Panasonic WV-CF132N1E Installation Manual

Installation Guide

Color CCTV Camera
WV-CF132N1E
Model No.
WV-CF132T1E
WV-CF132N1E WV-CF132T1E
Panasonic Corporation
http://panasonic.net
Panasonic System Networks Co., Ltd.
Fukuoka, Japan
Authorised Representative in EU:
Panasonic Testing Centre
Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, Germany
© Panasonic System Networks Co., Ltd. 2014
sL0514-1054 PGQX1619YA Printed in China
All the illustrations in this manual are based on WV-CF132N1E unless the
model is specified.
Before attempting to connect or operate this product, please read these
instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.
WARNING:
• To prevent fire or electric shock hazard, do not expose this appara-
tus to rain or moisture.
• To prevent injury, this apparatus must be securely attached to the
wall/ceiling in accordance with the installation instructions.
• The connections should comply with local electrical code.
• This product has no power switch. When turning off the power,
turn off a Power Supply or remove a power cable.
• The installation shall be carried out in accordance with all applica-
ble installation rules.
Important safety instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9) Only use attachments/accessories specified by the manufacturer.
10) Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the appa-
ratus. When a cart is used, use caution when moving
the cart/apparatus combination to avoid injury from
tip-over.
11) Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
Limitation of liability
THIS PUBLICATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF
ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY,
FITNESS FOR ANY PARTICULAR PURPOSE, OR NON-INFRINGEMENT
OF THE THIRD PARTY'S RIGHT.
THIS PUBLICATION COULD INCLUDE TECHNICAL INACCURACIES OR
TYPOGRAPHICAL ERRORS. CHANGES ARE ADDED TO THE
INFORMATION HEREIN, AT ANY TIME, FOR THE IMPROVEMENTS OF
THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S).
Disclaimer of warranty
IN NO EVENT SHALL Panasonic System Networks Co., Ltd. BE LIABLE
TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR
REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES,
INCLUDING BUT NOT LIMITED TO BELOW:
(1) ANY LOSS OR DAMAGE, INCLUDING WITHOUT LIMITATION,
D I R E C T O R I N D I R E C T, S P E C I A L , C O N S E Q U E N T I A L O R
EXEMPLARY, ARISING OUT OF OR RELATING TO THE PRODUCT;
(2) ANY INCONVENIENCE, LOSS, OR DAMAGE CAUSED BY
INAPPROPRIATE USE OR NEGLIGENT OPERATION OF THE USER;
(3) ALL MALFUNCTIONS OR TROUBLES FROM UNAUTHORIZED
DISASSEMBLE, REPAIR OR MODIFICATION OF THE PRODUCT BY THE
USER, REGARDLESS OF THE CAUSE OF THE MALFUNCTION OR
TROUBLE;
(4) INCONVENIENCE OR ANY LOSS ARISING WHEN IMAGES ARE
NOT DISPLAYED, DUE TO ANY REASON OR CAUSE INCLUDING
ANY FAILURE OR PROBLEM OF THE PRODUCT;
(5) ANY PROBLEM, CONSEQUENTIAL INCONVENIENCE, OR LOSS
OR DAMAGE, ARISING OUT OF THE SYSTEM COMBINED BY THE
DEVICES OF THIRD PARTY;
(6) ANY CLAIM OR ACTION FOR DAMAGES, BROUGHT BY ANY PERSON
OR ORGANIZATION BEING A PHOTOGENIC SUBJECT, DUE TO
VIOLATION OF PRIVACY WITH THE RESULT OF THAT SURVEILLANCE-
CAMERA'S PICTURE, INCLUDING SAVED DATA, FOR SOME REASON,
BECOMES PUBLIC OR IS USED FOR ANY PURPOSE;
Preface
This product is a color CCTV camera that comes with a 1/3 type CCD. If
connected to a video monitor, this product can be used as a monitoring
system.
Features
A brand new high resolution CCD
The newly developed 976-horizontal pixel CCD can achieve the horizontal
definition 650TV line.
Noise reduction, high sensitivity
With the introduction of low noise circuit design, this product enables the
following sensitivity of minimum illumination for color images:
0.04 lx (F1.2 equivalence) (color mode), 0.02 lx (F1.2 equivalence) (black
and white mode)
Black-and-white control (D&N)
Since the image can automatically switch to the black and white mode
from the color mode in the case of low illumination, you need not change
the settings at night.
S3125A
Precautions
Refer installation work to the dealer.
Installation work requires proper technique and experience. Failure to
observe this may cause injury or damage to the product.
Be sure to consult the dealer.
Do not attempt to disassemble or modify this product.
Failure to observe this may cause fire or electric shock.
Consult the dealer for repair or inspections.
