Digital Video Camcorder
SC-D351/D352/D353/D354/D355
AF
Auto Focus
CCD
Charge Coupled Device
LCD
Liquid Crystal Display
Owner's Instruction Book
Before operating the unit, please read this
Instruction Book thoroughly, and retain it for
future reference.
US PATENT 4415844
ENGLISH

Advertisement

Table of Contents
loading

Related Manuals for Samsung SC-D352

Summary of Contents for Samsung SC-D352

  • Page 1 Digital Video Camcorder SC-D351/D352/D353/D354/D355 Auto Focus Charge Coupled Device Liquid Crystal Display Owner’s Instruction Book Before operating the unit, please read this Instruction Book thoroughly, and retain it for future reference. US PATENT 4415844 ENGLISH...

  • Page 2: Notices And Safety Instructions

    8. ACCESSORIES: Do not place this CAMCORDER on an unstable cart, stand, tripod, bracket or table. The CAMCORDER may fall, causing serious injury to a child or adult, and serious damage to the unit.
  • Page 3 9. VENTILATION: Slots and openings in the cabinet are provided for ventilation to ensure reliable operation of the CAMCORDER and to protect it from overheating. These openings must not be blocked or covered. Never place your CAMCORDER on a bed, sofa, rug, or other similar surface: on or near a radiator or heat register.
  • Page 4 CAMCORDER to its normal operation. e. If the CAMCORDER has been dropped or the cabinet has been damaged. f. When the CAMCORDER exhibits a distinct change in performance, this indicates a need for service.
  • Page 5 DISPOSED OF ACCORDING TO LOCAL, STATE OR FEDERAL LAWS For details see lamprecycle.org, eiae.org, or call 1-800-Samsung NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 6: Table Of Contents

    ENGLISH Contents Notes and Safety Instructions ... 6 Getting to Know Your Camcorder ... 11 Features ... 11 Accessories Supplied with Camcorder ...12 Front & Left View...13 Left Side View...14 Right & Top View ...15 Rear & Bottom View...16 Remote Control (SC-D354/D355 only) ...17 Preparation ...
  • Page 7 To Stop Recording (use Fade In/Fade Out) ...45 Using Back Light Compensation Mode (BLC)...46 Using the Color Nite Shutter ...47 Using the Color Nite Shutter with LED Light (SC-D352/D354/D355 only) ...48 Nite Pix (0 lux recording) (SC-D352/D354/D355 only)...49 Power Nite Pix (SC-D352/D354/D355 only)...50 Advanced Recording...
  • Page 8 Audio Dubbing (SC-D354/D355 only)...77 Dubbing Sound...77 Dubbed Audio Playback ...78 IEEE 1394 Data Transfer... 79 USB Interface (SC-D352/D353/D354/D355 only)... 81 Digital Still Camera Mode (SC-D353/D354/D355 only)... 87 Memory Stick (Optional Accessory)...87 Memory Stick Functions...87 Inserting and Ejecting the Memory Card ...88 Structure of Folders and Files on the Memory Card ...89...
  • Page 9 Using Quick Menu: Print Mark ...109 PictBridge (SC-D353/D354/D355 only) ... 110 Maintenance ... 112 After Finishing a Recording ...112 Cleaning and Maintaining the Camcorder ...113 Using Your Camcorder Abroad...114 Troubleshooting ... 115 Specifications ... 118 Index... 119 Warranty(SEA users only)...120...

  • Page 10: Notes And Safety Instructions

    Notes regarding the Rotation of the LCD Screen Please rotate the LCD screen carefully as illustrated. Over rotation may cause damage to the inside of the hinge that connects the LCD screen to the Camcorder. 1. LCD screen closed. 2. Standard recording using the LCD screen.
  • Page 11 Television programs, video tapes, DVD titles, films, and other program materials may be copyrighted. Unauthorized copying of copyrighted material may be against the law. All the trade names and registered trademarks mentioned in this manual or other documentation provided with your Samsung product are trademarks or registered trademarks of their respective holders.
  • Page 12 To preserve battery power, keep your Camcorder turned off when you are not operating it. ■ If your Camcorder is in CAMERA mode, and it is left in STBY mode without being operated for more than 5 minutes with a ■...
  • Page 13 Notes regarding electronic Viewfinder 1. Do not position the Camcorder such that the Viewfinder is pointing towards the sun. Direct sunlight can damage the inside of the Viewfinder. Be careful when placing the Camcorder under sunlight or near a window exposed to sunlight.
  • Page 14 1. The Lithium battery maintains the clock function and user settings; even if the Battery pack or AC adapter is removed. 2. The Lithium battery for the Camcorder lasts about 6 months under normal operation from time of installation. 3. When the Lithium battery becomes weak or dead, the date/time indicator will display 12:00 AM JAN.1,2005 when you set the Date/Time to on.

  • Page 15: Getting To Know Your Camcorder

    PC, making it possible to produce or edit various images. USB Interface for Digital Image Data Transfer (SC-D352/D353/D354/D355 only) ■ You can transfer images to a PC using the USB interface without an add-on card.

