  • Page 1 SyncMaster 570DX Model SyncMaster 570DX Select Language Safety Instructions Install Programs PDF Manuals Registration Introduction Connections Using the Software Adjusting the LCD Display Troubleshooting Specifications Information Appendix © 2007 Samsung Electronics Co., Ltd. All rights reserved.
  • Page 2 Do not use a damaged or loose plug. This may cause electric shock or fire. Do not pull the plug out by the wire nor touch the plug with wet hands. This may cause electric shock or fire. Select Language Main Page Model SyncMaster 570DX Notational Power...
  • Page 3 Use only a properly grounded plug and receptacle. An improper ground may cause electric shock or equipment damage. Insert the power plug firmly so that it does not come loose. A bad connection may cause fire. Do not excessively bend the plug and wire nor place heavy objects upon them, which could cause damage.
  • Page 4 Failure to do so may cause electric shock or fire inside the LCD Display. Do not drop the LCD Display when moving it. This may cause damage to the product or the person carrying it. Install the LCD Display base in a showcase or shelf so that the end of the base does not protrude from the showcase or shelf.
  • Page 5 Failing to do so may damage the LCD Display. Do not place the LCD Display face down. This may damage the TFT-LCD surface. The installation of the bracket must be done by a qualified professional. Installing the bracket by unqualified personnel may result in injury. Always use the mounting device specified in the owner's manual.
  • Page 6 Do not use any chemicals such as wax, benzene, alcohol, thinners, insecticide, air freshener, lubricant or detergent. Contact the SAMSUNG customer care center or Customer Center interior cleaning once a year. Keep the product's interior clean. Dust which has accumulated in the interior over an extended period of time may cause a malfunction or fire.
  • Page 7 Disconnect the plug from the outlet during storms or lightning or if it is not used for a long period of time. Failure to do so may cause electric shock or fire. Do not try to move the LCD Display by pulling only the wire or the signal cable.
  • Page 8 This may cause electric shock or fire. If an alien substances or water enters the product, turn the product off, unplug the power connector from the wall outlet and contact the Service Center. When viewing a fixed screen for an extended period of time, residual image or blurriness may appear.
  • Page 9 Place the product out of children’s reach, as they could damage by hanging onto it. A falling product may cause injury to the person or even fatality. When not using the product for an extended period of time, keep the product unplugged.
  • Page 10 © 1995~2007 SAMSUNG. ALL Rights Reserved...
  • Page 11 • This stand is not for the Floor Standing Type. Manuals Quick Setup Guide Cables Other contact your dealer. to buy optional items. LCD Display Warranty Card (Not available in all locations) D-Sub Cable Power Cord Select Language Main Page Model SyncMaster 570DX Package Contents User's Guide, MDC Software...
  • Page 12 Remote Control Batteries (AAA X 2) BNC to RCA Adaptor Jack Sold separately Wall Mount KIT BNC Cable Speaker Wire Cable Front MENU Opens the on-screen menu and exits from the menu or closes the adjustment menu. Navigate buttons (Up-Down buttons) Moves from one menu item to another vertically or adjusts selected menu values.
  • Page 13 Adjust buttons (Left-Right buttons)/ Volume buttons Moves from one menu item to another horizontally or adjusts selected menu values. Adjusts the audio volume. ENTER Activates a highlighted menu item. SOURCE Switches from PC mode to Video mode. Changing the source is only allowed for external devices that are connected to the LCD Display at the time. [PC] →...
  • Page 14 POWER S/W ON [ | ] / OFF [O] Switches the LCD Display On/Off. POWER IN The power cord plugs into the LCD Display and the wall plug. REMOTE OUT/IN You can use a wired remote control by connecting it to your monitor. RS232C OUT/IN (RS232C Serial PORT) MDC(Multiple Display Control) Program Port DVI / PC IN [RGB] (PC Video Connection...
  • Page 15 Note • The number of LCD Displays that can be connected to loopout may differ depending on the cables, signal source etc. With cables where there is no degradation or signal source, up to ten LCD Displays can be connected. Note •...
  • Page 16 ON / OFF Turns the LCD Display On/Off. MAGICNET MagicNet Quick Launch Button. - This fuction does not work for this monitor. MDC Quick Launch Button. LOCK Activates or deactivates all function keys on both the remote control and the LCD Display except for the Power and LOCK buttons.
  • Page 17 TV channels provide text information services via teletext. - This fuction does not work for this monitor. MENU Opens the on-screen menu and exits from the menu screen or closes the screen adjustment menu. ENTER Activates a highlighted menu item. P.MODE When you press this button, current picture mode is displayed on the lower center of the screen.
  • Page 18 The image in the PIP window will appear on the main screen, and the main screen image will appear in the PIP window. SIZE Switches the PIP Picture Size. Rewind STOP Stop PLAY / PAUSE Play/Pause Fast forward Default Manual Change Mono © 1995~2007 SAMSUNG. ALL Rights Reserved...
  • Page 19 Mechanical Layout Monitor Head Speaker Installation VESA Bracket Wall Bracket Installation 1. Mechanical Layout 2. Monitor Head 3. Speaker...

