PDP-MONITOR
(P
D
P
)
LASMA
ISPLAY
ANEL
PPM42S3
PPM50H3
PPM63H3
Owner's Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
Intended for Commercial Use and Operation
ON-SCREEN MENUS
P
I
P
(PIP)
ICTURE
N
ICTURE

VIDEO WALL

MDC
(M
D
C
)
ULTIPLE
ISPLAY
ONTROL

Advertisement

Table of Contents
loading

Related Manuals for Samsung PPM 42S3

Summary of Contents for Samsung PPM 42S3

  • Page 1: Video Wall

    BN68-00457B-01_ENG 2003.10.23 3:20 PM Page 1 PDP-MONITOR LASMA ISPLAY ANEL PPM42S3 PPM50H3 PPM63H3 Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. Intended for Commercial Use and Operation ON-SCREEN MENUS (PIP) ICTURE ICTURE VIDEO WALL ULTIPLE...

  • Page 2: Warning! Important Safety Instructions

    BN68-00457B-01_ENG 2003.10.23 Thank you for choosing Samsung! Your new Samsung product represents the latest in PDP technology. We designed it with easy-to-use on-screen menus, making it one of the best products in its class. We are proud to offer you a product that will provide convenient,...

  • Page 3: Important Safety Informations (Ul1492)

    BN68-00457B-01_ENG 2003.10.23 3:20 PM Page 3 Important Safety Informations (UL1492) Read all safety and operating instructions before operating your PDP. Keep the safety and operating instructions for future reference. Heed all warnings on the PDP and in the operating instructions. Follow all operating and use instructions.
  • Page 4 BN68-00457B-01_ENG 2003.10.23 3:20 PM Page 4 Important Safety Informations (UL1492) (continued) Avoid overhead power lines. An outside antenna system should not be placed in the vicinity of overhead power lines or other electric light or power circuits or where it can fall into such power lines or circuits.

  • Page 5: Important Safety Informations (Ul6500)

    BN68-00457B-01_ENG 2003.10.23 3:20 PM Page 5 Important Safety Instructions (UL6500) Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with dry cloth. Do not block any ventilation openings, Install in accordance with the manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, or other apparatus (including amplifiers) that produce heat.

  • Page 6: Fcc Information

    004-000-00345-4 . The party responsible for product compliance: SAMSUNG ELECTRONICS CO., LTD America QA Lab of Samsung 3351 Michelson Drive, Suite #290, Irvine, CA92612 USA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 7: Important Warranty Information Regarding Pdp Format Viewing

    Be careful in the selection and duration of PDP formats used for viewing. Uneven PDP aging as a result of format selection and use, as well as burned-in images, are not covered by your Samsung limited warranty.

  • Page 8: User Instructions

    BN68-00457B-01_ENG 2003.10.23 User Instructions Screen Image retention Do not display a still image (such as on a video game or when hooking up a PC to this PDP) on the plasma display panel for more than 2 hours as it can cause screen image retention. This image retention is also known as “screen burn”.

  • Page 9: Wiring The Mains Power Supply Plug (Uk Only)

    BN68-00457B-01_ENG 2003.10.23 Wiring the Mains Power Supply Plug (UK Only) IMPORTANT NOTICE The mains lead on this equipment is supplied with a moulded plug incorporating a fuse. The value of the fuse is indicated on the pin face of the plug and, if it requires replacing, a fuse approved to BSI1362 of the same rating must be used. Never use the plug with the fuse cover omitted if the cover is detachable.

  • Page 10: Table Of Contents

    BN68-00457B-01_ENG 2003.10.23 OREWORD Warning! Important Safety Instructions ... Important Safety Informations (UL1492) ... Important Safety Informations (UL6500) ... FCC Information ... Important Warranty Information Regarding PDP Format Viewing... User Instructions... Wiring the Mains Power Supply Plug (UK Only)... ONNECTING AND Your New Plasma Display Panel...

  • Page 11: Your

    BN68-00457B-01_ENG 2003.10.23 SING ISPLAY Locking the Control buttons... Setting the MDC (Multiple Display Control) ... Protecting the Screen Burning... Setting the Multiple Screen... Displaying the PC Information ... Displaying the Setting Information... Setting and Displaying the Current Time... Switching On and Off Automatically ... Turning On the Fan ...

  • Page 12: Your New Plasma Display Panel

    BN68-00457B-01_ENG 2003.10.23 Your New Plasma Display Panel Front Panel Speaker SOURCE - External input selection. - Store your settings in the menu. - When the Main menu is displayed on screen, the Main menu is not operated with source key. MENU Menu display and exit.

