Husqvarna 240RJ Operator's Manual

Ryobi trimmer operator's manual
Hide thumbs Also See for 240RJ:
Table of Contents

Advertisement

Quick Links

Enlarged version
Operator´s manual
240RJ
Please read these instructions carefully and make sure
English
you understand them before using the machine.

Advertisement

Table of Contents
loading

Related Manuals for Husqvarna 240RJ

Summary of Contents for Husqvarna 240RJ

  • Page 1 Operator´s manual 240RJ Please read these instructions carefully and make sure English you understand them before using the machine.

  • Page 2: Symbol Explanation

    – English Always wear approved protective gloves. Use anti-slip and stable boots. Only use non-metallic, flexible cutting elements, that is trimmer head with trimmer cord. Only intended for the trimmer head. Noise emission to the environment according to the European Community’s Directive.

  • Page 3: Table Of Contents

    Control before starting ... 17 Start and stop ... 17 MAINTENANCE Carburettor ... 18 Muffler ... 20 Cooling system ... 20 Spark plug ... 20 Air filter ... 21 Angle gear ... 21 Maintenance schedule ... 21 TECHNICAL DATA 240RJ ... 23 English –...

  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS Personal protective equipment MPORTANT INFORMATION • A clearing saw, brushcutter or trimmer used incorrectly or carelessly can become a dangerous tool, that can cause serious or fatal injury to the operator or others. It is extremely important that you read and understand the content of this manual.
  • Page 5 SAFETY INSTRUCTIONS 3. Cutting attachment guard This guard is intended to prevent objects from being thrown towards the operator and to protect the operator from unintentionel contact with the cutting attachment. WARNING! Under no circumstances may the cutting equipment be used without an approved guard fitted.
  • Page 6 – English 6. Cutting equipment 1) Grass blades are intended for brush cutting. 2) The trimmer head is intended for trimming grass. 7. Locking nut A locking nut is used to secure some types of cutting equipment on the output shaft.

  • Page 7: Control, Maintenance And Service Of The Machine's Safety Equipment

    SAFETY INSTRUCTIONS Control, maintenance and service of the machine‘s safety equipment IMPORTANT INFORMATION • All service and repairs to the machine require special training. • This applies especially to the machine‘s safety equipment. If the machine does not meet any of the controls listed below you should contact your service workshop.
  • Page 8 6. Cutting equipment This section describes how through correct maintenance and through using the right type of cutting equipment you can: • Reduce the machine‘s tendency to kickback • Obtain maximum cutting capacity. • Increase the service life of the cutting equipment. The three basic rules: 1 Only use the cutting and guard equipment we...

  • Page 9: Cutting Equipment

    • Make sure the knife positioned on the trimmer guard is intact. This is used to cut the cord to the correct length. • To increase the life of the cord it can be soaked in water for a few days.

  • Page 10: General Safety Instructions

    General safety instructions IMPORTANT INFORMATION • The machine is only designed for trimming grass. • The only accessories to be used with the engine unit as a drive source are the cutting units we recommend in the chapter “Technical data“ . •...

  • Page 11: General Working Instructions

    General working instructions IMPORTANT INFORMATION • This section takes up the basic safety precautions for working with the trimmer. • If you encounter a situation where you are uncertain how to proceed you should ask an expert. Contact your dealer or your service workshop.
  • Page 12 – English SAFETY INSTRUCTIONS Trimming • The trimmer is ideal to cut grass that is difficult to reach using a normal lawn mower. Keep the cord parallel to the ground when cutting. Avoid...

  • Page 13: What Is What

    What is what on the trimmer? 1. Trimmer head 2. Grease filler cap 3. Angle gear 4. Spray guard 5. Shaft 6. Loop handlebar 7. Throttle 8. Stop switch 9. Throttle trigger lock 10. Suspension for harness 11. Cylinder cover 12.

  • Page 14: Assembly

    (left-hand thread). • Fit the trimmer head‘s bottom section (K) on the cover (I) by pressing the two sections together with the cut-outs on the bottom section aligned with the catches on the cover.

  • Page 15: Assembling The Blade Guard And Grass Blade

    (left-hand thread). ASSEMBLY Assembling other guards and cutting equipment • Fit the guard (A) intended for use with the trimmer head. Secure using four bolts (L) and the support plate (M) as shown in the diagram. • Fit the disc drive (B) on the output axle.