  • Page 20: Installation Vesa Bracket

    After your order is placed, installation professionals will visit you and install the bracket. At least 2 persons are needed in order to move the LCD Monitor. Samsung is not responsible for any product damage or any injury caused by installation at customer's discretion. Dimensions...

  • Page 21: Wall Bracket Installation

    5. Wall Bracket Installation Contact a technician for installing the wall bracket. Samsung Electronics is not responsible for any damages to the product or harm to customers when the installation is done by the customer. This product is for installing on cement walls. The product may not stay in place when installed on plaster or wood.

  • Page 22: To Mount The Product On The Wall Bracket

    To mount the product on the wall bracket The shape of the product may vary depending on the model. (The assemblies of the plastic hanger and the screw are the same) Check the installation diagram and mark the drill points on the wall. Use the 5.0 mm bit to drill holes deeper than 35 mm.

  • Page 23: Wall Bracket Angle Adjustment

    1. Mount the product on the wall bracket and make sure it is properly fixed to the left and right plastic hangers. 2. Be careful when installing the product on the bracket as fingers can be caught in the holes. 3.
  • Page 24 Note • Only the supplied bolts should be used. Caution Samsung Electronics will not be responsible for damages caused by using a base other than those specified. Installing the Semi Stand To protect your product, a Cover Hole is included as an accessory. This protects the hole at the bottom of the monitor where the stand is inserted.
  • Page 25 Using a Power cord with Earth In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in correctly, before connecting the AC power. When un-wiring the earth lead, make sure to disconnect the AC power in advance.
  • Page 26 Note • Turn on both your computer and the LCD Display. Note • The DVI cable or BNC cable is optional. Contact a local Samsung Electronics Service Center Connecting Digital DVD Note • Input devices such as digital DVD are connected to the DVI IN terminal of the monitor using the DVI cable.
  • Page 27 AV input devices such as VCRs or Camcorders are connected via the AV IN [VIDEO] or AV IN [S-VIDEO] of the LCD Display using an S-VHS or BNC cable. Connect the Audio (L) and Audio (R) terminals of a VCR or Camcorders to the LCD Display 's AV AUDIO IN [L-AUDIO-R] using audio cables.
  • Page 28 Connecting a Camcorder Locate the A/V output jacks on the camcorder. They are usually found on the side or back of the camcorder. Connect a set of audio cables between the AUDIO OUTPUT jacks on the camcorder and the AV AUDIO IN [L-AUDIO-R] on the LCD Display.
  • Page 29 Note • Select Component for the connection to a DTV Set Top Box using the SOURCE button on the front of the LCD Display or on the remote control. Note • For an explanation of Component video, see your Set Top Box owner's manual. Connecting Speakers Note •...
  • Page 30 • You can control a device by allowing it to receive remote control signals from other devices through the REMOTE IN terminal. Note • Restrictions: Available only if other devices support the wired remote control I/O terminals. © 1995~2007 SAMSUNG. ALL Rights Reserved...

