NEC UNIVERGE SV9100 Features And Specifications page 105

answering the call by pressing the line key if Automatic Handsfree in Program 15-02-08 is
set to 0 (Pre-select).
Caller ID information outputs on the SMDR report.
ANI/DNIS can use the Caller ID tables for routing.
The system can send Caller ID digits to the voice mail if allowed in Program 14-02-10.
When more than 20 characters are set in Program 20-20: Message Setup for Non-Caller ID
Data, either the first or last character is missing (based on the entry in Program 20-19-01).
If Program 20-09-06: Class of Service Options (Incoming Call Service): Incoming Time
Display is set to 1 (On), the first line displays the time and date.
When you shut down the system, incoming history data is cleared. But you can back up the
history data by pressing Speaker +
Program 15-07-01 button (63) when enabled, removes the CPN from the setup message
when making an outbound ISDN call, this is a toggle enable/disable button and can be
used on a Call-by-Call basis. Programs 14-01-20, 14-01-21 and 20-08-15 are used for
copper trunks only and can be set only per trunk/Class of Service.
SLT users cannot block an incoming call based on the incoming Caller ID information on a
station-by-station basis.
The GCD-CP10 has 32 resources for DTMF receiving and Dial Tone detection. When a is
GPZ-BS10 installed there are 64 resources available.
When Program 10-09-01 is set to 0 (Common) and Program 14-02-10 (Caller ID) is set to 1
(Yes), all DTMF/Dial Tone Detection resources are always allocated to analog trunks, not
analog extensions. However, if Program 14-02-10 (Caller ID) is set to 0 (No), all DTMF/Dial
Tone Detection resources can be used for both analog trunks and analog extensions.
For the Caller ID List to show calls to a station that received a busy tone, Program 15-02-57
must be set to 1 (On).
When Program 15-02-57 is set to 1 (On) and Program 15-02-34 is set to 0 (Trunk), only
outside calls are shown in the Caller ID List.
Caller ID history is not updated for a phone which is in power cutting mode from the ecology
feature. Once power is restored to the phone the caller ID history will start functioning
again.
The priority for the Large LED color for incoming calls is Programs 13-04-13, then 14-01-35
or 15-23-01.
Large LED Illumination by CID (Program 13-04-13) only applies to ITL and ITZ terminals.
DTL and DTZ terminals do not support Large LED Illumination by CID.
Default Settings
None
9.
# #
*
105
