Page 1: User Guide
TFT-LCD MONITOR SMT-1722 / SMT-1922 User Guide... -
Page 2: Important Safety Instructions
Use only with a cart, stand, tripod. bracket or table recommended by Samsung, or sold with the monitor. Any mounting of the monitor should follow Samsung’s instructions and should use a mounting accessory recommended by Samsung. -
Page 3: Ic Compliance Notice
20.Replacement Parts : When replacement parts are required, be sure the service technician has used replacement parts specified by Samsung or have the same characteristics as the original parts. Unauthorized substitutions may result in fire, electric shock or other hazards. -
Page 4: Table Of Contents
USER'S MANUAL Contents Important Safety Instructions ... 2 Unpacking ... 5 Viewing the Control Panels ... 5 Front View ... 5 Rear & Left Side View ... 6 Remote Controller ... 7 Connecting to External Devices..8 OSD Menu Configurations ... 9 No Signal Display ... -
Page 5: Unpacking
Remove the package cover and place the product on a flat and secure surface or in the installation location. Check whether all the following devices and accessories are included with the main system. TFT-LCD REMOTE & MONITOR BATTERIES Viewing the Control Panels Front View IR Sensor Remote controller sensor. -
Page 6: Rear & Left Side View
USER'S MANUAL USER'S MANUAL USER'S MANUAL Rear & Left Side View Left Side View Rear View Rear View POWER AC power input. VIDEO-A IN Composite signal input for VIDEO A. VIDEO-A OUT Video looping output for VIDEO A. VIDEO-B IN Composite signal input for VIDEO B. -
Page 7: Remote Controller
SOURCE Press the 'SOURCE' button to change the input signal source. Changing the source is allowed only in external devices that are connected to the monitor at the time. buttons Moves from one menu item to another horizontally, vertically or adjusts selected menu values. -
Page 8: Connecting To External Devices
USER'S MANUAL USER'S MANUAL Connecting to External Devices. The product can be connected to an external device such as Camera, DVR,VCR, External Monitor, etc. CAMERA External MONITOR - 8 -... -
Page 9: Osd Menu Configurations
USER'S MANUAL USER'S MANUAL OSD Menu Configurations No Signal Display When there is no connection at the VGA and Video input, the On Screen Display will show this message. No Signal <Video mode> Check signal cable. <VGA mode> OSD Menu Selection 1. - Page 10 This function is not available in VGA mode. Digital NR / DNIe Return If the signal received by your monitor is weak, you can activate the Digital Noise Reduction feature to help reduce any noisy signal that may appear on the screen.
-
Page 11: Sound Menu
USER'S MANUAL USER'S MANUAL • Digital NR : Off/Low/Medium/High/Auto If the signal received by the monitor is weak,you can activate this feature to reduce any noisy signal that may appear on the screen. Picture More Size : 4 : 3... -
Page 12: Setup Menu
USER'S MANUAL USER'S MANUAL Equalizer Sound Mode : Custom Equalizer Audio for VGA Mode : Off Reset Move Enter Equalizer Balance 100Hz 300Hz 1kHz 3kHz 10kHz Move Adjust 1. Press the MENU and button to select the Sound menu. 2. Press the ENTER or button. -
Page 13: Energy Saving
If you wish to continue viewing the poor picture, you must set the "Blue Screen" mode to "Off". • Melody:Off/Low/Medium/High You can hear melody sound when the monitor is powered on or off. 5. Press the MENU button to exit. Energy Saving... - Page 14 Even if your actual screens look different, the same, basic set-up information will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.) 1. First, click on "Control Panel" on the Windows start menu.
- Page 15 Press the ENTER button. 8. Press the MENU button to exit. • Position Adjust the PC’s screen positioning if it does not fi t the Monitor screen. Position Move Enter 1. Follow the "Image Lock" instructions number 2 to 4.
-
Page 16: Input Menu
USER'S MANUAL System ID Setup Language Blue Screen Melody Energy Saving System ID No Signal OSD Move Enter 1. Press the MENU and button to select the Setup menu. 2. Press the ENTER or button. 3. Press the button to select the System ID. 4. -
Page 17: Specifications
Net Weight Weight Package Weight Power Supply Electric Power Consumption Performance Temperature Operating condition Humidity SMT-1722 Inch 17" 337.92mm(H) x 270.336mm(V) 0.264mm(H) x 0.264mm(V) NTSC:600TVL PAL:620TVL A/D bits Horizontal: 30 kHz – 81 kHz, Vertical: 56 Hz – 75 Hz Freeze 2CH input, 1.0Vp-p, 75Ω... - Page 18 AB68-00747A...