  • Page 31: Main Screen

    Therefore, a serial cable should be connected between the serial port on a PC and the serial port on a display. Main Screen Click Start > Program > Samsung > MDC System to start the program. Select a set to see the volume of the selected set within the slider.

  • Page 32: Port Selection

    Main Icons Remocon Safety Lock Port Selection 1. Use the main icons to switch into each screen. 2. Allows you to enable or disable the remote control signal receiving function of the display unit. 3. Set the Safety Lock function. When setting the Lock function, you can only operate power and lock buttons on the remote control and set.

  • Page 33: Power Control

    1. The Multiple Display Control is originally set to COM1. 2. If any port other than COM1 is used, COM1 through COM4 can be selected in the Port Selection Menu. 3. If the exact port name that is connected to the LCD Display using a serial cable is not selected, communication will be unavailable.
  • Page 34 Info Grid shows some basic information necessary to Power Control. (Power Status) 2) Input 3) Image Size 4) On Timer 5) Off Timer 2. Use the Select All button or Check Box to choose a display to control. Power Control allows controlling some of the functions of the selected display. 1) Power On/Off...

  • Page 35: Input Source

    - Turns the power of the selected display On/Off. 2) Volume - Controls the volume level of the selected display. It receives the volume value of the selected display from the sets and displays it in the slider. (When you cancel the selection or choose Select All, the value returns to the default value 10) (Mute On/Off) - Turns on/off the Mute function of the selected display.

  • Page 36: Image Size

    Info Grid shows some basic information necessary to Input Source Control. 1) PC - Changes the Input Source of the selected display to PC. 2) BNC - Changes the Input Source of the selected display to BNC. 3) DVI - Changes the Input Source of the selected display to DVI. 4) TV - Changes the Input Source of the selected display to TV.
  • Page 37 Info Grid shows some basic information necessary to Image Size Control. ( Power Status) - Shows the power status of the current display. 2) Image Size - Shows the current Image Size of the display in use. 3) Input - Shows the current Input Source of the display in use. 4) Info Grid displays only the displays whose Input Source is PC, BNC, DVI.
  • Page 38 Info Grid shows some basic information necessary to Image Size Control. 1) Click the Video Source tab to adjust Image Size for TV, AV, S-Video, Component. , DVI(HDCP). Click Select All or use Check Box to select a display to control. 2) Info Grid displays only the display having TV, AV, S-Video, Component or DVI(HDCP) as input source.

  • Page 39: Pip Size

    Info Grid shows some basic information necessary to Time Control. 1) Current Time - Set the current time for the selected display (PC Time). - To change the current time, first change the PC Time. 2) On Time Setup - Set the Hour, Minute, AM/PM of On Time Setup, Status, Source, Volume of the selected display. 3) Off Time Setup - Set the Hour, Minute, and AM/PM, Status for Off Time Setup of the selected display.

  • Page 40: Pip Source

    Info Grid shows some basic information necessary to PIP Size Control. 1) PIP Size - Shows the current PIP Size of the display in use. 2) OFF - Turns off the PIP of the selected display. 3) Large - Turns on the PIP of the selected display and changes the size to Large. 4) Small - Turns on the PIP of the selected display and changes the size to Small.
  • Page 41 • PIP S-Video Mode Info Grid shows some basic information necessary to PIP Source Control. 1) PIP Source - PIP Source can be controlled with turning on the LCD Display power. 2) PC - Changes the source of the PIP of the selected display to PC. 3) BNC - Changes the source of the PIP of the selected display to BNC.
  • Page 42 6) AV - Changes the source of the PIP of the selected display to AV. 7) S-Video - Changes the source of the PIP of the selected display to S-Video. 8) Component - Changes the source of the PIP of the selected display to Component. 9) Channel - Channel arrow appears when the PIP Source is TV.

