Page 1: Parts List
SELF-CONTAINED CRESCENT CUBER KM-150BAF-E KM-150BWF-E PARTS LIST HOSHIZAKI 89/336 NUMBER: 73/23 ISSUED: FEB. 29, 2000 REVISED: MARCH 7, 2000 71179... - Page 2 This is accomplished in this icemaker through the use of stainless steel toothed washers, Hoshizaki Part # 7R22-0400. FEB. 1999 MARCH 2000...
-
Page 3: Material Abbreviations
ALUMINUM Aluminum COPPER Copper PLASTIC Acrylonitrile -butadiene - styrene Polyacetal EV A Ethylene vinyl acetate Polyamide = Nylon Polycarbonate Polyethylene Polyester PETP Polyethylene terephthalate = Tetlon Polypropylene Polystyrene PTFE Polytetrafluoroethylene = Teflon Polyurethane Polyvinyl chloride RUBBER Vinyl Nitrile EPDM EP rubber Nitrile butadiene rubber Natural rubber Neoprene... -
Page 4: Ice Cuber Assembly
KM-150BAF-E A. ICE CUBER ASSEMBLY... - Page 5 CLAMP CLAMP REAR PANEL (B) T2 SCREW REAR PANEL (A) T2 SCREW POWER SUPPLY CORD BUSHING TRUSS HEAD SCREW HEX NUT FRONT COVER (B) KM-150BAF-E TITLE A. ICE CUBER ASSEMBLY MATERIAL OR PART MODEL NUMBER NUMBER 1A0404A01 108446A02 338868A03 7P31-0408...
- Page 6 FRONT COVER (L) HINGE (L) TRUSS HEAD SCREW FRONT COVER (R) HINGE (R) TRUSS HEAD SCREW TOP PANEL TRUSS HEAD SCREW T2 SCREW WASHER KM-150BAF-E TITLE A. ICE CUBER ASSEMBLY MATERIAL OR MODEL NUMBER 4X8, SS 7P32-0408 226307-01 4X8, SS 7C32-0408...
- Page 7 KM-150BWF-E A. ICE CUBER ASSEMBLY...
- Page 8 MODEL INDEX DESCRIPTION REFRIGERATION CIRCUIT WATER CIRCUIT CONT. BOX ASSEMBLY (A) T2 SCREW CONT. BOX ASSEMBLY (B) T2 SCREW TRANSFORMER BOX ASSEMBLY TRUSS HEAD SCREW LABEL LOCATION BASE PANEL REAR TRUSS HEAD SCREW GASKET BODY-INSULATION T2 SCREW STOPPER T2 SCREW CAPILLARY RING CLAMP CLAMP...
- Page 9 MODEL INDEX DESCRIPTION T2 SCREW FRONT PANEL TRUSS HEAD SCREW LOUVER TAPPING SCREW (BLACK) REAR PANEL (C) T2 SCREW CUSHION INSULATION-TOP SUPPORT-TOP PANEL FLAT HEAD SCREW DOOR COLLAR FRONT COVER (L) HINGE (L) TRUSS HEAD SCREW FRONT COVER (R) HINGE (R) TRUSS HEAD SCREW TOP PANEL TRUSS HEAD SCREW...
-
Page 10: Refrigeration Circuit
KM-150BAF-E B. REFRIGERATION CIRCUIT... - Page 11 FAN BLADE BRACKET – FM HEX HEAD BOLT W/WASHER (LF) DRIER VALVE BODY COIL VALVE BOLT TRUSS HEAD SCREW BRACKET HG T2 SCREW KM-150BAF-E TITLE B. REFRIGERATION CIRCUIT MATERIAL OR MODEL NUMBER 108456A02 4X8, SS 7C32-0408 3A1254G01 5X12, SS 7B0230512...
- Page 12 MODEL KM-150BAF-E TITLE INDEX DESCRIPTION PRESSURE SWITCH PRESSURE SWITCH BRACKET T2 SCREW COPPER TUBE – HIGH SIDE COPPER TUBE – CONDENSER HEAT EXCHANGER COPPER TUBE (A) – HOT GAS COPPER TUBE (A) – ACCESS VALVE EXP. VALVE RUBBER TUBE THERMISTOR...