  • Page 16: Accessories Supplied With Camcorder

    5. Instruction Book 6. Lithium Battery for Remote Control (SC-D354/D355 only) or Clock. (TYPE: CR2025) 7. Remote Control (SC-D354/D355 only) 8. USB Cable (SC-D352/D353/D354/D355 only) 9. Software CD (SC-D352/D353/D354/D355 only) 10. Lens Cover 11. Lens Cover Strap Optional Accessories 12. S-Video Cable 13.

  • Page 17: Front & Left View

    Getting to Know Your Camcorder Front & Left View 1. Lens 2. LED light (SC-D352/D354/D355 only) 3. Remote sensor (SC-D354/D355 only) 4. S-Video jack 5. Internal MIC 1. Lens 2. LED light (see page 48) (SC-D352/D354/D355 only) 3. Remote sensor (SC-D354/D355 only) 4.

  • Page 18: Left Side View

    5. Focus adjustment knob 5. Focus adjustment knob 6. Viewfinder 6. Viewfinder 7. COLOR NITE SHUTTER (see page 47) (SC-D351/D353 only) 7. COLOR NITE/LED LIGHT (see page 48) (SC-D352/D354/D355 only) 7. COLOR NITE SHUTTER (SC-D351/D353 only) 7. COLOR NITE/ LED LIGHT...

  • Page 19: Right & Top View

    Getting to Know Your Camcorder Right & Top View 1. NITE PIX switch (SC-D352/D354/D355 only) 2. Menu selector (VOL/MF) 3. MENU button 4. Start/Stop button 5. Power switch 6. DC jack 1. NITE PIX switch (SC-D352/D354/D355 only) 2. Menu selector (VOL/MF) 3.

  • Page 20: Rear & Bottom View

    ENGLISH Getting to Know Your Camcorder Rear & Bottom View 1. Lithium battery cover 2. Charging indicator 1. Lithium battery cover 2. Charging indicator 3. Memory card slot (SC-D353/D354/D355 only) 4. Battery release 5. Tripod receptacle 3. Memory card slot...

  • Page 21: Remote Control (Sc-D354/D355 Only)

    Getting to Know Your Camcorder Remote Control (SC-D354/D355 only) 1. PHOTO 2. START/STOP 3. SELF TIMER 4. ZERO MEMORY 5. PHOTO SEARCH 6. A.DUB (FF) (REW) (PLAY) 10. Direction 1. PHOTO (see page 68) 2. START/STOP 3. SELF TIMER (see page 43) 4.

  • Page 22: Preparation

    It is very important to ensure that the Hand strap has been correctly adjusted before you begin your recording. The Hand strap enables you to: - Hold the Camcorder in a stable, comfortable position. - Press the ZOOM and Start/Stop button without having to change the position of your hand.

  • Page 23: Lithium Battery Installation

    ✤ adapter is removed. ✤ The Lithium battery for the Camcorder lasts about 6 months under normal operation from the time of installation. ✤ When the Lithium battery becomes weak or dead, the date/time indicator will display 12:00 AM JAN.1,2005 when you set the Date/Time to on.

  • Page 24: Connecting A Power Source

    ENGLISH Preparation Connecting a Power Source There are two types of power source that can be connected to your Camcorder. - The AC Power adapter and AC Cord: used for indoor recording. - The Battery pack: used for outdoor recording.

  • Page 25: Using The Lithium Ion Battery Pack

    The Battery pack may be charged a little at the time of purchase. ■ ■ To prevent reduction in the life and capacity of the Battery pack, always remove it from the Camcorder after it is fully charged. The amount of continuous recording time available depends on: ■...

  • Page 26: Table Of Continuous Recording Time Based On Model And Battery Type

    Do not allow the + and – terminals of the Battery pack to be short-circuited. It may cause leakage, heat generation, induce overheating or fire. ■ Use SB-LSM80 or SB-LSM160 Battery pack only. It is recommended to use original battery pack that is available at SAMSUNG service center. ■ Continuous recording time LCD ON VIEWFINDER ON Approx.

  • Page 27: Battery Level Display

    40~80% used d. 80~95% used e. Completely used (Blinking) (The Camcorder will turn off soon, change the battery as soon as possible) [ Notes ] Please refer to the Table on page 22 for approximate continuous recording time. ■...

  • Page 28: Osd (On Screen Display In Camera/Player Modes)

    9. Manual focus (see page 58) 10. Date/Time (see page 33) 11. Zoom position (see page 44) 12. NITE PIX (see page 49) (SC-D352/D354/D355 only) 13. Color Nite (see page 47) 14. USB (SC-D352/D353/D354/D355 only) 15. Remote (see page 28) (SC-D354/D355 only) 16.

  • Page 29: Osd (On Screen Display In M.cam/M.player Modes) (Sc-D353/D354/D355 Only)

    Preparation OSD (On Screen Display in M.Cam/M.Player Modes) (SC-D353/D354/D355 only) 1. Photo quality 2. CARD (Memory Card) indicator 3. Image counter Total number of recordable still images. 4. Image recording and loading indicator 5. Erase protection indicator (see page 97) 6.