  • Page 43: Picture Pc

    - Adjusts Tint of the selected display. - Available only for NT. 7) Color Tone - Adjusts the Color Tone for the selected display. 8) Color Temp - Adjusts the Color Temp for the selected display. 9) Brightness Sensor - Adjusts the Brightness Sensor for the selected display. 10) Dynamic Contrast - Adjusts the Dynamic Contrast for the selected display.
  • Page 44 - Adjusts green Color of the selected display. - Available only for NT. 6) Blue - Adjusts blue Color of the selected display. - Available only for NT. 7) Color Tone - Adjusts the Color Tone for the selected display. 8) Color Temp - Adjusts the Color Temp for the selected display.

  • Page 45: Image Lock

    - SRS TS XT Sound ON/OFF of the selected display. 6) Sound Select - Select either Main or Sub when PIP is On. The Input source of MagicNet works only on MagicNet model. The Input source of TV works only on TV model. This feature is available only for the displays whose power status is ON and if no selection is made, the factory default is displayed.
  • Page 46 1. Click on the "Maintenance" icon in the Main Icon column to display the Maintenance screen. An "Info Grid" showing several basic data items appears. 1) Maintenance - Allows the Maintenance Control function for all input sources. 2) Auto Lamp Control - Automatically adjusts the backlight of the selected display at a specified time.

  • Page 47: Video Wall

    1) Safety Screen - Eliminates the afterimages that can result when the selected display stays in Pause mode for an extended period of time. You can set the repeat cycle timer by selecting the "Interval" by hour and "Second" by second. It can be set to Scroll, Pixel, Bar and Eraser by Screen Type.

  • Page 48: Troubleshooting

    Select a display from Display Selection. The place will be set up by pressing a number in the selected mode. The MDC program supplied by Samsung supports over 5*5. 3) On / Off - Turns on/off the Video Wall function of the selected display.

