- Page 1 INSTRUCTION MANUAL Split System Heat Pump Wall-mounted type KHS2432 KHS3632 Save This Instruction Manual Pub. OI-85464189212002 ©SANYO 2003 Ceiling-mounted type Recessed type THS2432 THS3632 THS4232 XHS2432 XHS3632 XHS4232...
-
Page 2: Features
These air conditioners are equipped with a cooling function. Details on this function are provided below; refer to these descriptions when using the air conditioner. Microprocessor Controlled Operation • The interior compartment of the remote control unit contains several features to facilitate automatic operation, and is logically displayed for easy use. -
Page 3: Table Of Contents
Contents Features... 2 Product Information ... 3 Warning Symbols... 3 Installation Location... 4 Electrical Requirements ... 4 Safety Instructions ... 4 Names of Parts ... 5 Using the Remote Control Unit ... 11 Operation with the Remote Control Unit... 13 Special Remarks ... -
Page 4: Installation Location
Otherwise there is a risk of suffocation in extreme cases. Do not turn the air conditioner on and off from the power mains switch. Use the ON/OFF operation button. Do not stick anything into the air outlet of the outdoor unit. This is dangerous because the fan is rotating at high speed. -
Page 5: Names Of Parts
Names of Parts Each air conditioner shown below consists of an indoor unit and an outdoor unit. You can control the air conditioner with the remote control unit. Ceiling-mounted type Air outlet intake Drain tube Remote Refrigerant control tubes unit... -
Page 6: Unit Display And Operation Selector
Unit Display and Operation Selector Recessed type OPERATION lamp Recessed type Operation selector ADDRESS 1. TEST RUN 2. PCB CHK(ON) 3. RCU MAIN (OFF) 4. (OFF) SERVICING ADDRERS NORM./ SWEEP switches switch HOLD button switch Air filter Ceiling-mounted type TIMER STANDBY Remote lamp... - Page 7 TIMER lamp This section picks up infrared signals from the remote control unit (transmitter). This position is for operating the air conditioner with the wireless remote control unit. The selector should normally be set in this position. Switch the selector to the OFF position if you are not going to use the air conditioner for a few days or longer.
-
Page 8: Remote Control Unit (Display)
Remote Control Unit (Display) Displayed when main unit sensor is in use (1) Operation mode AUTO... COOLING... HEATING ... FAN ... (2) Fan speed Automatic operation ... HIGH ... MEDIUM... LOW... “ROOM TEMP” is displayed when the temperature setting has not been made. -
Page 9: Remote Control Unit
Press the button to reduce the set temperature. This button is for turning the air conditioner on and off. First, press the program button to select the mode you want. Each time you press the “HH” button, the hours advance by one. - Page 10 NOTE NOTE The remote control unit sends the temperature signal to the air conditioner regularly at five minute intervals. If the signal from the remote control unit stops for more than ten minutes due to the loss of the remote control unit or other trouble, the air conditioner will switch to the temperature sensor which is built into the indoor unit and control the room temperature.
-
Page 11: Using The Remote Control Unit
Remote Control Unit The remote control unit may be operated either from a non-fixed position or from a wall-mounted position. To ensure that the air conditioner operates Installation Position correctly, DO NOT install the remote control unit in the following places: DO NOT •... - Page 12 Point the transmitter on the remote control unit at the sensor on the indoor unit when operating the remote control unit and the air conditioner. Do not place objects which may block the transmitted signals between the receiver and the remote control unit.
-
Page 13: Operation With The Remote Control Unit
NOTE operation selector of the indoor unit is in the ON position. When Automatic operation mode steps below, the air conditioner operates automatically and brings the room to the desired temperature simply by pressing the ON/OFF operation button. To stop the air conditioner, press the ON/OFF operation button again. -
Page 14: Manual Operation
ON position. If the automatic operation settings of the unit are not satisfactory, press the setting buttons below to change the settings as desired. To stop the air conditioner, press the ON/OFF operation button again. STEP 1 STEP 5... -
Page 15: Adjusting The Fan Speed
Fan Speed A. Automatic Simply set the FAN SPEED selector button to the A microcomputer in the air conditioner controls the fan speed automatically when the the difference between the room temperature and the set temperature is detected by the microcomputer which then automatically switches the fan speed to a suitable level. -
Page 16: Fan Only
Operation with the Remote Control Unit (continued) 4. Fan Only If you want to circulate air without any temperature control, follow these steps: STEP 1: Press the MODE selector button to switch to the fan mode. STEP 2: Press the ON/OFF button. STEP 3: Press the FAN SPEED selector button to select the fan speed of 5. - Page 17 A. Cooling Mode: B. Heating Mode: OI-212-17EG When the night setback mode is selected, the air conditioner automatically raises the temperature setting 2 °F when 30 minutes have passed after the selection was made, and then another 2 °F after another 30 minutes have passed, regardless of the indoor temperature when night setback was selected.
-
Page 18: Special Remarks
2. How to set the OFF time (Example) To stop the air conditioner at 11:30 pm. In case of power failure, the unit will stop. When the power is restored, the unit will restart automatically after three minutes. - Page 19 Setting the Timer (continued) 3. How to set the ON time (Example) To start operation at 7:10 am. 4. How to set a program (Example) To start operation at 7:10 am. and stop the air conditioner at for daily ON/OFF operation Present...
-
Page 20: Using The 1-Hour Off Timer
Using the 1-Hour OFF Timer 1. 1-Hour OFF Timer This function causes the unit to operate for one hour and then stop, regardless of whether the unit is on or off when this button is pressed. Setting procedure: Regardless of whether the unit is operating or stopped, press the 1 HR. TIMER button. -
Page 21: Adjusting The Airflow Direction
If you have lost the remote control unit or it is not working, follow the steps below. 1. When the air conditioner is stopped. If you want to turn on the air conditioner, switch the operation selector to STANDBY the OFF position, and then to the ON position. -
Page 22: Care And Cleaning
Care and Cleaning 1. For safety, be sure to turn the air conditioner off and also to 2. Do not pour water or spray detergent on the indoor unit to clean it. Air Intake and outlet side Clean the air intake and outlet side of the indoor unit with a vacuum cleaner (Indoor Unit) brush, or wipe them with a clean soft cloth. - Page 23 Care and Cleaning (continued) How to remove the filter Ceiling-mounted type: 1. Remove the bolt screws on the latch using a screwdriver. (After 2. Take hold of the two latches on the air intake grille and press them to 3. Take hold of the finger-hold on the air filter, first lift it and then pull it How to remove the filter Wall-mounted type 1.
-
Page 24: Troubleshooting
If your air conditioner does not work properly, first check the following points before requesting service. If it still does not work properly, contact your dealer or service center. Trouble Air conditioner does not 1. Power failure. run at all. - Page 25 SANYO FISHER COMPANY A DIVISION OF SANYO NORTH AMERICA CORPORATION 21605 Plummer Street Chatsworth, CA 91311 U.S.A. In Canada SANYO Canada Inc. 300 Applewood Crescent, Concord, Ontario, L4K 5C7, Canada...
