- Page 1 NPR 032 PE-A22 English Printed: 29.10.2018 | Doc-Nr: PUB / 5436899 / 000 / 01...
- Page 2 Printed: 29.10.2018 | Doc-Nr: PUB / 5436899 / 000 / 01...
- Page 3 NPR 032 PE-A22 Original operating instructions Printed: 29.10.2018 | Doc-Nr: PUB / 5436899 / 000 / 01...
- Page 4 Printed: 29.10.2018 | Doc-Nr: PUB / 5436899 / 000 / 01...
-
Page 5: Table Of Contents
Contents Information about the documentation ........About this documentation . -
Page 6: Information About The Documentation
Information about the documentation About this documentation • Read this documentation before initial operation or use. This is a prerequisite for safe, trouble-free handling and use of the product. • Observe the safety instructions and warnings in this documentation and on the product. •... -
Page 7: Product Information
Risk of crushing injury! Wireless data transfer Hilti Li-ion battery type series used. Observe the information given in the section headed In- tended use. Product information products are designed for professional users and only trained, authorized personnel are permitted to operate, service and maintain the products. This personnel must be specifically informed about the possible hazards. - Page 8 Personal safety ▶ Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury. ▶...
-
Page 9: Additional Safety Instructions For Crimping Tools
Crimping tools must undergo inspection by Hilti service at the latest every 15,000 crimping operations and at least once a year. Crimping jaws and rings must undergo servicing by Hilti service at least once a year. -
Page 10: Description
Description Product overview Crimping / pressing head Key ring English Printed: 29.10.2018 | Doc-Nr: PUB / 5436899 / 000 / 01... -
Page 11: Intended Use
If the LEDs of the charge state indicator flash, follow the instructions in the 'Troubleshooting' section. Items supplied Crimping / pressing tool, operating instructions. Other system products approved for use with this product can be found at your local HILTI STORE or online at: www.hilti.group Technical data NPR 032 PE-A22 Rated voltage 21.6 V... -
Page 12: Battery
However, if the power tool is used for different applications, with different accessory tools, or is poorly maintained, the data can vary. This can significantly increase exposure over the total working period. An accurate estimation of exposure should also take into account the times when the tool is switched off, or when it is running but not actually being used for a job. -
Page 13: Inserting The Battery
Inserting the battery CAUTION Risk of injury! A falling battery presents a risk of injury. ▶ Take care to ensure that the battery is inserted correctly. 1. Push the battery into the product's battery holder until it engages with an audible click. 2. -
Page 14: Extending The Stroke
1. Fit the crimping / pressing jaws. 2. Insert the battery. 3. Press and hold down the control switch until the piston is just short of the crimping jaws. 4. Release the control switch. ➥ The piston stops. 5. Press the pin on the tubular guard. 6. -
Page 15: Position/Stroke Table
5.5.3 Position/stroke table Pos. Stroke Application 40 mm 12.0 mm …66.7 mm (with NPR PS M & NPR PR M) 16.0 mm …75.0 mm (with NPR PS G & NPR PR G) 12.0 mm …108.0 mm (with NPR PS V & NPR PR V) 12.0 mm …63.0 mm (with NPR PS TH &... -
Page 16: Removing The Crimping / Pressing Jaws
Removing the crimping / pressing jaws WARNING Risk of injury! Unintentional starting. ▶ Remove the battery before fitting, changing or removing the crimping / pressing jaws. 1. Remove the battery and rotate the crimping / pressing head into the outset position. 2. -
Page 17: Crimping / Pressing
• Do not operate the product if signs of damage are found or if parts malfunction. Have it repaired immediately by Hilti Service. • After cleaning and maintenance, fit all guards or protective devices and check that they function correctly. -
Page 18: Transport And Storage Of Cordless Tools
To help ensure safe and reliable operation, use only genuine Hilti spare parts and consumables. Spare parts, consumables and accessories approved by Hilti for use with the product can be found at your local Hilti Store or online at: www.hilti.group. -
Page 19: The Crimping / Pressing Tool Is In Working Order
▶ Cover the terminals with a non-conductive material (such as electrical tape) to prevent short circuiting. ▶ Dispose of your battery out of the reach of children. ▶ Dispose of the battery at your Hilti Store, or consult your local governmental garbage disposal or public health and safety resources for disposal instructions. - Page 20 English Printed: 29.10.2018 | Doc-Nr: PUB / 5436899 / 000 / 01...
- Page 21 Printed: 29.10.2018 | Doc-Nr: PUB / 5436899 / 000 / 01...
- Page 22 Hilti = registered trademark of Hilti Corp., Schaan 20181009 Printed: 29.10.2018 | Doc-Nr: PUB / 5436899 / 000 / 01...