  • Page 49: Settings Value Display In Multiple Display Mode

    - Check the displays to see if any of the other displays connected have the same ID. If more than one displays have the same ID, those displays are not properly detected by the program due to data conflict. - Check if the Display Set ID is a number between 0 and 16 . (Adjust using the Display menu) Note : A Display Set ID must be a value between 0 and 16 .
  • Page 50 4) AV 5) S-Video 6) Component [The direct button on the remote control is the 'SOURCE' button.] Note • PIP turns off when the LCD Display is switched to an external source. Select Language Main Page Model SyncMaster 570DX Input...
  • Page 51 When external AV devices such as VCRs or DVDs are connected to the LCD Display , PIP allows you to watch video from those devices in a small window super-imposed on the PC Video signal. (Off/On) Note • More than one PIP cannot be overlapped on screen as BNC and the component use the same terminal. 1) PIP [MENU] →...
  • Page 52 5) S-Video 6) Component Available Modes PC / BNC / DVI S-Video Component DVI-Video MagicBright™ [MENU] → [∧ / ∨] → [ENTER] → [ENTER] → [∧ / ∨] → [ENTER] MagicBright™ is a new feature providing the optimum viewing environment depending on the contents of the image you are watching.
  • Page 53 1) Contrast Adjusts the Contrast. 2) Brightness Adjusts the Brightness. Note • By adjusting the picture using the Custom function, MagicBright will change to Custom mode. Color Tone [MENU] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] The color tones can be changed.
  • Page 54 Image Lock Image Lock is used to fine-tune and get the best image by removing noise that creates unstable images with jitters and shakiness. If satisfactory results are not obtained using the Fine adjustment, use the Coarse adjustment and then use Fine again. (Available in PC, BNC mode only) 1) Coarse [MENU] →...
  • Page 55 The Size can be switched. 1) 16:9 2) 4:3 PIP Picture [MENU] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [< / >] → [ENTER] Adjusts the PIP Screen Settings.
  • Page 56 1) Dynamic 2) Standard 3) Movie 4) Custom [The direct button on the remote control is the 'P.MODE' button.] Custom [MENU] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [< / >] → [ENTER] By using the on-screen menus, the contrast and brightness can be changed to your personal preference.
  • Page 57 Brightness Sensor [MENU] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [< / >] → [ENTER] Brightness Sensor is to automatically detect distribution of inputted visual signal and adjust to create optimum brightness. 1) Off 2) On Dynamic Contrast [MENU] →...
  • Page 58 Available Modes PC / BNC / DVI S-Video Component DVI-Video Mode [MENU] → [∧ / ∨] → [ENTER] → [ENTER] → [∧ / ∨] → [ENTER] The LCD Display has a built-in high fidelity stereo amplifier. 1) Standard Selects Standard for the standard factory settings. 2) Music Selects Music when watching music videos or concerts.
  • Page 59 Auto Volume [MENU] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] Reduces the difference in volume control between broadcasters. 1) Off 2) On SRS TS XT [MENU] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] SRS TS XT is a patented SRS technology that solves the problem of playing 5.1 multichannel content over two speakers.
  • Page 60 DVI-Video Language [MENU] → [∧ / ∨] → [ENTER] → [ENTER] → [∧ / ∨] → [ENTER] You can choose from 11 languages. Note • The language chosen affects only the language of the OSD. It has no effect on any software running on the computer. Time Selects from one of 4 time settings, Clock Set, Sleep Timer, On Timer, and Off Timer.
  • Page 61 [MENU] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [MENU] The picture parameters are replaced with the factory default values. 1) On 2) Off Video Wall A Video Wall is a set of video screens connected together, so that each screen shows a part of the whole picture or where the same picture is repeated on each screen.
  • Page 62 2) Interval [MENU] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [∧ / ∨]→ [ENTER] →[∧ / ∨] → [ENTER] Determines the time interval to run the Screen Scroll operation. (1~10 Hour) The time is calculated on the basis of the power on time. By default, the time is set to 10 hours.
  • Page 63 [MENU] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [∧ / ∨]→ [ENTER] Adjusts the DVI Source. 1) PC DVI Selects PC DVI mode. 2) DTV DVI Selects DTV DVI mode. [MENU] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [∧ / ∨]→ [ENTER] Adjusts the FAN.
  • Page 64 Available Modes PC / BNC / DVI S-Video Component DVI-Video Multi Control Assigns an individual ID to the SET. 1) ID Setup [MENU] → [∧ / ∨] → [ENTER] → [∧ / ∨] → [ENTER] → [ENTER] → [0~9] Assigns distinctive IDs to the SET. 2) ID Input [MENU] →...
  • Page 65 • Resetting the password for the function key lock. Press MUTE → 1 → 8 → 6 → On. The password will be reset to '0000'. resetting the password. The remote control is required for © 1995~2007 SAMSUNG. ALL Rights Reserved...
  • Page 66 85Hz, you will see the black screen because the LCD Display does not support over 85Hz. Note • Refer to Display. Specifications > Preset Timing Modes for the resolutions or frequencies supported by the LCD Select Language Main Page Model SyncMaster 570DX Self-Test Feature Check...
  • Page 67 Do not use benzene, thinner or other flammable substances, or a wet cloth. • We recommend that a Samsung cleansing agent is used to prevent damage to the screen. Maintaining the Flat Panel Display Screen. Clean with a soft cloth (cotton flannel) smoothly.
  • Page 68 Problems related to the Screen Note • Problems related to the LCD Display screen and their solutions are listed. Problems The screen is blank and the power indicator is off. "Check Signal Cable" message. "Not Optimum Mode " message. The picture rolls vertically. The image is not clear;...
  • Page 69 Windows / Computer Manual). Windows ME/2000: Set the resolution at the Control Panel → Display → Screen Saver. Set the function in the BIOS-SETUP of the computer. (Refer to the Windows / Computer Manual). © 1995~2007 SAMSUNG. ALL Rights Reserved Q & A...