  • Page 30: System Menu Setting

    ENGLISH System Menu Setting Selecting the OSD Language ✤ The Language function works in Camera/Player/M.Cam/M.Player modes. ✤ Select the appropriate OSD Language among English, French, Spanish, German, Italian, Portuguese, Polish and Dutch. 1. Set the Power switch to CAMERA or PLAYER. 2.

  • Page 31: Setting The Clock

    System Menu Setting Setting the Clock ✤ Clock setup works in Camera/Player/M.Cam/M.Player modes. ✤ The Date/Time is automatically recorded onto a tape. Before recording, please set the Date/Time. 1. Set the Power switch to CAMERA or PLAYER. 2. Set the Mode switch to TAPE or MEMORY CARD. (SC-D353/D354/D355 only) 3.

  • Page 32: Setting The Wireless Remote Control Acceptance (Remote) (Sc-D354/D355 Only)

    The Remote function works in Camera/Player/M.Cam/M.Player modes. ✤ The Remote option allows you to enable or disable the remote control for use with the Camcorder. 1. Set the Power switch to CAMERA or PLAYER. 2. Set the Mode switch to TAPE or MEMORY CARD.

  • Page 33: Setting The Beep Sound

    System Menu Setting Setting the Beep Sound ✤ The Beep Sound function works in Camera/Player/M.Cam/M.Player modes. ✤ You can turn the Beep Sound on or off, when on, each press of a button sounds a beep. 1. Set the Power switch to CAMERA or PLAYER. 2.

  • Page 34: Setting The Shutter Sound (Sc-D353/D354/D355 Only)

    ENGLISH System Menu Setting Setting the Shutter Sound (SC-D353/D354/D355 only) ✤ The Shutter Sound function works in both Player and M.Cam modes. ✤ You can turn the Shutter Sound on or off, when on, with each press of the PHOTO button the Shutter will Sound. 1.

  • Page 35: Viewing The Demonstration

    System Menu Setting Viewing the Demonstration ✤ Before you begin: Make Sure that there is no tape inserted in the Camcorder. (see page 36) ✤ Demonstration automatically shows you the major functions that are included with your Camcorder so that you may use them more easily.

  • Page 36: Display Menu Setting

    ✤ This function works in Camera/Player/M.Cam/M.Player modes. ✤ Your Camcorder is equipped with a 2.36 inch color Liquid Crystal Display(LCD) screen, which enables you to view what you are recording or playing back directly. ✤ Depending on the conditions under which you are using the Camcorder (indoors or outdoors for example), you can adjust;...

  • Page 37: Displaying The Date/Time

    The Date/Time will read 12:00 AM JAN.1,2005 in the following conditions. - During playback of a blank section of a tape. - If the tape was recorded before setting the Date/Time in the Camcorder. - When the Lithium battery becomes weak or dead.

  • Page 38: Setting The Tv Display

    - Off: The OSD appears in the LCD screen and Viewfinder only. - On: The OSD appears in the LCD screen, Viewfinder and TV. - Use the DISPLAY button located at the left side of the Camcorder to turn the OSD on/off on the LCD screen /Viewfinder/TV.

  • Page 39: Basic Recording

    Basic Recording Using the Viewfinder ✤ In the PLAYER mode, the Viewfinder will work when the LCD screen is closed. ✤ In the CAMERA mode, the Viewfinder will work when the LCD screen is closed or rotated counterclockwise 180°. Adjusting the Focus The focus adjustment knob of the Viewfinder enables individuals with vision problems to see clearer images.

  • Page 40: Inserting And Ejecting A Cassette

    ENGLISH Basic Recording Inserting and Ejecting a Cassette ✤ When inserting a tape or closing the cassette compartment, do not apply excessive force. As it may cause a malfunction. ✤ Do not use any tape other than Mini DV cassettes. 1.

  • Page 41: Hints For Stable Image Recording

    Basic Recording Hints for Stable Image Recording ✤ While recording, it is very important to hold the Camcorder correctly. ✤ Fix the lens cover firmly by clipping it to the hand strap. (see page 18) Recording with the LCD Screen 1.

  • Page 42: Various Recording Techniques

    In circumstances where it is difficult to use the LCD screen, the Viewfinder can be used as a convenient alternative. [ Note ] Please rotate the LCD screen carefully as excessive rotation may cause damage to the inside of the hinge that connects the LCD screen to the Camcorder.

  • Page 43: Making Your First Recording

    Basic Recording Making your First Recording 1. Connect a power source to the Camcorder. (see page 20) (A Battery pack or a AC Power adapter) Insert a cassette. (see page 36) 2. Remove the Lens cover. 3. Set the Power switch to CAMERA.

  • Page 44: Using Easy.q Mode (For Beginners)

    1. Set the Power switch to CAMERA. 2. Set the Mode switch to TAPE. (SC-D353/D354/D355 only) 3. By pressing the EASY.Q button, all functions on the Camcorder will be set to off and the recording settings will be set to the following basic modes: Battery level, recording mode, counter, date/time, and DIS ( ) will be displayed.

  • Page 45: Record Search (Rec Search)

    Basic Recording When a cassette is loaded and the Camcorder is left in the STBY mode for more than 5 minutes without being used, it will switch off automatically. To use it again, press the Start/Stop button or set the Power switch to Off and then back to CAMERA.

