PowerBrite PB15 Rear Panel
1: Power Cord - Heavy Duty, 14 gauge mains power cord.
2: USB Socket - USB type socket for connecting the included USB gooseneck LED
lamp.
3: Switched AC outlets (horizontal mount)- Connect external equipment to these
standard 3-pin AC outlets, which are turned on and off from the front panel
Outlets switch (see #6 on the previous page).
4: Switched AC outlets (vertical mount)- Similar to the AC outlets described in #3
above, these are mounted vertically so as to accommodate external transformer
AC power adapters.
5: Ground Lug - Convenient thumb screw for connecting home run grounds.
PB15 Guided Tour - Rear Panel