  • Page 70: Specifications

    Storage Audio Characteristics Audio Input 1 Audio Input 2 Select Language SyncMaster 570DX 57 " Diagonal (143 cm) 1251.36 mm (H) x 703.89 mm (V) 0.651 mm (H) x 0.651 mm (V) 30 ~ 81 kHz 50 ~ 85 Hz 16.7 M...
  • Page 71 Green, Blinking Amber Less than 1 W Less than 1 W (Off-mode) (Power button) ® compliant and ENERGY2000 ® Partner, SAMSUNG has determined that this ® guidelines for energy efficiency. Preset Timing Modes Vertical Pixel Clock Sync Polarity Frequency (MHz) (Hz) 70.086...
  • Page 72 75.000 31.500 85.008 36.000 56.250 36.000 60.317 40.000 72.188 50.000 75.000 49.500 85.000 56.250 60.004 65.000 70.069 75.000 75.029 78.750 85.997 94.500 75.000 108.000 60.000 108.000 60.020 108.000 75.025 135.000 16.662 85.500 59.934 138.500 © 1995~2007 SAMSUNG. ALL Rights Reserved...
  • Page 73 To prevent this, the accumulated voltage difference must be decreased. For example, the number of TFT LCD sub pixels contained in this product are 6,220,800. PRODUCT INFORMATION (Image Retention Free) Select Language Main Page Model SyncMaster 570DX For Better Display...
  • Page 74 Power Off, Screen Saver, or Power Save Mode Turn the power off for 4 hours after 20 hours in use Turn the power off for 2 hours after 12 hours in use Set the Monitor to power off with the PC Display Properties Power Scheme. Use a Screen saver if possible - Screen saver in one color or a moving image is recommended.
  • Page 75 Every 30 minutes, change the characters with movement. All area display Moving image together with Logo periodically. - Cycle: Display moving image together with Logo for 60 seconds after 4 hours in use. The best way to protect your monitor from Image retention is to turn Power off, or set your PC, or System to operate a Screen Saver program when you are not using it.
  • Page 76 . Time Interval : 1 ~ 10 hours ( Recommend : 1 ) . Time Period : 10 ~ 50 second ( Recommend : 50 ) Note • ( Please check CD's User Guide at "OSD Function", some model's will not available ) © 1995~2007 SAMSUNG. ALL Rights Reserved...
  • Page 77 Information Appendix Appendix Contact SAMSUNG WORLDWIDE Terms Correct Disposal Authority Note • If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. U.S.A CANADA MEXICO ARGENTINE BRAZIL CHILE COLOMBIA COSTA RICA...
  • Page 78 030-6227 515 3260 SAMSUNG(7267864) FRANCE (€ 0,15/min) GERMANY 01805-121213 (€ 0,14/Min) HUNGARY 06-80-SAMSUNG (7267864) ITALIA 800 SAMSUNG (7267864) LUXEMBURG 0032 (0)2 201 24 18 NETHERLANDS 0900 20 200 88 (€ 0,10/Min) NORWAY 815-56 480 POLAND 0 801 801 881 PORTUGAL...
  • Page 79 Middle East & Africa SOUTH AFRICA 0860 7267864 (SAMSUNG) 800SAMSUNG (7267864) U.A.E 8000-4726 Sync Signal Sync (Synchronized) Signals refer to the standard signals that are required to display desired colors on the LCD Display. They are divided into Vertical and Horizontal Sync Signals. These signals display normal color images by the set resolution and frequency.
  • Page 80 Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