  • Page 16: Fuel Handling

    Fuel mixture NOTE! The machine is fitted with a two-stroke engine and must always be run on a mixture of petrol and two-stroke oil. It is important to measure the quantity of oil accurately, to ensure the correct mixture ratio. Small discrepancies in the amount of oil have a great bearing on the proportions of the fuel mixture when mixing small amounts of fuel.

  • Page 17: Start And Stop

    • Check that the guard is not damaged or cracked. Replace the guard if it is exposed to impact or is cracked. • Check that the trimmer head and spray guard are not damaged or cracked. Replace the trimmer head or spray guard if they are exposed to impact or are cracked.

  • Page 18: Maintenance

    Carburettor Your Husqvarna product has been designed and manufactured to specifications that reduce harmful emissions. After your unit has been run 8-10 tanks of fuel the engine has broken in. To ensure that your unit is at peak performance and producing the least amount of harmful emissions after break in, have your authorized servicing dealer, who has a revolution counter at his disposal, to adjust your carburettor for optimum operating conditions.
  • Page 19 Final setting of the idling speed T Adjust the idling speed with the screw T, if it is necessary to readjust. First turn the idle speed adjusting screw T clockwise until the cutting attachment starts to rotate/ move. Then turn, counter- clockwise until the cutting attachment stops.

  • Page 20: Muffler

    Muffler NOTE! Some mufflers are fitted with a catalytic converter. See “Technical data” to see whether your machine is fitted with a catalytic converter. The muffler is designed to dampen the noise level and to direct the exhaust fumes away from the user. The exhaust fumes are hot and can contain sparks, which can result in fire if the...

  • Page 21: Air Filter

    Replace the guards if they have been exposed to impact or are cracked. 7.Check that the trimmer head is undamaged and not cracked. Replace the trimmer head if necessary. 8.Check that the locking nut is tight.
  • Page 22 Weekly maintenance 1. Check the starter, the starter cord and the return spring. 2. Make sure that the vibration damping elements are not damaged. 3. Clean the outside of the spark plug. Remove and check the electrode gap. Adjust the gap to 0.5 mm or change the spark plug.

  • Page 23: Technical Data

    NOTE! The noise pressure level at operator’s ear and vibrations on the handles are measured with all the approved cutting attachments for the machine. The table indicates the lowest and highest values. TECHNICAL DATA 240RJ 36,3 2 700 11 000-11 700...

  • Page 24: Ec Declaration Of Conformity

    We, Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46 36-146500, declare under sole responsibility that the clearings saws Husqvarna 240RJ from 2002’s serial numbers and onwards (the year is clearly stated in plain text on the type plate with subsequent serial number), are in conformity with the following standards or other normative documents following the provisions in the COUNCIL’S DIRECTIVES:...
  • Page 25 Super Auto II Super Auto II 1 " 4,0 m 15 cm ~2,0 m 6,5 ' 15 cm 6 " 6 " English –...
  • Page 26 Tri Cut >20mm >20mm 6 Nm X 10 – English...
  • Page 27 Trimmy H II 15 cm 6" 7,5 m ~ 3,7 m 15 cm 6" English –...
  • Page 28 Trimmy Hit “Click” ~ 15 cm " – English 15 cm 6 " 7,0 m ~ 3,5 m 12 cm 5" “Click”...
  • Page 29 Trimmy Hit Junior 15 cm 6" “Click” 15 cm 6" 5,75 m 15 cm 6" ~ 2,8 m English –...
  • Page 30 Trimmy Hit Pro 15 cm 6" “Click” – English 7,5 m ~ 3,7 m 15 cm 6" 15 cm 6"...
  • Page 31 Trimmy Hit VI ~ 15 cm " 15 cm " 7,0 m 12 cm 5" ~ 3,5 m “Click” English –...
  • Page 32 Trimmy SII ~ 15 cm – English 35-50 NM 7,0 m 12 cm 5" ~ 3,5 m "Clic"...
  • Page 33 Trimmy SII ~ 15 cm ~ 15 cm 502 26 04-01 502 25 56-01 502 25 53-01 729 53 27-71 (x3) 738 21 03-04 502 26 24-01 (x2) 740 43 14-00 502 26 03-01 502 25 52-01 502 26 01-01 735 31 19-00 502 27 07-01 502 26 86-01...
  • Page 34 ´+H'"¶6A¨...
  • Page 35 English –...
  • Page 36 114 00 70-26 ´+H'"¶6A¨ 2002W04...