- Page 13 KM-150BWF-E B. REFRIGERATION CIRCUIT...
- Page 14 MODEL KM-150BWF-E TITLE INDEX DESCRIPTION EVAPORATOR TRUSS HEAD SCREW UNIT BASE HEX HEAD BOLT W/WASHER (LF) COMPRESSOR STARTING CAPACITOR RUBBER GROMMET SLEEVE BOLT WASHER START RELAY CONDENSER – WATER COOLED T2 SCREW DRIER WATER REGULATOR MALE CONNECTOR TRUSS HEAD SCREW WATER REGULATOR BRACKET T2 SCREW VALVE BODY...
- Page 15 MODEL KM-150BWF-E TITLE INDEX DESCRIPTION COPPER TUBE (B) – WATER SIDE T2 SCREW COPPER TUBE (C) – WATER SIDE T2 SCREW HEAT EXCHANGER COPPER TUBE (A) – HOT GAS COPPER TUBE (A) – ACCESS VALVE EXP. VALVE RUBBER TUBE THERMISTOR HOLDER-THERMISTOR INSULATION-THERMISTOR EXP.
-
Page 16: Water Circuit
KM-150BAF-E, BWF-E C. WATER CIRCUIT J-0, K-0... - Page 17 JOINT PIPE TANK OVERFLOW PIPE “O” RING OVERFLOW CAP SUPPORT-TANK RAIL-TANK THUMB SCREW CUBE GUIDE VINYL HOSE VINYL HOSE INSULATION TUBE HOSE CLAMP KM-150BAF-E TITLE C. WATER CIRCUIT MATERIAL OR PART MODEL NUMBER NUMBER 226314A01 5X10, SS 7C32-0510 4A1955A02 7C31-0408 443613-01...
- Page 18 MODEL INDEX DESCRIPTION HOSE CLAMP HOSE CLAMP FITTING-DRAIN SPACER TRUSS HEAD SCREW TANK DRAIN HOSE DRAIN CAP KM-150BAF-E TITLE C. WATER CIRCUIT MATERIAL OR PART MODEL NUMBER NUMBER 20mm, SS 427443-06 13.5mm, SS 427443-07 85-5-5-5 BRASS 452659-01 452660-01 4X12, SS...
- Page 19 MODEL INDEX DESCRIPTION PUMP MOTOR ASSEMBLY TRUSS HEAD SCREW WATER VALVE TRUSS HEAD SCREW FITTING (A) RUBBER GASKET SOLENOID VALVE TRUSS HEAD SCREW ARROW LABEL BRACKET-SOLENOID VALVE TRUSS HEAD SCREW WATER SUPPLY HOSE SPRAY GUIDE (A) SPRAY GUIDE (D) SPRAY TUBE ELBOW JOINT PIPE TANK...
- Page 20 MODEL INDEX DESCRIPTION HOSE CLAMP HOSE CLAMP FITTING-DRAIN SPACER TRUSS HEAD SCREW TANK DRAIN HOSE DRAIN CAP KM-150BWF-E TITLE C. WATER CIRCUIT MATERIAL OR PART MODEL NUMBER NUMBER 20mm, SS 427443-06 13.5mm, SS 427443-07 85-5-5-5 BRASS 452659-01 452660-01 4X12, SS 7C32-0412 452693-01 322015-01...
- Page 21 KM-150BAF-E, BWF-E D. CONT. BOX ASSEMBLY (A) J-0, K- 2 2a 3 3a...
- Page 22 MODEL KM-150BAF-E TITLE INDEX DESCRIPTION THERMOSTAT ASSEMBLY TRUSS HEAD SCREW CONT. BOX (A) TRANSFORMER T2 SCREW CAPACITOR T2 SCREW CONTROLLER BOARD BOARD SUPPORT 9P PLUG HOUSING 2P PLUG HOUSING BUSHING BUSHING D. CONT. BOX ASSEMBLY (A) MATERIAL OR PART MODEL...
