Tetra Waterfall Globe Quick Setup Manual

Start Here - LED Waterfall Globe
1
Part Identifi cation
Filter
Cartridge
Waterfall Slider
Filter Holder
Filter
Housing
Pump
Cover
Glass Globe
4
Filter Setup
Replace Glass Globe.
A.
ALWAYS handle Glass Globe
from the bottom, the rim.
NEVER
D
Snap Filter Holder with Filter
B.
Housing and Pump on lip of Glass
Globe under LED Light.
Waterfall Slider
A
For questions and concerns contact Customer Support 800.526.0650 • www.tetra-fi sh.com
Quick Setup Guide
2
LED Light
Tilt the LED Light up to access the Filter Assembly
A.
and Glass Globe.
Remove Filter Assembly from Glass Globe, then remove
B.
Glass Globe from Base. Rinse Glass Globe and set aside.
Install Pump fi rmly onto bottom/back of Filter Housing.
C.
Pump With
Impeller
Arm
Pump
Base
AC Low Voltage
Adapter Plug
Bend Waterfall Slider. Align hole
C.
in the Waterfall Slider with cylinder on
Filter Housing, press Slider all the way
down. The Waterfall Slider
helps reduce splashing.
B
Remove the Filter
D.
Cartridge and rinse.
C
Reinsert Filter Cartridge
into Filter Housing.
Replace Filter
NOTE:
Cartridge every 3 to 4
weeks for optimal
fi sh health.
Install Pump
A
Rinse &
Filter
Assembly Set Aside
B
Glass
Globe
5
Turn Waterfall and Light On & Off
C
Waterfall
To turn waterfall
NOTE:
OFF unplug AC Adapter.
run the Pump
NEVER:
without water in Globe.
© 2012 United Pet Group, Inc. Tetra®, AquaSafe® are registered trademarks
of United Pet Group, Inc. or one of its subsidiaries
3
Fill Glass Globe
Fill Glass Globe with gravel and decor.
A.
Add room temperature dechlorinated tap water
B.
approximately 1"/2.5 cm from the top edge.
1"
2.5 cm
C
Install
Pump
Attach AC Adapter Plug into the
A.
Light Switch
D
Jack on the back of Waterfall base.
(I) ON - (O) OFF
Plug AC Adapter into power outlet.
B.
This powers LED Lights and Waterfall
Pump. Make a Drip Loop for safety.
After water is fl owing, adjust Waterfall
C.
Slider front angle to minimize splashing.
Rotate the LED light down over the
D.
water. Use Light Switch to power lights
(I) ON and (0) OFF.
A
AC Adapter Plug
Room
Temperature
Always:
Make a
B
Drip Loop
(for safety).
08/12 29008_985 Rev B