  • Page 13: Rear Panel

    BN68-00457B-01_ENG 2003.10.23 Your New Plasma Display Panel The actual configuration on your PDP may be different, depending on your model. Rear Panel For further details about connection, refer to pages 41~43. a) RS232C - IN : Used for the MDC function when connecting PC or RS232C output of another PDP.

  • Page 14: Becoming Familiar With The Remote Control

    BN68-00457B-01_ENG 2003.10.23 Becoming Familiar with the Remote Control The remote control is used mainly to: Change sources and adjust the volume Set up the PDP using the on-screen menu system SOUND MODE SELECTION PICTURE MODE SELECTION NUMERIC BUTTONS PICTURE STILL VOLUME INCREASE TEMPORARY SOUND SWITCH-OFF Press it again , or - /+ button...

  • Page 15: Inserting The Batteries In The Remote Control

    BN68-00457B-01_ENG 2003.10.23 Inserting the Batteries in the Remote Control You must insert or replace the batteries in the remote control when you: Purchase the PDP Find that the remote control is no longer operating correctly Remove the cover on the rear of the remote control by pressing the symbol downwards and then pulling firmly to remove it.

  • Page 16: Installing The Display On The Wall Attachment Panel

    BN68-00457B-01_ENG 2003.10.23 Installing the Display on the Wall Attachment Panel This wall mount bracket installation guide is for the following models: WMN4230/WMN5030/WMN6330. This installation guide may be different from the PDP User’s manual. Please refer to the proper installation guide for your product. Installation Notes Do not install the PDP on any place other than vertical walls.
  • Page 17 BN68-00457B-01_ENG 2003.10.23 Installing the Display on the Wall Attachment Panel The exterior of the PDP may be different than the picture. (Assembly and installation of the plastic hanger is the same.) Remove the screws from the back of the PDP. PPM42S3 Use the screws and assemble the plastic hanger.

  • Page 18: Installing The Display Vertically

    BN68-00457B-01_ENG 2003.10.23 Installing the Display Vertically Before Using the Video Wall and the Multiple Display Contol function Please create ID for each PDP before installing them close together. It may be difficult to create IDs when operating the remote control for PDPs that are installed close to each other.

  • Page 19: Connecting Speakers

    BN68-00457B-01_ENG 2003.10.23 Connecting Speakers Remove the screws on the rear of the PDP. PPM42S3 Hang the two “T” shaped hangers on the square holes on the rear of the PDP. Tighten the PDP and the speaker bracket using the screws removed from the PDP. PPM42S3 When moving your PDP, do NOT hold the speaker connected to your PDP.
  • Page 20 BN68-00457B-01_ENG 2003.10.23 Connecting Speakers Connect the speaker audio cable to the external speaker output jack on the rear of the PDP matching the “+” and “-” ends of the cable with the diagram on the PDP. PPM42S3/PPM50H3 PPM63H3 The speakers MUST have to a power handling capability of 10 watts minimum (impedance 8Ω).

  • Page 21: Switching On And Off

    BN68-00457B-01_ENG 2003.10.23 Switching On and Off The mains lead is attached to the rear of your PDP. If you have purchased this PDP in the United Kingdom, refer to page 9 for further instructions on plug wiring. Plug the mains lead into an appropriate socket. Result: The Standby indicator on the front of the PDP lights up.

  • Page 22: Selecting The Color System (Video Or S-Video Mode)

    BN68-00457B-01_ENG 2003.10.23 Selecting the Color System Picture œ œ AUTO √ √ Color System œ œ Dynamic √ √ Mode √ √ Adjust œ œ Normal √ √ Color Tone Size Wide œ œ Off √ √ Digital NR Move Sel.

  • Page 23: Adjusting The Picture Settings

    BN68-00457B-01_ENG 2003.10.23 Adjusting the Picture Settings Your PDP has several settings which allow you to control picture quality. Press the MENU button. Result: The options available in the Picture group are displayed. Press the √ button. button to select Adjust. Press the √ button. Press the Result: The Adjust menu is displayed.

  • Page 24: Adjusting The Picture Settings (Pc Or Dvi Mode)

    BN68-00457B-01_ENG 2003.10.23 Adjusting the Picture Settings Picture œ œ Custom √ √ Mode √ √ Adjust œ œ Custom √ √ Color Tone √ √ Color Adjust Size Wide Move Enter Adjust (Custom) Contrast Brightness Sharpness Move Adjust Store Picture œ...