  • Page 46: Setting The Zero Memory (Sc-D354/D355 Only)

    ENGLISH Basic Recording Setting the Zero Memory (SC-D354/D355 only) ✤ The ZERO MEMORY function works in both Camera and Player modes. ✤ You can mark a point on a tape that you want to return to following playback. 1. Set the Power switch to CAMERA or PLAYER. 2.

  • Page 47: Self Record Using The Remote Control (Sc-D354/D355 Only)

    5. Press the Start/Stop button again when you wish to stop recording. [ Notes ] ■ Do not obstruct the remote control sensor by putting obstacles between the remote control and Camcorder. The remote control range is 4 ~5m (13 ~17 ft). ■ ■...

  • Page 48: Zooming In And Out

    ENGLISH Basic Recording Zooming In and Out ✤ The Zoom function works in both Camera and M.Cam modes. ✤ Zooming is a recording technique that lets you change the size of the subject in a scene. You can zoom using variable zoom speeds. ✤...

  • Page 49: Using The Fade In And Out

    Basic Recording Using the Fade In and Out ✤ The FADE function works only in Camera mode. ✤ You can give your recording a professional look by using special effects such as fade in at the beginning of a sequence or fade out at the end of a sequence.

  • Page 50: Using Back Light Compensation Mode (Blc)

    Each press of the BLC button toggles: Normal ➝ BLC ➝ Normal. ■ [ Notes ] ■ When NITE PIX to set to ON, the BLC function does not work. (SC-D352/D354/D355 only) The BLC function will not operate in EASY.Q mode. ■ <BLC off>...

  • Page 51: Using The Color Nite Shutter

    Digital Zoom, Photo image recording,16:9 Wide, Emboss2, Pastel2, Mirror or Mosaic is not ■ available in the COLOR NITE SHUTTER mode. If DIS or EASY.Q is set, COLOR NITE SHUTTER mode will be released. ■ ) and off. (SC-D352/D354/D355 only) ENGLISH STBY 0:00:10 60min...

  • Page 52: Using The Color Nite Shutter With Led Light (Sc-D352/D354/D355 Only)

    ENGLISH Basic Recording Using the Color Nite Shutter with LED Light (SC-D352/D354/D355 only) ✤ COLOR NITE SHUTTER function works only in Camera mode. ✤ The LED light enables you to record a subject in dark places without sacrificing color. ✤...

  • Page 53: Nite Pix (0 Lux Recording) (Sc-D352/D354/D355 Only)

    Basic Recording Nite Pix (0 lux recording) (SC-D352/D354/D355 only) ✤ The Nite Pix function works in both Camera and M.Cam modes. ✤ The Nite Pix function enables you to record a subject in darkness. 1. Set the Power switch to CAMERA.

  • Page 54: Power Nite Pix (Sc-D352/D354/D355 Only)

    ENGLISH Basic Recording Power Nite Pix (SC-D352/D354/D355 only) ✤ The Power Nite Pix function works only in Camera mode. ✤ The Power Nite Pix function can record a subject more brightly in darkness than the Nite Pix function. ✤ When you work in Power Nite Pix mode, the Power Nite Pix icon remains on the LCD screen.

  • Page 55: Advanced Recording

    Advanced Recording Use of various Functions Setting menu items Main Menu Sub Menu Camera Program AE Selecting the Program AE Function White Balance Setting White Balance Digital Effect Setting the Digital special effect Selecting the Digital Image Stabilizing Digital Zoom Selecting Digital Zoom Tape Photo Search...
  • Page 56 Setting the Shutter sound USB Version Setting the USB Version USB Connect $ Setting the USB Language Selecting the OSD language Demonstration Demonstration (!): SC-D353/D354/D355 only (#): SC-D354/D355 only ($): SC-D352/D353/D354/D355 only Functions Camera ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔...

  • Page 57: Function Availability In Each Mode

    ✩ : The requested mode will work. (operating mode data will be backed up.) !: This Function works on models SC-D352/D354/D355 only. [ Note ] When you select an item that cannot be changed, an error message will be displayed.

  • Page 58: Selecting The Record Mode

    The Record Mode function works in both Camera and Player (DV IN) modes. ✤ This Camcorder records and plays back in SP (standard play) mode and in LP (long play) mode. - SP (standard play): This mode permits 60 minutes of recording time with a DVM60 tape.

  • Page 59: Selecting Audio Mode

    The Audio Mode function works in both Camera and Player modes. ✤ This Camcorder records sound in two ways. (12Bit, 16Bit) - 12Bit: You can record two 12Bit stereo sound tracks. The original stereo sound can be recorded onto the Main (Sound1) track.

  • Page 60: Cutting Off Wind Noise (Wind Cut)

    ENGLISH Advanced Recording Cutting Off Wind Noise (Wind Cut) ✤ The Wind Cut function works in both Camera and Player (Audio dubbing) modes. Use the Wind Cut when recording in windy places such as the beach or near buildings. ✤ The Wind Cut function minimizes wind noise or other noise while recording.

  • Page 61: Setting The Shutter Speed & Exposure

    The image may not seem as smooth when a high Shutter Speed is set. ■ ■ The Camcorder returns to the auto shutter and auto exposure settings when you set the NITE PIX to ON, or change to the EASY.Q mode. (SC-D352/D354/D355 only) ■...