- Page 23 9P PLUG HOUSING 2P PLUG HOUSING BUSHING BUSHING D. CONT. BOX ASSEMBLY (A) MATERIAL OR PART MODEL NUMBER NUMBER 339623A02 7C31-0408 226319-01 26D285H 3A0172-01 7P31-0408 4A2128-06 4X10 7P31-0410 HOSHIZAKI-001 2A1410-01 CBLS37-M 4A0336-03 3191-09P 412832-02 3191-02P 412832-09 OCB-625 428394-03 OCB-500 428394-02 REQUIRED NUMBER...
- Page 24 KM-150BAF-E, BWF-E E. CONT. BOX ASSEMBLY (B) J-0, K-...
- Page 25 CONT. BOX (B) MAGNETIC CONTACTOR BRACKET T2 SCREW TOGGLE SWITCH – VDE 9P PLUG HOUSING 2P PLUG HOUSING BUSHING COVER – CONT. BOX (B) T2 SCREW KM-150BAF-E TITLE E. CONT. BOX ASSEMBLY (B) MATERIAL OR MODEL NUMBER NUMBER 226320-01 VC20 428393-01 428393F01...
- Page 26 MODEL INDEX DESCRIPTION CONT. BOX (B) MAGNETIC CONTACTOR BRACKET T2 SCREW TOGGLE SWITCH – VDE 9P PLUG HOUSING 2P PLUG HOUSING BUSHING COVER – CONT. BOX (B) T2 SCREW KM-150BWF-E TITLE E. CONT. BOX ASSEMBLY (B) MATERIAL OR MODEL NUMBER 226320-01 VC20 428393-01...
-
Page 27: Transformer Box Assembly
KM-150BAF-E, BWF-E F. TRANSFORMER BOX ASSEMBLY J-0, K-0... - Page 28 MODEL KM-150BAF-E TITLE INDEX DESCRIPTION TRANSFORMER BOX TRANSFORMER BOX COVER TRUSS HEAD SCREW TRANSFORMER TRUSS HEAD SCREW BUSHING 3P PLUG HOUSING PIN TERMINAL F. TRANSFORMER BOX ASSEMBLY MATERIAL OR PART MODEL NUMBER NUMBER 3A1244-01 440361-01 7C31-0408 2U0130 2U0130-01 7C31-0408 OCB-625...
- Page 29 MODEL KM-150BWF-E TITLE INDEX DESCRIPTION TRANSFORMER BOX TRANSFORMER BOX COVER TRUSS HEAD SCREW TRANSFORMER TRUSS HEAD SCREW BUSHING 3P PLUG HOUSING PIN TERMINAL F. TRANSFORMER BOX ASSEMBLY MATERIAL OR PART MODEL NUMBER NUMBER 3A1244-01 440361-01 7C31-0408 2U0130 2U0130-01 7C31-0408 OCB-625 428394-03 3191-03P 412832-06...
-
Page 30: Label Location
KM-150BAF-E G. LABEL LOCATION... - Page 31 CAUTION LABEL (F) CAUTION LABEL (G) MANUAL LABEL LABEL – AIR FILTER INSTRUCTION LABEL CAUTION LABEL LABEL – CONTROL BOARD WATER SUPPLY LABEL LABEL - CE KM-150BAF-E TITLE G. LABEL LOCATION MATERIAL OR PART MODEL NUMBER NUMBER PETP FILM 4A0560-01...
- Page 32 KM-150BWF-E G. LABEL LOCATION...
- Page 33 MODEL INDEX DESCRIPTION EMBLEM MODEL NUMBER LABEL LABEL – PENGUIN – HA (L) MAINTENANCE LABEL WIRING LABEL NAMEPLATE INSTRUCTION SHEET LABEL – R404A LABEL – SWITCH CONTROL – LABEL CAUTION LABEL (G) MANUAL LABEL INSTRUCTION LABEL CAUTION LABEL LABEL – CONTROL BOARD WATER SUPPLY LABEL LABEL - CE LABEL –...