  • Page 25: Selecting The Picture Size

    BN68-00457B-01_ENG 2003.10.23 Selecting the Picture Size You can select the picture size which best corresponds to your viewing requirements. Press the MENU button. Result: The options available in the Picture group are displayed. Press the √ button. button to select Size. Press the √ button. Press the Select the option by pressing the œ...

  • Page 26: Freezing The Current Picture

    BN68-00457B-01_ENG 2003.10.23 Freezing the Current Picture Changing the Sound Mode Sound œ œ Custom √ √ Mode √ √ Equalizer œ œ Off √ √ Auto Volume œ œ Off √ √ Melody œ œ Off √ √ Pseudo Stereo œ...

  • Page 27: Adjusting The Sound Settings

    BN68-00457B-01_ENG 2003.10.23 Adjusting the Sound Settings The sound settings can be adjusted to suit your personal preferences. Press the MENU button. Result: The main menu is displayed. Press the button to select Sound. Result: The options available in the Sound group are displayed. Press the √...

  • Page 28: Extra Sound Settings

    BN68-00457B-01_ENG 2003.10.23 Extra Sound Settings Sound œ œ Custom √ √ Mode √ √ Equalizer œ œ Off √ √ Auto Volume œ œ Off √ √ Melody œ œ Off √ √ Pseudo Stereo œ œ Off √ √ Virtual Surround Move Sel.

  • Page 29: Adjusting The Screen Position And Scale

    BN68-00457B-01_ENG 2003.10.23 Adjusting the Screen Position and Scale Press the MENU button. Result: The main menu is displayed. Press the button to select Setup. Result: The options available in the Setup group are displayed. Press the √ button. Result: The Screen Adjust is selected. Press the √...

  • Page 30: Adjusting The Image Preferences (Pc Mode)

    BN68-00457B-01_ENG 2003.10.23 Adjusting the Image Preferences Setup √ √ Image Lock œ œ Off √ √ Key Lock √ √ Multi Control √ √ Burning Protection √ √ Video Wall √ √ Information Move Enter Image Lock √ √ Auto Adjustment √...

  • Page 31: Locking The Control Buttons

    BN68-00457B-01_ENG 2003.10.23 Locking the Control buttons This feature allows you to lock the PDP so that it cannot be switched on via the front panel. It can, however, still be switched on via the remote control. Thus, by keeping the remote control away from unauthorised users.

  • Page 32: Protecting The Screen Burning

    BN68-00457B-01_ENG 2003.10.23 Protecting the Screen Burning Setup √ √ Screen Adjust œ œ Off √ √ Key Lock √ √ Multi Control √ √ Burning Protection √ √ Video Wall Move Enter Burning Protection √ √ Pixel Shift œ œ Off √ √ Signal Pattern œ...

  • Page 33: Setting The Multiple Screen

    BN68-00457B-01_ENG 2003.10.23 Setting the Multiple Screen You can get the various display effect with many PDPs. Press the MENU button. Result: The main menu is displayed. Press the button to select Setup. Result: The options available in the Setup group are displayed. Press the √...

  • Page 34: Displaying The Pc Information

    BN68-00457B-01_ENG 2003.10.23 Displaying the PC Information Setup √ √ Image Lock œ œ Off √ √ Key Lock √ √ Multi Control √ √ Burning Protection √ √ Video Wall √ √ Information Move Enter PC Information Resolution 1024x768 V Frequency H Frequency Return Displaying the Setting Information...

  • Page 35: Setting And Displaying The Current Time

    BN68-00457B-01_ENG 2003.10.23 Setting and Displaying the Current Time You can set the clock so that the current time is displayed. You must also set the time if you wish to use the automatic on or off timers. Press the MENU button. Result: The main menu is displayed.

  • Page 36: Switching On And Off Automatically

    BN68-00457B-01_ENG 2003.10.23 Switching On and Off Automatically Time Clock 11:35 œ œ Off √ √ Clock Display œ œ Off √ √ Timer On Time Volume - - : - - On Time - - : - - Off Time œ...

  • Page 37: Turning On The Fan

    BN68-00457B-01_ENG 2003.10.23 Turning On the Fan You can use the Fan if you are anxious for the PDP. Press the MENU button. Result: The main menu is displayed. Press the button to select Function. Result: The options available in the Function group are displayed.