  • Page 62: Auto Focus/Manual Focus

    Manual Focusing ✤ In the following situations, you may obtain better results by adjusting the focus manually. a. A picture containing several objects, some close to the Camcorder, others further away. b. A person enveloped in fog or surrounded by snow.

  • Page 63: Setting The White Balance

    Advanced Recording Setting the White Balance ✤ The White Balance function works in both Camera and M.Cam modes. ✤ The White Balance is a recording function that preserves the unique image color of the object in any recording condition. You may select the appropriate White Balance mode to obtain good quality image color. ✤...

  • Page 64: Using Quick Menu: White Balance

    Outdoor), then press the Menu selector. 4. To exit, press the MENU button. [ Notes ] When NITE PIX is set to ON, the White Balance function does not work. (SC-D352/D354/D355 only) ■ The White Balance function will not operate in EASY.Q mode.

  • Page 65: Setting The Digital Image Stabilizer (Dis)

    The DIS function works only in Camera mode. ✤ DIS (Digital Image Stabilizer) is a function that compensates for any shaking or hand movement while holding the Camcorder (within reasonable limits). ✤ It provides more stable pictures when: - Recording with the zoom (DIS is not available in Digital Zoom mode.)

  • Page 66: Using Quick Menu: Digital Image Stabilizer(Dis)

    Advanced Recording Using Quick Menu: Digital Image Stabilizer(DIS) ✤ Quick menu is used to access Camcorder functions by simply using the Menu selector. ✤ Quick menu provides easier access to the frequently used menus without using the MENU button. 1. Press the Menu selector twice.

  • Page 67: Programmed Automatic Exposure Modes (Program Ae)

    For recording fast-moving subjects such as players in golf or tennis games. [ Notes ] ■ While setting the NITE PIX to ON, the Program AE function does not work. (SC-D352/D354/D355 only) The Program AE function will not operate in EASY.Q mode. ■...

  • Page 68: Setting The Program Ae

    ENGLISH Advanced Recording Setting the Program AE 1. Set the Power switch to CAMERA. 2. Set the Mode switch to TAPE. (SC-D353/D354/D355 only) 3. Press the MENU button. The menu list will appear. ■ 4. Move the Menu selector to the left or right to select Camera, then press the Menu selector. 5.

  • Page 69: Applying Digital Effects

    Advanced Recording Applying Digital Effects ✤ The Digital Effect function works only in Camera mode. ✤ The Digital Effects enable you to give a creative look to your recording. ✤ Select the appropriate Digital Effect for the type of picture that you wish to record and the effect you wish to create. ✤...

  • Page 70: Selecting The Digital Effects

    ENGLISH Advanced Recording Selecting the Digital Effects 1. Set the Power switch to CAMERA. 2. Set the Mode switch to TAPE. (SC-D353/D354/D355 only) 3. Press the MENU button. The menu list will appear. ■ 4. Move the Menu selector to the left or right to select Camera, then press the Menu selector. 5.

  • Page 71: Zooming In And Out With Digital Zoom

    Advanced Recording Zooming In and Out with Digital Zoom ✤ Zoom works only in Camera mode. Selecting the Digital Zoom Zooming more than 20x is achieved digitally, up to 900x when combined with optical zoom. ✤ ✤ The picture quality may deteriorate depending on how much you zoom in on the subject. ✤...

  • Page 72: Photo Image Recording

    3. Press the PHOTO button. The still picture is recorded for about 6~7 seconds. ■ 4. After the PHOTO has been recorded, the Camcorder returns to its previous mode. Searching for a Photo Image ✤ The Photo Search works only in Player mode.

  • Page 73: Playback

    The adjustment method is the same procedure as used in Camera mode. (see page 32) [ Notes ] You can also view the picture on a TV screen, after connecting the Camcorder to a TV or VCR. (see page 71~72) ■...

  • Page 74: Controlling Sound From The Speaker

    [ Notes ] ■ When the AV cable is connected to the Camcorder, you cannot hear sound from the Built-In Speaker and cannot adjust the volume. The sound will return when you remove the connected AV cable from the jack of your Camcorder.

  • Page 75: Tape Playback

    You may use an S-Video (optional) cable to obtain better quality pictures if you have a S-Video connector on your TV. Even if you use an S-Video (optional) cable, you need to connect an audio cable. ■ If you connect the cable to the Audio/Video jack, you will not hear sound from the Camcorder's speakers. ■ ■...

  • Page 76: Connecting To A Tv Which Has No Audio And Video Input Jacks

    Playback Connecting to a TV which has no Audio and Video Input Jacks ✤ You can connect your Camcorder to a TV through a VCR. 1. Connect the Camcorder to your VCR with the Audio/Video cable. The yellow jack: Video ■...

  • Page 77: Various Functions While In Player Mode

    The F.ADV(Frame advance), X2, SLOW buttons are located on the remote control only. (SC-D354/D355 only) ✤ ✤ To prevent tape and head-drum wear, your Camcorder will automatically stop if it is left in still or slow modes for more than 3 minutes. Playback Pause Press the (PLAY/STILL) button during playback.