Stop operation immediately when something is wrong with this
product.
When smoke or the smell of smoke comes from this product, stop opera-
tion immediately and contact your dealer.
In this case, turn the power off immediately and contact qualified service
personnel for service.
Ensure the installation site can bear the weight of the product.
Failure to observe this may cause a drop resulting in injury.
Installation work shall be started after sufficient reinforcement.
Periodic inspections shall be conducted.
Rust on the metal parts or screws may cause the falling of the product,
thus resulting in injury.
Consult the dealer for inspections.
Do not install this product in locations subject to vibration.
Constant vibration easily leads to loose screws or nuts, which may cause
the falling of the product, thus resulting in injury.
Do not strike or give a strong shock to this product.
Failure to observe this may cause fire or injury.
Turn off the power before wiring.
Failure to observe this may cause electric shock. Short circuit or wrong wiring
may lead to a fire.
Do not put the product near inflammable gas.
Failure to observe this may cause an explosion and injury.
Avoid installing this product in locations where salt damage occurs
or corrosive gas is produced.
Otherwise the installation portion will deteriorate and a falling accident
may occur.
The screws and bolts must be tightened to the specified torque.
Loosening of mounting screws or bolts may cause a fall of the product
resulting in injury or accidents.
[Precautions for use]
The product is designed for indoor use.
This product has no power switch.
When turning off the power, turn off a power supply or remove a power cable.
To keep on using with stable performance
Do not use this product under hot and humid conditions. Failure to
observe this may cause component degradation, thus resulting in life
shortening of this product.
(Recommended temperature: +35 °C or below)
Do not expose this product to direct heat sources such as a heater, radia-
tor or an electrothermal furnace.
Handle this product with care.
Be cautious when using this product to keep it free from strong impact or
vibration.
Otherwise it may cause malfunction.
Do not touch the lens with your hands.
Otherwise the lens may be stained, thus decreasing the image quality.
Noise points on the image
This product comes with a super sensitive CCD, so noise points may
appear on the image. This is not a fault.
CCD color filter deterioration
When continuously shooting a bright light source such as a spotlight, the
color filter in the CCD may become deteriorated and this may cause dis-
coloration to the affected part. Even when changing the fixed shooting
direction after continuously shooting a spotlight for a certain period, the
discoloration may remain.
Do not expose the camera to any direct intense light source such
as a spotlight.
Blooming
The intense light source may
lead to dimming (mistiness)
Dimming
or blooming (vertical lines) of
the image.
Cleaning the product
Be sure to turn off the power before cleaning to prevent electric shock.
Do not use diluent, benzene or other volatile chemical reagents to clean
the product; otherwise it may lead to discoloration of the shell.
About synchronous mode settings
The image synchronous mode of the product is internal synchronization
(INT) only. When a Panasonic system controller is connected, set the mul-
tiplexing vertical drive (VD2) to the off status.
Precautions for installation
Panasonic assumes no responsibility for injuries or property dam-
age resulting from failures arising out of improper installation or
operation inconsistent with this documentation.
The product is designed for indoor use.
Do not expose this camera to direct sunlight for hours and do not install
the product near a heater or an air conditioner. Otherwise, it may cause
deformation, discoloration and malfunction.
Keep the product far away from water and a damp environment.
Installation position
Consult your dealer about the installation position, and be sure to select a
firm site for installation.
• Install the product on a ceiling (such as a concrete ceiling) with sufficient
strength.
• Install the main unit of the camera at the fundamental part of the build-
ing or a portion with sufficient strength.
• If a site such as a plaster board is too weak to support the total weight,
the installation position shall be sufficiently reinforced.
Do not place this product in the following places:
• Locations directly subject to direct splashing of rain or water
• Locations where a chemical agent is used such as a swimming pool
• Locations subject to moisture or oil smoke such as a kitchen or
machine shop
• Locations that have a specific environment that is subject to an inflam-
mable atmosphere
• Locations where radiation, an X-ray, a strong radio wave or a strong mag-
netic field is generated
• Locations where corrosive gas is produced, or locations where it may
be damaged by briny air such as seashores
• Locations where the temperature is beyond the range of -10 °C to +65 °C
• Locations subject to vibrations, such as on vehicles, marine vessels, or
above product lines (This product is not designed for on-vehicle use.)
• Locations subject to condensation as the result of severe changes in
temperature
Do not install the camera at a damp and dusty site
Otherwise the service life of internal parts may be shortened.
Do not install the camera at a site with high amounts of noise.
Noises may exist at a site near an air conditioner, an air freshener or a
vending machine.
Do not perform installation or wiring during thunder and lightning;
otherwise it may lead to a fire or electric shock.
Make sure to remove this product if it will no longer be used.
Do not damage the power plug or cable.
Bright
object
