Page 1: User Manual
Refrigerator user manual English imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/global/register... -
Page 2: Key Features Of Refrigerator
KEy fEaturEs of your nEw rEfrigErator Your Samsung Side-By-Side Refrigerator comes equipped with many space-saving, innovative storage and energy-efficient features. • twin Cooling Plus™ By monitoring the states of the freezer and the fridge compartments on a real... -
Page 3: Safety Information
It is recommended that this symbol be handled by service man. These warning signs are here to prevent injury to you and others. Please follow them explicitly. After reading this section, keep it in a safe place for future reference. • This refrigerator must be properly installed and located in accordance with the manual before it is used. • Use this appliance only for its intended purpose as described in this instruction manual. - Page 4 - Otherwise, there is a risk of electric shock. sEVErE warning signs • Do not install the refrigerator in a damp place or place where it may come in contact with water. - Deteriorated insulation of electrical parts may cause an electric shock or fire.
- Page 5 • Do not touch the inside walls of the freezer or products stored in the freezer with wet hands. - This may cause frostbite. • If the refrigerator is not to be used for a long period of time, pull out the power plug. - Deterioration in the power cord insulation may cause fire.
- Page 6 In the event of a power failure, call the local office of your Electricity Company and ask how long it is going to last. CAUTION Most power failures that are corrected in an hour or two will not affect your refrigerator temperatures. However, you should minimize the number of door openings while the power is off.
- Page 7 - Do not put any newly introduced food for freezing near to already frozen food. • There is no need to disconnect the refrigerator from the power supply if you will be away for less than three weeks. But, remove all the food if you are going away for the three weeks or more.
-
Page 8: Table Of Contents
RefRIGeRATOR OPeRATING The sAMsUNG sIDe-by-sIDe RefRIGeRATOR TROUbleshOOTING _ contents Getting ready to install the refrigerator Setting up the refrigerator doors Levelling the refrigerator Making minor adjustments to the doors Checking the water dispenser line Installing the water dispenser line Setting up the refrigerator... -
Page 9: Getting Ready To Install The Refrigerator
Congratulations on the purchase of your Samsung Side-By-Side Refrigerator. We hope you will enjoy the many state-of-the-art features and efficiencies that this new appliance has to offer. Selecting the best location for the refrigerator • Select a location with easy access to the water supply. -
Page 10: Before Using Icemaker
First things first! Make sure that you can easily move your refrigerator to its final location by measuring doorways (both width and height), thresholds, ceilings, stairways, etc. The following chart details the exact height and depth. MODel Width Dimension(mm) Depth Height • Allow clearance to the right, left, back and top when installing. -
Page 11: Setting Up The Refrigerator Doors
Doors If your entrance won’t allow the refrigerator to pass easily through it, you can remove the doors. Removing the Front Leg Cover First, open both the freezer and refrigerator doors, and then take off the front leg cover by turning the three screws counter-clockwise. -
Page 12: Removing The Freezer Door
. Be careful that the door does not fall on you as you are removing it by carefully lifting the door straight up from the bracket using a screwdriver, and Be careful not to miss the parts of refrigerator. Be careful not to pinch the water tubing and wire harness on the door. -
Page 13: Removing The Fridge Door
Fixing the Doors Fix the Doors by assembling 2 screws as shown after finishing all operations. using a screwdriver. by turning counter-clockwise, and take Be careful not to miss the parts of refrigerator. by lifting the door by gently setting up _1... -
Page 14: Levelling The Refrigerator
LEVELLing thE rEfrigErator Now that the doors are back on the refrigerator, you want to make sure the refrigerator is level so that you can make final adjustments. If the refrigerator is not level, it will not be possible to get the doors perfectly even. -
Page 15: Making Minor Adjustments To The Doors
MaKing Minor aDjustMEnts to thE Doors Remember, a levelling refrigerator is necessary for getting the doors perfectly even. If you need help, review the previous section on levelling the refrigerator. In the case of the process to correct the imbalance is the same. Open the doors and adjust them, one at a time, as follows: 1. Unscrew the nut... -
Page 16: Checking The Water Dispenser Line
ChECKing thE watEr DisPEnsEr LinE A water dispenser is just one of the helpful features on your new Samsung refrigerator. To help promote better health, the Samsung water filter removes unwanted particles from your water. However, it does not sterilize or destroy microorganisms. You will need to purchase a water purifying system to do that. -
Page 17: Installing The Water Dispenser Line
Before being used, the leakage in these places should be examined CAUTION • Samsung Warranty does not cover WATER LINE INSTALLATION. • It’ll be done at customer’s charge unless the retail price includes installation cost. - Page 18 . Additional flushing may be required in some households. . Open the refrigerator door and make sure there are no water leaks coming from the water filter. A newly installed water filter cartridge may cause water to briefly spurt from the water dispenser.