  • Page 78: Frame Advance (To Play Back Frame By Frame) (Sc-D354/D355 Only)

    ENGLISH Playback Frame Advance (To play back frame by frame) (SC-D354/D355 only) Press the F.ADV button on the remote control while in still mode. ■ - Video sequence advances frame by frame each time you press the F.ADV button. - The F.ADV function works in still mode only. To resume normal playback, press the ■...

  • Page 79: Zooming During Playback (Pb Zoom)

    You cannot apply the Playback Zoom function to pictures which are being input from ■ an external video source. The Playback Zoom image cannot be imported to your PC from the Camcorder’s DV jack. ■ The PB ZOOM images cannot be exported to a PC.

  • Page 80: Av In/Out (Sc-D355 Only)

    Menu selector. 9. Move the Menu selector to the left or right to select In, then press the Menu selector. If you want to see the Camcorder picture with a TV, set AV In/Out menu to Out. ■ 10. To exit, press the MENU button.

  • Page 81: Audio Dubbing (Sc-D354/D355 Only)

    1. Set the Power switch to PLAYER. If you want to use an external microphone, connect the microphone to ■ the external MIC input jack on the Camcorder. 2. Set the Mode switch to TAPE. 3. Press the (PLAY/STILL) button and find the time frame of the scene to be dubbed.

  • Page 82: Dubbed Audio Playback

    ENGLISH Playback Dubbed Audio Playback 1. Set the Power switch to PLAYER. 2. Set the Mode switch to TAPE. (SC-D353/D354/D355 only) 3. Insert the dubbed tape and press the MENU button. 4. Move the Menu selector to the left or right to select Tape, then press the Menu selector. 5.

  • Page 83: Ieee 1394 Data Transfer

    If a product has a DV port, you can transfer data by connecting to the DV port using the correct cable. !!! Please be careful since there are two types of DV ports, (4pin, 6pin). This Camcorder has a 4pin terminal.
  • Page 84 [ Notes ] ■ When using this Camcorder as a recorder, the pictures that appear on a monitor may seem uneven, however recorded pictures will not be affected. Operation is not guaranteed for all the recommended computer environments mentioned above.

  • Page 85: Usb Interface (Sc-D352/D353/D354/D355 Only)

    USB Streaming requires Video Codec, DV Driver and DirectX 9.0. ■ If you disconnect the USB cable from the PC or the Camcorder during the data transfer, the data transfer will stop and the data may be damaged. ■ If you connect the USB cable to a PC using a USB HUB or with other devices at the same time, it may cause conflict and may not work properly.
  • Page 86 ✤ ✤ Using the USB cable, you can connect your Camcorder to a computer to copy your movies and images from the Memory card (or built-in memory;SC-D354/D355), or to a printer to print your images. 1. Set the Power switch to PLAYER.
  • Page 87 USB Interface (SC-D352/D353/D354/D355 only) Setting the USB Communication Speed (SC-D353/D354/D355 only) ✤ To ensure proper communication between the camcorder and a PC, please set the USB Version before connecting the camcorder to a PC. ✤ It is available only in M.Cam and M.Player modes.
  • Page 88 USB Interface (SC-D352/D353/D354/D355 only) Installing DV Media PRO 1.0 Program ✤ To play back MPEG moving pictures recorded by the camcorder or streaming data transferred through the USB connection on a PC, the Video Codec program should be installed. ✤...
  • Page 89 ✤ The PC CAMERA's screen size (Transferred video frame rate for the PC Camera function is max 15 fps.) ✤ If PC is connected with the USB to the Camcorder, only the Power, Mode, Zoom and NITE PIX switches can be operated.
  • Page 90 1. Set the Mode switch to TAPE(SC-D353/D354/D355 only), set the Power switch to CAMERA or PLAYER. 2. Connect one end of the USB cable to the USB jack on the Camcorder and the other end to the USB port on your computer.

  • Page 91: Digital Still Camera Mode (Sc-D353/D354/D355 Only)

    Formatting a Memory Stick ■ [ Notes ] ■ You can use most of the Camcorder’s functions when recording to the Memory Stick. appears on the screen while recording to the Memory Stick. ■ ■ While recording or loading an image, do not eject or insert the Memory Stick.

  • Page 92: Inserting And Ejecting The Memory Card

    ■ After pulling the Memory card out from the Camcorder, please keep the Memory card in a soft case to prevent static shock. The stored contents may be changed or lost as a result of misuse, static electricity, electric noise or repair.

  • Page 93: Structure Of Folders And Files On The Memory Card

    ✤ You can use this Camcorder as a Digital Still Camera (DSC). ✤ You have to set the Mode switch to Memory card to use this Camcorder as Digital Still Camera. M.Cam mode (Memory record mode) 1. Set the Power switch to CAMERA.

  • Page 94: Selecting The Built-In Memory (Sc-D354/D355 Only)

    ENGLISH Digital Still Camera Mode (SC-D353/D354/D355 only) Selecting the Built-in Memory (SC-D354/D355 only) ✤ Built-in memory setting is available in the Player/M.Cam/M.Player modes. (SC-D354: 32MB/SC-D355: 64MB) ✤ Images can be stored and played back using the built-in memory. Hence, set the memory type before storing and playing back images. 1.

