ARCHITECT'S & ENGINEER'S
SPECIFICATION
The microphone shall be of a dynamic
type with hypercardioid polar pattern. The
microphone shall provide its output on a male
XLR-type connector. Output impedance shall
be 600 ohms.
The microphone shall be constructed of a
zinc casing and shall contain a triple-plated
multi-stage windscreen and noise filter for the
removal of pops, sibilance and onstage noise,
an aluminum humbucking voice coil for the
elimination of magnetic field interference and
true hum rejection, a Neoprene transformer
cover for the reduction of microphonics, a
high-output Neodymium element, and a multi-
axis shock-mount to minimize handling noise.
The microphone shall be equipped with
an On/Off switch. The microphone shall have
frequency response from 50 Hz to 15 kHz, sen-
sitivity of -71 dBV at 94 dB SPL, and a maxi-
mum SPL of 137 dB. Dimensions shall be 1.8
(46 mm) head length, 4.2 (107 mm) main
unit length and 6 (152 mm) total length.
Weight shall be 10.5 oz. (300 g). The micro-
phone shall carry a three-year warranty.
The microphone shall be a SAMSON R11.
SAMSON
Measuring Obj.;
(dB)
R11
10
0
-10
-20
-30
-40
20
50
100
FREQUENCY RESPONSE
Type:
Polar Pattern:
Frequency Response:
Sensitivity (0 dB = 1 V / 0.1pa @ 1 kHz):
Max. SPL
Output Impedance (@ 1 kHz):
Connector:
Switch:
Dimensions:
Weight:
500
200
1000
Frequency(Hz)
Specifications subject to change without notice. © 1998 SAMSON
R11 SPECIFICATIONS
2000
5000
10000
Dynamic
Hypercardioid
50 Hz - 15 kHz
-71 dB ± 3 dB
137 dB
600 (Lo Z)
3-pin XLR male
On/Off
6 • 152mm
10.5 oz. • 300g
20000
