SERVICE
If you have any problems with this product in
the first instance please call 0118 973 6222.
Do not return product to store unless advise to do so.
v.1_10-11_Recreation
DO NOT RETURN TO STORE!
change without notice.
Item Number:
E100 PINK
RAZE100-P
E100 RED
RAZE100-09
E100 BLACK/SILVER
RAZE100-SIL
E100S
RAZE100S
Advertisement
Related Manuals for Razor E100S
Summary of Contents for Razor E100S
- Page 1 NOTE: The E100/E100S/E125/E150 must be traveling up to 5kmh (3mph) before motor will engage. Kick start up to 5kmh (3mph) while applying throttle to engage motor. Owner’s Manual Read and understand this entire manual before riding! DO NOT RETURN TO STORE! This does not affect your statutory rights.
-
Page 2: Table Of Contents
Do not ride at night or when visibility is limited. riders are able to safely and responsibly use this product. Razor recommends that you periodically review and reinforce the information in this manual with PROPER RIDING ATTIRE younger riders, and that you inspect and maintain your children’s vehicle to... -
Page 3: Before You Begin
DO NOT USE NON- RAZOR PRODUCTS MAKE SURE POWER SWITCH IS TURNED “OFF” BEFORE CONDUCTING ANY ASSEMBLY WITH YOUR RAZOR OR MAINTENANCE PROCEDURES. ELECTRIC SCOOTER. Razor recommends assembly by an adult. Charger (Note: Charger design may vary from one shown) Charger Brake Lever... -
Page 4: Assembly And Set-Up
ASSEMBLy AND SET-UP q Attaching Handlebars Note: Make sure the cables/ wires are out of the way before inserting the stem in the fork. Adjust tension of the quick release to where you can close lever all the way to secure stem. q Inflating Tire Note: The pressurized air supplies found at gasoline... -
Page 5: Connectors/Hardware Maintenance
ASSEMBLy AND SET-UP q Charging Battery WARNING: Always Charge battery prior to use. disconnect scooter from charger before cleaning with liquid. • Initial charge time: 12 hours • Run time: Up to 40 minutes of continuous ride time • Recharge time: up to 12 hours • Average battery life: 250 charge/discharge cycles Note: If your charger does not When scooter is not in regular look like the one illustrated, use, recharge battery at least your unit has been supplied once a month until normal use is... -
Page 6: Repair And Maintenance
REPAIR AND MAINTENANCE Turn power “OFF” before conducting any maintenance procedures. q Adjusting Brakes Thread brake lever adjuster If too tight or has too much Inspect brake pads (A) for 1/4 to 1/2 turn until desired slack, loosen brake cable and proper alignment against wheel brake adjustment is attained. - Page 7 If acid comes into Disposal: Your Razor product uses sealed lead-acid batteries which must be recycled or disposed of in contact with skin or eyes, an environmentally sound manner. Do not dispose of a lead-acid battery in a fire. The battery may explode flush with cool water for at or leak.
-
Page 8: Troubleshooting Guide
Battery is old and will not accept Average battery life is 1 to 2 years depending on scooter use and full charge conditions. Replace only with a Razor replacement battery. Brakes are not adjusted Refer to adjusting the brakes instructions on page 5. - Page 9 Loose wires or connectors they are tight. doesn’t run, but other times it does Motor or electrical switch Contact your local Razor authorized service center for diagnosis and damage repair. Scooter makes loud Chain is too dry Apply a lubricant such as 3 in 1 or Tri-Flow to the chain.
-
Page 10: Electric Scooter Parts
E100 SERIES ELECTRIC SCOOTER PARTS Keep your scooter running for years with genuine Razor parts. Visit our web site or e-mail us for more information on spare part availability. (Specifications subject to change without notice.) Charger port Handlebar grip (right/left) -
Page 11: Warranty
Alberto House, Marino Way, Hogwood Lane, Finchampstead, Berkshire, RG40 4RF Copyright © 2003-2012 Razor USA LLC. All rights reserved. RAZOR and the Razor Logo Design are among the registered trademarks of Razor USA LLC in the United States and/or select foreign coun- 10/2011...