  • Page 95: Selecting The Image Quality

    Digital Still Camera Mode (SC-D353/D354/D355 only) Selecting the Image Quality ✤ You can select the quality of a still images to be recorded. Select the Image Quality 1. Set the Power switch to CAMERA. 2. Set the Mode switch to MEMORY CARD. 3.

  • Page 96: Using Quick Menu: Photo Quality

    Digital Still Camera Mode (SC-D353/D354/D355 only) Using Quick Menu: Photo Quality ✤ Quick menu is used to access Camcorder functions by using the Menu selector. ✤ Quick menu provides easier access to frequently used menus without using the MENU button.

  • Page 97: Memory File Number

    Digital Still Camera Mode (SC-D353/D354/D355 only) Memory File Number ✤ File number setting works only in M.Cam mode. ✤ File numbers are given to images in the order they were recorded when they are stored on the Memory card. ✤ Memory file numbers may be set as follows: Series: When there are existing files, the new image will be named as the next number in the sequence.

  • Page 98: Taking Photos

    ✤ You may take still images while in M.Cam mode and store the images on the Memory card. This function is useful when you want to take a snapshot of a subject while you are using the Camcorder. ✤ You can take photos using the remote control.(SC-D354/D355 only) ✤...

  • Page 99: Viewing Still Images

    Digital Still Camera Mode (SC-D353/D354/D355 only) Viewing Still Images ✤ This function works only in M.Player mode. You can playback and view still images recorded on the Memory card. ✤ Be sure that the M.Play Select is set to Photo in the Menu. ✤...

  • Page 100: To View The Multi Display

    ENGLISH Digital Still Camera Mode (SC-D353/D354/D355 only) To view the Multi Display 1. Set the Power switch to PLAYER. 2. Set the Mode switch to MEMORY CARD. The last recorded image appears. ■ 3. To view six stored images on single screen, press the A selection mark ( ) appears under the image.

  • Page 101: Protection From Accidental Erasure

    Digital Still Camera Mode (SC-D353/D354/D355 only) Protection from accidental Erasure The protection function works only in M.Player mode. ✤ ✤ You can protect important images from accidental erasure. If you execute format, all images including protected images will be erased. 1.

  • Page 102: Using Quick Menu: Protect

    Digital Still Camera Mode (SC-D353/D354/D355 only) Using Quick Menu: Protect ✤ Quick menu is used to access Camcorder functions by simply using the Menu selector. ✤ Quick menu provides easier access to the frequently used menus without using the MENU button.

  • Page 103: Deleting Still Images And Moving Images

    Digital Still Camera Mode (SC-D353/D354/D355 only) Deleting Still Images and Moving Images ✤ The Delete function works only in M.Player mode. ✤ You can erase the still images and moving images recorded on the Memory card. ✤ If you want to delete protected images, you must first deactivate the image protection. ✤...

  • Page 104: Using Quick Menu: Delete

    Digital Still Camera Mode (SC-D353/D354/D355 only) Using Quick Menu: Delete ✤ Quick menu is used to access Camcorder functions by simply using the Menu selector. ✤ Quick menu provides easier access to the frequently used menus without using the MENU button.

  • Page 105: Formatting The Memory Card

    ✤ The format function restores the Memory card to its initial state. ✤ The Memory card supplied with this Camcorder has been formatted already. Attention ✤ If you execute the memory format function, all images will be erased completely and erased images cannot be recovered.

  • Page 106: Mpeg Recording

    MPEG recording is not available when a menu or Quick menu is displayed on the screen. To start recording, press the MENU button to make it disappear. Before using the MPEG REC function, check whether the Memory card is inserted into the Camcorder. ■...

  • Page 107: Mpeg Playback

    ■ The MPEG4 file recorded by another Camcorder may not play on by this Camcorder. To playback MPEG4 moving pictures on a PC, the Video Codec (in the CD provided with the camcorder) should be installed. ■ - You need Microsoft Windows Media Player Version 9 or higher version in order to play MPEG4 file on the Memory card on your - You can download the Microsoft Windows Media Player applied each languages on Microsoft Website, “http://www.microsoft.com/windows/windowsmedia/download/default.asp”.

  • Page 108: Using Quick Menu: M.play Select

    Digital Still Camera Mode (SC-D353/D354/D355 only) Using Quick Menu: M.Play Select ✤ Quick menu is used to access Camcorder functions by simply using the Menu selector. ✤ Quick menu provides easier access to the frequently used menus without using the MENU button.

  • Page 109: Recording An Image From A Cassette As A Still Image

    Digital Still Camera Mode (SC-D353/D354/D355 only) Recording an Image from a Cassette as a Still Image ✤ This function works only in Player mode. ✤ You can record still images from a cassette on a Memory card. ✤ If you want to move recorded multiple still images from a cassette to a Memory card, use the COPY function.

  • Page 110: Copying Still Images From A Cassette To Memory Card

    5. Move the Menu selector to the left or right to select Photo Copy, then press the Menu selector. All still images that recorded on a cassette will be copied into a Memory card. ■ 6. The Camcorder automatically performs the photo search to find still images and copy starts. 7. Press the (STOP) button to stop copying.