- Page 34 KM-150BAF-E, BWF-E H. EVAPORATOR J-0, K-0...
- Page 35 BRACKET (R) – EVAP. POP-RIVET HOOK REDUCER COPPER TUBE (A) COPPER TUBE (B) INSULATION TUBE INSULATION TUBE INSULATION TUBE INSULATION TUBE COPPER TUBE (A) – EXPV. KM-150BAF-E TITLE H. EVAPORATOR MATERIAL OR PART MODEL NUMBER NUMBER 226312G01 4A1449-01 452654-01 452655-01...
- Page 36 MODEL INDEX DESCRIPTION EVAPORATOR BRACKET – EVAP. BRACKET (L) – EVAP. BRACKET (R) – EVAP. POP-RIVET HOOK REDUCER COPPER TUBE (A) COPPER TUBE (B) INSULATION TUBE INSULATION TUBE INSULATION TUBE INSULATION TUBE COPPER TUBE (A) – EXPV. KM-150BWF-E TITLE H. EVAPORATOR MATERIAL OR PART MODEL...
-
Page 37: Pump Motor Assembly
KM-150BAF-E, BWF-E J. PUMP MOTOR ASSEMBLY J-0, K-0... - Page 38 TRUSS HEAD SCREW IMPELLER PUMP HOUSING ASSEMBLY PUMP GASKET T2 SCREW FLOAT SWITCH BRACKET T2 SCREW FLOAT SWITCH T2 SCREW VINYL HOSE KM-150BAF-E TITLE J. PUMP MOTOR ASSEMBLY MATERIAL OR MODEL NUMBER NUMBER 3U0153-01 452662-01 4X12, SS 7C32-0412 JSR CB40...
- Page 39 MODEL KM-150BWF-E TITLE INDEX DESCRIPTION PUMP MOTOR BRACKET – PM TRUSS HEAD SCREW PUMP MOTOR BRACKET PUMP SHAFT COVER TRUSS HEAD SCREW IMPELLER PUMP HOUSING ASSEMBLY PUMP GASKET T2 SCREW FLOAT SWITCH BRACKET T2 SCREW FLOAT SWITCH T2 SCREW VINYL HOSE J.
-
Page 40: Thermostat Assembly
KM-150BAF-E, BWF-E K. THERMOSTAT ASSEMBLY J-0, K-0... - Page 41 MODEL INDEX DESCRIPTION THERMOSTAT HEATER VINYL HOSE 3P PLUG HOUSING SILICONE TUBE PIN TERMINAL KM-150BAF-E TITLE K. THERMOSTAT ASSEMBLY MATERIAL OR MODEL NUMBER A30-3761-00 437626-01 EP-21 437409-01 L=800 7711-0406 3191-03P 412832-06 8x10XL380 7730-0810 1190T 7921-0003 PART REQUIRED NUMBER NUMBER...
- Page 42 MODEL KM-150BWF-E TITLE INDEX DESCRIPTION THERMOSTAT HEATER VINYL HOSE 3P PLUG HOUSING SILICONE TUBE PIN TERMINAL K. THERMOSTAT ASSEMBLY MATERIAL OR PART MODEL NUMBER NUMBER A30-3761-00 437626-01 EP-21 437409-01 L=800 7711-0406 3191-03P 412832-06 8x10XL380 7730-0810 1190T 7921-0003 REQUIRED NUMBER...
- Page 43 KM-150BAF-E, BWF-E L. ACCESSORIES J-0, K-0...
- Page 44 MODEL INDEX DESCRIPTION INSTRUCTION MANUAL INSTALLATION MANUAL SCOOP KM-150BAF-E TITLE L. ACCESSORIES MATERIAL OR PART MODEL NUMBER NUMBER PAPER 91A1LA10A PAPER 91U1TB10A 437625-01 REQUIRED NUMBER...
