TFT-LCD MONITOR SMT-170MN SMT-170MP User Guide...
Page 2
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Graphic Symbol Explanation The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated ‘dangerous voltage’...
Item 5. 6. Attachments : Do not use attachments not recommended by Samsung as they may cause hazards. 7. Water and Moisture : Do not use this monitor near water for example,...
Page 4
The monitor may fall, causing serious injury to a child or adult, and serious damage to the appliance. Use only with a cart, stand, tripod. bracket, or table recommended by Samsung, or sold with the monitor. Any mounting of the monitor should follow Samsung’s instructions, and should use a mounting accessory...
Page 5
13. Lightning : For added protection for this monitor during a lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the cable system. This will prevent damage to the monitor due to lightning and power-line surges. 14.
18. Replacement Parts : When replacement parts are required, be sure the service technician has used replacement parts specified by Samsung or have the same characteristics as the original parts. Unauthorized substitutions may result in fire, electric shock or other hazards.
Page 7
Information to user Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Page 8
The party responsible for product compliance: SAMSUNG ELECTRONICS CO., LTD. America QA Lab of Samsung 3351 Michelson Drive, Suite #290, Irvine, CA92612 USA IC Compliance Notice This Class (A) digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
Unpacking Remove the package cover and place the product on a flat and secure surface or in the installation location. Check whether all the following devices and accessories are included with the main system. TFT-LCD Monitor Remote Control/ User’s Guide Batteries Power Cord AC Adapter...
Names and Functions of Parts Front Panel A. Auto Use this button to auto adjustment direct access. B. Exit Use this button to Exit the active menu or the OSD. (Adjust) These buttons allow you to highlight and adjust items in the menu. C-.
Remote Control A. POWER SAVE Changes to Power Save mode. B. ONEAF Performs Auto Focus for the selected camera once in the present status. Only the remote control has this button. It is only available when a camera (SOC-420(P), or SOC- 920(P), sold separately) is connected with the product.
Page 13
K. TALK Communicates with the doorbell in duplex mode. L. Number Key(0 ~ 9) Press the number of the channel to watch it in full screen mode. Or, press the SYSTEM ID button and then press the number of the system you want to control with the remote control.
Rear Panel A. 14V DC Connect the power cord for your monitor to the power port on the back of the monitor. B. SIGNAL (RJ-45) MUX input port. C. DVR DVR input terminals. Eng-14...
Attaching a Base Attaching a base NOTE: This monitor accepts a 75mm x 75mm VESA-compliant mounting interface pad. Squeeze the folded monitor stand into the VESA mounting bracket. Then fasten it using the four supplied nuts with the monitor, mounting pad and VESA mounting bracket aligned. 1.
8. Power Consumption 9. Dimensions (WxDxH) 10. Weight 11. Environmental Considerations 12. DVR mode SMT-170MN/SMT-170MP 17.0 inch diagonal 337.92(H) x 270.336(V) 0.264(H) x 0.264(V) a-si TFT active matrix 70/70/60/60 (L/R/T/B) AC 90 to 264 VAC, 60/50Hz ± 3Hz Max. 42W 385 x 233 x 413.7 mm (After installation of stand)