  • Page 38: Viewing The Picture In Picture (Pip)

    BN68-00457B-01_ENG 2003.10.23 Viewing the Picture In Picture (PIP) œ œ On √ √ œ œ Video √ √ Sel. √ √ Swap œ œ Large √ √ Size œ œ Locate œ œ Main √ √ Sound Sel. Move Sel. œ...
  • Page 39 BN68-00457B-01_ENG 2003.10.23 Viewing the Picture In Picture (PIP) Easy functions of remote control. Buttons Feature PIP ON Used to activate or deactivate the PIP feature directly. SIZE Used to select a size of sub picture (Large, Small, Double1, Double2). LOCATE Used to move the sub picture counterclockwise.

  • Page 40: Listening To The Sound Of The Sub Picture

    BN68-00457B-01_ENG 2003.10.23 Listening to the Sound of the Sub Picture œ œ On √ √ œ œ Video √ √ Sel. √ √ Swap œ œ Large √ √ Size œ œ Locate œ œ Sub √ √ Sound Sel. Move Sel.

  • Page 41: Connecting To The Audio/Video Input

    BN68-00457B-01_ENG 2003.10.23 Connecting to the Audio/Video Input The "VIDEO IN" connectors are used for the equipment with an Composite Video output, such as video game devices or video disc players. Rear of the PDP (Input) The "VIDEO OUT" connectors are used for the equipment with an Composite Video input, such as a camcorder or VCR.

  • Page 42: Connecting To The S-Video Input

    BN68-00457B-01_ENG 2003.10.23 Connecting to the S-Video Input The S-VIDEO and RCA (AUDIO-L/R) connectors are used for equipment with an S-Video output, such as a camcorder or VCR. Rear of the PDP To play picture and sound, both the S-VIDEO and RCA connectors must be used. Connecting to the DVD/DTV RECEIVER Input The “COMPONENT1 IN”...

  • Page 43: Connecting To The Dvi Input

    BN68-00457B-01_ENG 2003.10.23 Connecting to the DVI Input The “DVI IN” (video) and “AUDIO” connectors are used for equipment with a DVI output. Rear of the PDP Connecting to the RGB(PC) Input The “RGB1(PC1) IN” (or “R(Pr)/G(Y)/B(Pb)/H/V”) and “AUDIO” connectors are used for interfacing with your PC. Rear of the PDP Personal Computer 3:21 PM...

  • Page 44: Setting Up Your Pc Software (Windows Only)

    PC will probably be different, depending upon your particular version of Windows and your particular video card. But even if your actual screens look different, the same, basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) 3:21 PM...

  • Page 45: Pin Configurations

    BN68-00457B-01_ENG 2003.10.23 Pin Configurations RGB(PC) Input Connector (15Pin) RGB(PC) IN Red (R) Green (G) Blue (B) Grounding Grounding (DDC) Red (R) Grounding Green (G) Grounding Blue (B) Grounding Reserved Sync Grounding Grounding Data (DDC) Horizontal sync. Vertical sync. Clock (DDC) RS232C Connector (9Pin) Signal...

  • Page 46: Input Mode (Pc/Dvi)

    BN68-00457B-01_ENG 2003.10.23 Input Mode (PC/DVI) Both screen position and size will vary depending on the type of PC monitor and its resolution. The table below shows all of the display modes that are supported: Resolution 640 x 350 640 x 400 720 x 400 640 x 480 SVGA...

  • Page 47: Power Saver (Pc1 Mode Only)

    BN68-00457B-01_ENG 2003.10.23 Power Saver (PC1 mode only) This monitor has a built-in power management system called Power Saver. This power management system saves energy by switching your monitor into a low-power mode when it has not been used for a certain amount of time.

  • Page 48: Troubleshooting: Before Contacting Service Personnel

    BN68-00457B-01_ENG 2003.10.23 Troubleshooting: Before contacting Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of the PDP and contact your local dealer. No sound or picture...

  • Page 49: Technical Specifications

    BN68-00457B-01_ENG 2003.10.23 Technical Specifications Exterior design and product specifications are subject to change without prior notice to improve the performance of this product. This PDP applies to Class B digital device for home use. This PDP has been registered for residential use in terms of EMI. So it can be used in all areas as well as residential areas.
  • Page 50 BN68-00457B-01_ENG 2003.10.23 3:21 PM Page 50 Memo...
  • Page 51 BN68-00457B-01_ENG 2003.10.23 3:21 PM Page 51 Memo...
  • Page 52 BN68-00457B-01_ENG 2003.10.23 3:21 PM Page 52 - AFTER SALES SERVICE - Do not hesitate to contact your retailer or service agent if a change in the performance of your product indicates that a faulty condition may be present. ELECTRONICS BN68-00457B-01...