-
Page 19: Setting Up The Refrigerator
Now that you have your new refrigerator installed and in place, you are ready to set up and enjoy the full features and functions of the appliance. By completing the following steps, your refrigerator should be fully operational. If not, first check the power supply and electricity source or try the troubleshooting section at the back of this user guide. -
Page 20: Operating The Refrigerator
If you are going on vacation or business trip or you do not need to use the refrigerator, press and hold this button for 3 seconds. The temperature in the fridge will be around 15°C and the freezer will work normally. -
Page 21: Using The Digital Display
This icon will light up when you activate the “Vacation” feature. If you are going on vacation or business trip or you do not need to use the refrigerator, press and hold the Child Lock button for 3 seconds. The temperature in the fridge will be around 15°C and the freezer will work normally. -
Page 22: Controlling The Temperature
The temperature of the freezer or the refrigerator may rise from opening the doors too frequently, or if a large amount of warm or hot food is placed in either side. This may cause the digital display to blink. Once the freezer and refrigerator return to their normal set temperatures the blinking will stop. -
Page 23: Using The Ice And Cold Water Dispenser
• Do not put your fingers, hands or any other unsuitable objects in the chute or ice-maker bucket. - It may result in personal injury or material damage. WARNING • Use only the ice maker provided with the refrigerator. • The water supply to this refrigerator must only be installed/connected by a suitably qualified person and connect to a potable water supply only. -
Page 24: Storing Food
The Samsung Side-By-Side Refrigerator has been designed to provide you with maximum spacesaving features and functions. Here are some of the customized compartments we have created to keep your food fresher, longer. Remember, in order to prevent odor penetration to the ice, stored food should be wrapped securely and as airtight as possible. -
Page 25: Storing Food In The Freezer
Bottles should be stored tightly together so that they do not tip and fall out when the refrigerator door is opened. • If you plan to go away for a significant time, empty the refrigerator and turn it off. Wipe the excess moisture from the inside of the appliance and leave the doors open. This helps keep WARNING odor and mold from developing. -
Page 26: Using The Coolselect Zone™ Drawer (Optional
When “Cool” is selected, the temperature in the CoolSelect Zone™ Drawer will be the same as the overall temperature setting of the refrigerator. The drawer digital panel shows the same temperature as that of the refrigerator display panel. Since the “Cool” function mimics the refrigerator temperature, you have extra general storage space. -
Page 27: Removing The Freezer/Fridge Accessories
SAMSUNG side-by-side refrigerator rEMoVing thE frEEZEr/friDgE aCCEssoriEs Cleaning and rearranging the interior of the freezer is a snap. 1. shelves (freezer/fridge) Remove the shelf by pulling the shelf out to the hole point as shown at the right figure. And then remove it by turning and lifting it up. -
Page 28: Cleaning The Refrigerator
CLEaning thE rEfrigErator Caring for your Samsung Side-By-Side Refrigerator prolongs the life of your appliance and helps keep it odor and germ-free. Cleaning the Interior Clean the inside walls and accessories with a mild detergent and then wipe dry with a soft cloth. You can remove the drawers and shelves for a more thorough cleaning. -
Page 29: Changing The Interior Lights
If you experience difficulty when changing the light, contact your service center. Changing the LED Type Lighting Do not disassemble or replace the LED type Lighting. To change the LED Type Lighting contact Samsung service center or your authorized CAUTION Samsung dealer. -
Page 30: Using The Doors
To order more water filter cartridges, contact your authorized Samsung dealer. using thE Doors The refrigerator doors are equipped with a door opening and closing feature that ensures that the doors close all the way and are securely sealed. After opening beyond a certain point, the door will “catch” and remain open. When the door is ajar ahead of the catch that allows it to stay open, it will close automatically. -
Page 31: Troubleshooting
Try setting it to a lower temperature. • Is the refrigerator in direct sunlight or located too near a heat source? • Is the back of the refrigerator too close to the wall and therefore keeping air from circulating? • Is the temperature control on the display panel set to the correct... - Page 32 circuit diagram...
- Page 33 memo...
- Page 34 memo...
- Page 35 memo...