  • Page 111: Copy To (Copies Files From The Memory Card To The Built-In Memory) (Sc-D354/D355 Only)

    Digital Still Camera Mode (SC-D353/D354/D355 only) Copy to (Copies Files from the Memory Card to the Built-in Memory) (SC-D354/D355 only) ✤ The Copy To function works only in M.Player mode. ✤ You can copy selected or all images stored in the Memory card to the built-in memory. 1.

  • Page 112: Marking Images For Printing

    ENGLISH Digital Still Camera Mode (SC-D353/D354/D355 only) Marking Images for Printing ✤ This Camcorder supports the DPOF (Digital Print Order Format) print format. ✤ You can automatically print images recorded on a Memory card with a printer supporting DPOF. ✤...

  • Page 113: Using Quick Menu: Print Mark

    Digital Still Camera Mode (SC-D353/D354/D355 only) Using Quick Menu: Print Mark ✤ Quick menu is used to access Camcorder functions by simply using the Menu selector. ✤ Quick menu provides easier access to the frequently used menus without using the MENU button.

  • Page 114: Pictbridge (Sc-D353/D354/D355 Only)

    ✤ With the PictBridge Support, you can control the printer directly through your Camcorder in order to print out stored pictures. For direct printing of your stored pictures using the PictBridge function, you must connect your Camcorder to a PictBridge printer using a USB cable.
  • Page 115 Use the AC power adapter for your Camcorder during PictBridge Direct Printing. ■ Turning your Camcorder off during the printing might damage data on the Memory card. Printing still images is supported. Motion clips are not available for printing. ■...

  • Page 116: Maintenance

    At the end of a recording you must remove the power source. ✤ When recording with a Lithium ion Battery pack, leaving the pack on the Camcorder can reduce the life span of the battery. The Battery pack should be release after recording is completed.

  • Page 117: Cleaning And Maintaining The Camcorder

    Clean the video heads with a dry type cassette cleaner. Some cleaning cassette products stop automatically. Refer to the cleaning cassette’s instructions for detailed information. ■ If the problem continues after the cleaning, consult your nearest Samsung dealer or Authorized Service Center. (blue screen) ENGLISH...

  • Page 118: Using Your Camcorder Abroad

    Before using your Camcorder abroad, check the following items. Power sources You can use your Camcorder in any country or area with the supplied AC Power adapter within 100V to 240V, 50/60 Hz. ■ Use a commercially available AC jack adapter, if necessary, depending on the design of the local wall outlet.

  • Page 119: Troubleshooting

    ✤ If the Camcorder is brought directly from a cold place to a warm place, moisture may condense inside the Camcorder, on the surface of the tape, or on the lens. In this condition, the tape may stick to the head drum and be damaged or the unit may not operate correctly.
  • Page 120 Protect! slow protected image. The Camcorder can not Read error! slow playback. Write error! slow The Camcorder can not record. The Memory card needs to Not Formatted! slow format. Now deleted... slow When progressing file delete. Memory Card If inserted Memory Card is not...
  • Page 121 Troubleshooting ✤ If these instructions do not solve your problem, contact your nearest Samsung authorized service center. Symptom Explanation/Solution You cannot switch the Check the Battery pack or the AC Power adapter. Camcorder on. Start/Stop button Check the Power switch is set to CAMERA.

  • Page 122: Specifications

    ENGLISH Specifications Model Name: SC-D351/D352/D353/D354/D355 System Video signal NTSC Video recording system 2 rotary heads, Helical scanning system Audio recording system Rotary heads, PCM system Usable cassette Digital video tape (6.35mm width): Mini DV cassette Tape speed SP: approx. 18.81mm/s Tape recording time SP: 60 minutes (when using DVM 60), LP: 90 minutes (when using DVM 60) FF/REW time...

  • Page 123: Index

    Index - A - Accessories ...12 AF/MF ... 58 Audio Dubbing ... 77 Audio Mode... 55 - B - Battery Pack ... 21 BLC ... 46 - C - Cassette ... 36 Cleaning ... 113 Clock Set... 27 Connecting ... 71 - D - Date/Time ...

  • Page 124: Warranty(Sea Users Only)

    Warranty (SEA users only) SAMSUNG Electronics America Inc. (SEA), warrants that this product is free from defective material and workmanship. SEA further warrants that if product fails to operate properly within the specified warranty period and the failure is due to improper workmanship or defective material, SEA will repair or replace the product at it’s option.
  • Page 125 ENGLISH Memo...
  • Page 126 ENGLISH Memo...
  • Page 127 ENGLISH Memo...
  • Page 128 ENGLISH THIS CAMCORDER IS MANUFACTURED BY: SERVICE DIVISION 400 Valley Road, Suite 201, Mt. Arlington N.J. 07856 Tel: 1-800-SAMSUNG (1-800-726-7864) *Samsung Electronics’ Internet Home Page AD68-00839B http://www.samsung.com...

This manual is also suitable for:

Sc-d355Sc-d354Sc-d353Sc-d351Sc d353 - minidv camcorder w/20x optical zoom

Table of Contents
